製品紹介
The Emerson SE4601T07 KL4201X1-BA1 CHARM Baseplate is a critical component within the DeltaV™ Electronic Marshalling system. It serves as a mounting platform for CHARM (CHARacterization Module) I/O modules, facilitating flexible and efficient integration / field devices into the control system. Designed for use in both standard and hazardous environments, this baseplate supports various terminal block configurations, ensuring adaptability to diverse application requirements.
Technical Specifications
| Parameter | Details |
| モデル Number | SE4601T07 |
| Ordering Number | KL4201X1-BA1 |
| Product Type | CHARM Baseplate |
| メーカー | Emerson |
| Product Line | DeltaV™ Electronic Marshalling |
| Dimensions (H x W x D) | 200 x 120 x 60 mm |
| 重量 | 0.499 kg |
| CHARM Bus Power | 6.3 VDC at 4 A |
| Field Circuit Power | 24 VDC at 10 A |
| Operating Temperature | -40°C to +70°C |
| Humidity Range | 5% to 95% non-condensing |
| Vibration Resistance | 1 mm peak-to-peak (2–13.2 Hz), 0.7 g (13.2–150 Hz) |
| Shock Resistance | 10 g, ½ sine wave for 11 ms |
| Certifications | CE, ATEX, IECEx, FM (Class I, Div 2, Groups A-D) |
| Mounting Type | DIN rail or panel mount |
| Terminal Block サポート | Standard, Fused Injected Power, 3-wire DI, 3-wire AI, Relay Output, Thermocouple/mV |
Product Applications
The Emerson SE4601T07 KL4201X1-BA1 CHARM Baseplate is utilized across various industries due to its versatility and robust design:
-
Oil & Gas: Facilitates integration / field instruments in upstream and downstream processes.
-
Chemical Processing: サポートs safe and efficient control in hazardous environments.
-
Power Generation: Enables reliable monitoring and control / power plant operations.
-
Pharmaceuticals: Assists in maintaining stringent process control and compliance standards.
-
Water & Wastewater Treatment: Enhances automation and monitoring / treatment facilities.
-
Food & Beverage: サポートs precise control systems for production and packaging lines.
Product Advantages
-
Flexibility: Compatible with a wide range / CHARM I/O modules and terminal blocks, allowing customization to specific application needs.
-
Safety Compliance: Certified for use in hazardous locations, ensuring safe operation in challenging environments.
-
Compact Design: Space-saving dimensions facilitate installation in areas with limited space.
-
Robust Construction: Designed to withstand harsh industrial conditions, including extreme temperatures, vibration, and shock.
-
Ease / Integration: Seamlessly integrates into the DeltaV™ system, simplifying the process / adding or modifying I/O points.
-
Efficient Power Distribution: Provides reliable power to connected field devices, reducing the need for additional power supplies.
よくある質問 (FAQ)
-
What is the primary function / the KL4201X1-BA1 CHARM Baseplate?
-
It serves as a mounting and connection platform for CHARM I/O modules within the DeltaV™ system.
-
-
Is the baseplate suitable for use in hazardous environments?
-
Yes, it holds certifications such as ATEX and IECEx for use in hazardous locations .
-
-
What types / terminal blocks are compatible with this baseplate?
-
It supports various terminal blocks, including standard, fused injected power, 3-wire DI, 3-wire AI, relay output, and thermocouple/mV types .
-
-
What are the power specifications for the CHARM bus and field circuits?
-
CHARM Bus Power: 6.3 VDC at 4 A; Field Circuit Power: 24 VDC at 10 A .
-
-
What are the environmental operating conditions for this baseplate?
-
Operating temperature ranges from -40°C to +70°C, with a humidity range / 5% to 95% non-condensing .
-
-
How is the baseplate mounted within a control system?
-
It can be mounted on a DIN rail or directly onto a panel, /fering flexibility in installation.
-
-
What are the dimensions and weight / the baseplate?
-
Dimensions: 200 x 120 x 60 mm; 重量: 0.499 kg.
-
-
Is the baseplate compatible with all DeltaV™ systems?
-
Yes, it is designed to integrate seamlessly with DeltaV™ Electronic Marshalling systems.
-
-
Can different types / terminal blocks be used simultaneously on the same baseplate?
-
Yes, the design allows for mixing different terminal block types to suit various application requirements.
-
-
What is the warranty period for the KL4201X1-BA1 CHARM Baseplate?
-
We provide one year warranty.
-
Related モデルs from the Same Series or Functionality
| モデル Number | 説明 | Key Features |
| SE4602T07 | CHARM Baseplate with Fused Injected Power | Adds fused power injection; supports high-availability I/O configurations. |
| SE4603T07 | CHARM Baseplate for 3-Wire DI Modules | Tailored for 3-wire discrete input applications. |
| SE4604T07 | CHARM Baseplate for 3-Wire AI Modules | Optimized for 3-wire analog input configurations. |
| SE4605T07 | CHARM Baseplate for Relay Output | Designed to support relay output CHARMs. |
| SE4606T07 | CHARM Baseplate for Thermocouple/mV Modules | Built for low-voltage signal inputs like thermocouples. |
| KL4201X1-BB1 | CHARM Baseplate with advanced terminal block version | Enhanced wiring interface for rugged environments. |
Popular モデルs from Emerson (Same ブランド, Various Applications)
| モデル Number | 説明 | Key Features |
| DeltaV MX Controller | Advanced control module for DeltaV systems | Scalable performance, embedded redundancy, easy integration. |
| CHARM I/O Card (CIOC) | I/O interface for CHARM modules | Enables hot-swappable CHARM modules, networked over DeltaV backbone. |
| VE4034C1 | DeltaV KJ4001X1-BE1 Analog Input Card | High-performance AI card with 4–20 mA or HART signal support. |
| KJ3001X1-BB1 | DeltaV 12-Channel DI Card | Used for connecting discrete field inputs to DeltaV systems. |
| KJ4001X1-CA1 | DeltaV Redundant Controller | Provides redundancy in critical process applications. |
| VE4003S2T2B2 | DeltaV Field Interface Module | Bridges field devices and controller hardware with precise signal conditioning. |
