The Bently Nevada 288055-01+146031-01 Transient Data Interface Module (TDIM) is a high-performance device designed to capture, process, and interface transient data from industrial machinery monitoring systems. This module provides a bridge between vibration sensors, proximity probes, and monitoring systems, enabling real-time acquisition / high-speed transient signals.
The TDIM is engineered to support advanced diagnostic and condition monitoring applications, capturing transient events such as impacts, sudden speed changes, and mechanical shocks. It integrates seamlessly with Bently Nevada monitoring systems, including the 3500 and 3300 series, providing precise, high-fidelity data for machinery diagnostics, predictive maintenance, and troubleshooting. The module’s robust construction and industrial-grade components ensure reliable performance in harsh operating environments with electrical noise, vibration, and temperature variations.
Technical Specifications
| Parameter | Specification |
|---|---|
| モデル Number | 288055-01+146031-01 |
| Product Type | Transient Data Interface Module |
| Input Channels | Up to 8 simultaneous transient input channels |
| Output Interface | Standard Bently Nevada interface protocols |
| Signal Type | Analog voltage from vibration and proximity sensors |
| Sample Rate | Up to 100 kHz per channel |
| Resolution | 16-bit |
| Operating Temperature | -20°C to 70°C |
| Storage Temperature | -40°C to 85°C |
| Power Supply | 24 V DC ±10% |
| Dimensions | 81.3 x 35.1 x 63.5 mm |
| 重量 | 0.246 kg |
| Environmental Rating | IP20 |
| Compliance | IEC, ISO, and Bently Nevada internal standards |
| Connector Type | Standard industrial D-sub or screw terminals |
Applications
-
Real-time acquisition / transient events in rotating machinery
-
Integration with Bently Nevada 3500 and 3300 series monitoring systems
-
状態 monitoring / turbines, compressors, generators, and pumps
-
Detection / impacts, misalignment, sudden load changes, and mechanical shocks
-
サポート for predictive maintenance programs and early fault detection
-
Laboratory and field testing for machinery diagnostic studies
-
High-speed signal acquisition for advanced vibration analysis and fault detection
Advantages
-
High-Speed Data Capture: サポートs up to 100 kHz sampling per channel for accurate transient detection
-
Multi-Channel Input: Allows simultaneous monitoring / multiple sensors for comprehensive analysis
-
Reliable Signal Processing: Provides precise analog-to-digital conversion with 16-bit resolution
-
Seamless System Integration: Compatible with Bently Nevada 3500 and 3300 series monitoring systems
-
Robust Construction: Industrial-grade components ensure performance under vibration, electrical noise, and temperature variations
-
Predictive Maintenance サポート: Captures transient data critical for early fault detection
-
Flexible Connectivity: サポートs standard industrial connectors for easy integration with monitoring systems
FAQ
-
How many input channels does the Transient Data Interface Module support?
The TDIM supports up to 8 simultaneous transient input channels, allowing multiple sensors to be monitored at the same time. -
What type / signals can the module process?
It processes analog voltage signals from vibration sensors and proximity probes, capturing high-speed transient events. -
What is the maximum sampling rate per channel?
The module supports up to 100 kHz sampling per channel, ensuring high-fidelity capture / transient signals. -
What is the resolution / the module’s analog-to-digital conversion?
The module provides 16-bit resolution, /fering precise signal digitization for detailed analysis. -
Which monitoring systems is this module compatible with?
It is compatible with Bently Nevada 3500 and 3300 series monitoring systems, facilitating seamless integration. -
Can the module capture sudden mechanical shocks or impacts?
Yes, it is specifically designed to capture transient events such as mechanical shocks, impacts, and sudden load changes. -
What type / connectors does the module use?
It uses standard industrial D-sub connectors or screw terminals for sensor and system connections. -
What is the operating temperature range?
The module operates reliably in temperatures from -20°C to 70°C, suitable for typical industrial control environments. -
Is the module suitable for predictive maintenance applications?
Yes, the TDIM provides high-speed transient data essential for early fault detection and predictive maintenance. -
Can this module be used in laboratory or field testing?
Yes, it is designed for both laboratory experiments and field testing, capturing precise transient events in real machinery conditions.
