Product Overview: GE IC693MDL634
The GE IC693MDL634 is a 24VDC Positive Logic Output module designed for use within the GE Series 90-30 PLC system. It is engineered to provide reliable interfacing between low-voltage DC field devices and the PLC’s central processing 台 (CPU). This module supports output switching / up to 0.5 amps per point and /fers 16 output points grouped into two isolated groups / 8. With fast response time, high isolation, and rugged industrial design, the IC693MDL634 is suitable for a broad range / automation tasks in manufacturing, utilities, and infrastructure.
Technical Specifications
| Parameter | Details |
|---|---|
| メーカー | GE Fanuc / General Electric |
| Product Series | Series 90-30 |
| Module Type | Discrete Output Module |
| Output Type | Positive Logic (Source) |
| Voltage Range | 5VDC to 30VDC (Nominal: 24VDC) |
| Number / Points | 16 outputs |
| Groups | 2 isolated groups / 8 |
| Max Load per Point | 0.5 A |
| Max Load per Module | 4.0 A total (2 A per group) |
| Output Delay (ON/OFF) | <0.5 ms |
| Isolation | 1500V AC (field to logic) |
| Power Consumption | 80 mA from +5V backplane |
| LED Indicators | Yes (1 per output point) |
| Terminal Type | Removable terminal block |
| Mounting | DIN rail or panel mount |
| Module Dimensions | 130 x 40 x 100 mm |
| 重量 | 0.24 kg |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% (non-condensing) |
| Agency Approvals | UL, CE, CSA, Class I Div 2, FCC |
Product Applications
The GE IC693MDL634 is commonly deployed in:
-
Automated manufacturing lines – Controls DC solenoids, relays, valves, and contactors.
-
Material handling systems – Operates actuators and indicator lamps.
-
Process control systems – Used to interface with low-voltage DC field equipment.
-
Building automation – Controls access systems, lighting, and alarms.
-
Water treatment plants – Activates pumps, gates, and status indicators.
-
Renewable energy systems – Enables switching in low-voltage subsystems.
Product Advantages
-
High Reliability: Built for industrial use with robust isolation and durable electronics.
-
Fast Switching: Output response time under 0.5 milliseconds ensures real-time control.
-
Field Flexibility: Two independently isolated groups support diverse wiring schemes.
-
Status Monitoring: Integrated LEDs allow easy diagnostic / each output.
-
Compact Design: Fits into space-constrained control panels with ease.
-
Wide Voltage Range: Compatible with standard 24VDC systems as well as other DC ranges.
-
Ease / Replacement: Plug-in design with removable terminals simplifies maintenance.
よくある質問 (FAQ)
Q1: What type / load is suitable for the IC693MDL634?
A1: It is ideal for resistive and inductive DC loads up to 0.5A per point, such as relays, contactors, and LED indicators.
Q2: Can the IC693MDL634 be used in negative logic systems?
A2: No, it is designed specifically for positive logic (source-type) outputs.
Q3: How many outputs can I energize at the same time?
A3: All 16 outputs can be energized simultaneously, provided the total current per group does not exceed 2A and the entire module does not exceed 4A.
Q4: Is it hot-swappable?
A4: No, for safety and integrity, power must be removed before replacing or installing the module.
Q5: What does each LED indicator show?
A5: Each LED indicates the ON/OFF status / its corresponding output point.
Q6: Does the module support any diagnostic features?
A6: Besides LED indicators, the module relies on system-level diagnostics via the PLC CPU.
Q7: Is this module compatible with VersaMax or RX3i systems?
A7: No, it is specifically designed for the GE Series 90-30 system.
Q8: What is the field-to-logic isolation rating?
A8: The module /fers 1500V AC isolation between field and logic circuits.
Q9: What protection is in place for short circuits?
A9: Each output channel includes current limiting, but external fusing is still recommended.
Q10: Can this module operate in hazardous environments?
A10: It is certified for Class I Div 2 environments, making it suitable for many hazardous industrial settings.
