The Ovation 1X00095H01 Ethernet Switch is a high-reliability industrial networking component designed for Emerson Ovation Distributed Control Systems (DCS). It provides fast, deterministic Layer-2 switching to interconnect controllers, operator workstations, SCADA servers, and remote I/O subsystems. With rugged construction, redundant power inputs, and advanced management options, the 1X00095H01 ensures uninterrupted communication even in harsh industrial environments. This switch is optimized for critical infrastructure such as power generation, water treatment, and process automation where dependable real-time data exchange is essential.
製品仕様
| Parameter | Details |
|---|---|
| モデル Number | 1X00095H01 |
| Product Type | Managed Industrial Ethernet Switch |
| Switching Capacity | 8 Gbps non-blocking |
| Packet Forwarding Rate | 6 Mpps |
| Ports | 8 × 10/100 Mbps RJ-45 copper ports, 2 × 100/1000 Mbps SFP fiber slots |
| VLAN サポート | IEEE 802.1Q, up to 256 VLANs |
| Redundancy Protocols | RSTP (802.1w), MSTP, Ring redundancy |
| Power Input | Dual redundant 24 VDC (18–36 VDC) |
| Power Consumption | <15 W typical |
| Protection Features | Over-voltage, reverse polarity, and ESD protection |
| Management Interfaces | Web GUI, SNMP v1/v2c/v3, Telnet/SSH CLI |
| Operating Temperature | –40 °C to +75 °C |
| Storage Temperature | –40 °C to +85 °C |
| Relative Humidity | 5–95% non-condensing |
| Cooling Method | Fan-less natural convection |
| Dimensions (L × W × H) | 220 × 40 × 120 mm |
| 重量 | 0.8 kg |
| Compliance | CE, FCC Class A, UL 508, IEEE 1613 |
Applications
-
Power Generation Plants – Integrates Ovation controllers, HMIs, and SCADA networks in fossil, nuclear, and renewable energy facilities.
-
Water and Wastewater – Provides redundant network backbones for pumping stations and treatment plants.
-
Oil & Gas Processing – Ensures deterministic communications for refineries and chemical plants.
-
Industrial Automation – Links PLCs, remote I/O, and SCADA servers with low latency.
-
Transportation Systems – サポートs networked monitoring / tunnels, rail systems, and traffic controls.
-
Distributed Data Acquisition – Connects high-speed data loggers and analytical systems in large industrial sites.
Advantages
-
Industrial Ruggedness – Wide operating temperature range and surge protection for challenging field conditions.
-
High Availability – Dual power inputs and ring redundancy protocols reduce network downtime.
-
Advanced Management – Web interface, SNMP, and CLI for flexible configuration and remote diagnostics.
-
Wire-Speed Switching – Non-blocking architecture guarantees microsecond-level packet forwarding.
-
Maintenance-Free Design – Fan-less cooling ensures silent, reliable operation with minimal upkeep.
-
Seamless DCS Integration – Fully certified for Emerson Ovation systems for quick deployment.
FAQ
-
Which network management protocols are supported?
The switch supports SNMP v1/v2c/v3, secure web management, and CLI via Telnet or SSH for flexible remote administration. -
Does the 1X00095H01 support redundancy for critical industrial networks?
Yes, it implements Rapid Spanning Tree (RSTP), Multiple Spanning Tree (MSTP), and ring topologies for fast recovery. -
What is the maximum switching capacity?
The non-blocking fabric provides up to 8 Gbps switching capacity, enabling full-duplex traffic on all ports simultaneously. -
Are fiber connections available on this switch?
Two SFP slots support 100/1000 Mbps fiber transceivers for long-distance backbone connections. -
How does the 台 handle power fluctuations or failures?
Dual redundant 24 VDC inputs and over-voltage protection guarantee continuous operation during power disturbances. -
Is VLAN configuration supported for network segmentation?
Yes, IEEE 802.1Q VLAN tagging is supported with up to 256 configurable VLANs for secure traffic separation. -
What latency can be expected for packet forwarding?
The switch provides wire-speed forwarding with microsecond-level latency, ideal for real-time control traffic. -
Does it include electrostatic discharge protection?
Yes, integrated ESD and surge suppression protect internal circuits from electrical disturbances. -
Can it be mounted in a standard Ovation control cabinet?
Yes, the 台 is designed for direct mounting in Ovation DCS enclosures or standard 19-inch racks. -
Is it suitable for outdoor or unconditioned environments?
Absolutely. Its –40 °C to +75 °C operating range and rugged enclosure support deployment in harsh conditions.
