製品紹介
The Epro PR6426/000-021 Eddy Current Sensor is a precision proximity probe designed for non-contact measurement / shaft vibration, axial displacement, and rotational position in critical rotating machinery. With a 32 mm sensor head diameter, this model is part / Epro’s advanced PR6426 series, known for its reliability in harsh industrial environments such as turbines, compressors, and generators. The sensor utilizes the eddy current principle to deliver highly accurate measurements / metallic target motion and position without physical contact, ensuring minimal wear and maximum longevity.
This model is optimized for integration with Epro CON021 and CON041 converters, providing stable and linear output across a wide measuring range. Built with rugged stainless-steel housing and hermetically sealed construction, it /fers excellent resistance to oil, moisture, and high temperatures, making it ideal for long-term monitoring in demanding applications.
Technical Specifications
| Parameter | 説明 |
|---|---|
| モデル | Epro PR6426/000-021 |
| Sensor Type | Eddy Current Proximity Probe |
| Measuring Principle | Non-contact electromagnetic induction (eddy current) |
| Sensor Head Diameter | 32 mm |
| Measuring Range | Typically 4 mm to 8 mm (depends on target material and configuration) |
| Linearity | ≤ ±1% / full-scale |
| Frequency Response | Up to 10 kHz (-3 dB) |
| Sensitivity | 8 mV/µm (nominal, depending on converter configuration) |
| Target Material | Ferromagnetic and conductive materials (e.g., steel, nickel alloys) |
| Operating Temperature | -35 °C to +180 °C (probe only) |
| Storage Temperature | -40 °C to +200 °C |
| Pressure Rating | Up to 20 bar (depending on installation) |
| Output Signal | Dependent on converter (e.g., 4–20 mA or voltage output) |
| Insulation Resistance | >100 MΩ at 500 VDC |
| Housing Material | Stainless steel (AISI 316L) |
| Mounting Thread | M32 x 1.5 |
| Connection Type | Compatible with Epro CON021/CON041 |
| 重量 | 0.8 kg |
| Protection Class | IP67 (fully sealed) |
| Compliance | CE, ATEX Zone 2 (optional), RoHS compliant |
Product Applications
The PR6426/000-021 is specifically designed for condition monitoring and vibration analysis in critical rotating machinery. Its precision and rugged construction make it suitable for use in:
-
Steam and gas turbines for shaft vibration monitoring
-
Compressors and pumps for radial displacement measurement
-
Generators and motors for bearing and rotor position tracking
-
Gearboxes and turboexpanders for early fault detection
-
Process industries such as petrochemical, power generation, and marine propulsion systems
The sensor’s compatibility with Epro monitoring systems ensures real-time data acquisition and reliable integration with protection and control systems.
Product Advantages
-
High Measurement Precision – Provides accurate displacement data even under extreme vibration or temperature conditions.
-
Non-お問い合わせ Design – Eliminates mechanical wear, ensuring long-term stability and minimal maintenance.
-
Wide Operating Range – Performs effectively in both low and high-speed rotating machinery.
-
Robust Construction – Stainless-steel housing and hermetic sealing guarantee durability against oil, dust, and moisture.
-
優良 Linearity – Ensures consistent signal output across the full measurement range.
-
Modular System Compatibility – Seamlessly integrates with Epro CON021 and CON041 for signal conditioning and data output.
-
High Temperature Resistance – Designed to withstand harsh environments and maintain stable performance.
-
Field Proven Reliability – Extensively used in industrial monitoring systems worldwide.
FAQ
-
What is the measuring principle / the PR6426/000-021 sensor?
It operates using the eddy current principle, detecting changes in electromagnetic fields caused by the motion / conductive targets. -
Can this sensor measure both radial and axial displacements?
Yes, it is capable / measuring both radial shaft vibration and axial displacement depending on the installation orientation. -
Is the PR6426/000-021 compatible with all Epro converters?
It is fully compatible with Epro CON021 and CON041 converters, which provide calibration and signal conditioning. -
How is linearity maintained over the measuring range?
The sensor features precision-wound coils and calibrated electronics that ensure linear output characteristics across its range. -
What is the frequency response capability / this sensor?
The PR6426/000-021 provides frequency response up to 10 kHz (-3 dB), suitable for dynamic vibration monitoring. -
Can this model be used in hazardous areas?
Yes, with appropriate certification such as ATEX Zone 2 or equivalent when used with certified converters and cabling. -
What materials are compatible with the sensing element?
The sensor is designed for ferromagnetic and conductive materials such as steel, nickel, or cobalt alloys. -
How does temperature affect sensor accuracy?
The sensor’s internal compensation circuit minimizes drift over a wide temperature range, ensuring stable measurement. -
Is the PR6426/000-021 suitable for integration into turbine monitoring systems?
Absolutely, it is widely used for turbine vibration and axial displacement measurement in condition monitoring systems. -
Does the sensor require field calibration after installation?
Calibration is typically performed through the Epro converter, and no mechanical adjustment / the probe is required once installed.
Related モデルs (Same Series)
| モデル | 説明 | Sensor Head Diameter | 重量 |
|---|---|---|---|
| PR6426/000-000 | Standard eddy current sensor | 32 mm | 0.8 kg |
| PR6426/000-010 | High-temperature version | 32 mm | 0.8 kg |
| PR6426/000-020 | Pressure-resistant version | 32 mm | 0.8 kg |
| PR6426/000-030 | Extended range version | 32 mm | 0.8 kg |
| PR6426/000-040 | Compact housing version | 25 mm | 0.6 kg |
| PR6426/000-050 | Explosion-pro/ model | 32 mm | 0.9 kg |
Popular モデルs from the Same ブランド (Epro)
| モデル | 説明 | Measurement Type | 重量 |
|---|---|---|---|
| PR6423/002-030 | Eddy current sensor | Vibration/Displacement | 0.6 kg |
| PR6424/014-040 | Eddy current probe | Axial displacement | 0.7 kg |
| PR6425/010-030 | Proximity probe | Shaft vibration | 0.8 kg |
| PR6422/010-030 | Compact probe | Bearing displacement | 0.5 kg |
| MMS3120/022-100 | Vibration monitoring module | 状態 monitoring | 1.2 kg |
| MMS6822 | Dual-channel monitor | Shaft and casing vibration | 1.5 kg |
