The Bently Nevada 330851-02-010-100-90-01-05 3300 XL 25 mm Proximity Probe is a high-performance non-contact vibration and displacement measurement device designed for industrial machinery monitoring. As part / the 3300 XL series, this probe is engineered to provide highly reliable shaft vibration, axial position, and clearance measurements in demanding environments.
Technical Specifications
| Parameter | Value |
|---|---|
| Product モデル | 330851-02-010-100-90-01-05 |
| Series | 3300 XL 25 mm Proximity Probe |
| Probe Tip Diameter | 25 mm |
| Total Length | 9 m |
| 重量 | 1.57 kg |
| Linear Range | Up to 25.4 mm |
| Sensitivity | 200 mV/mil (7.87 mV/µm) |
| Frequency Range | DC to 10 kHz |
| Typical Output Voltage | -2 V to -18 V (proportional to distance) |
| Operating Temperature | -35 °C to +177 °C |
| Cable Type | Armored extension cable for harsh areas |
| Compliance | API 670, ISO vibration monitoring standards |
Product Applications
-
Turbomachinery monitoring such as gas turbines, steam turbines, and compressors.
-
Large rotating equipment including generators, motors, and pumps.
-
Axial position and shaft displacement monitoring in high-speed machinery.
-
状態 monitoring systems in refineries, petrochemical plants, and power generation facilities.
-
Safety and protection systems to prevent equipment damage due to excessive vibration.
Product Advantages
-
High Precision Measurement – Provides stable and accurate shaft vibration readings.
-
Wide Linear Range – Allows reliable displacement measurements up to 25 mm.
-
Rugged Construction – Designed to withstand high temperatures and harsh operating environments.
-
Long Distance Signal Transmission – 9 m total length ensures installation flexibility.
-
Industry Standard Compliance – Compatible with API 670 and global monitoring requirements.
-
Reliability in Harsh Environments – Armored cabling protects against mechanical damage and interference.
FAQ
Q1: What type / transducer does the 330851-02-010-100-90-01-05 work with?
A1: It is designed to work with Bently Nevada 3300 XL Proximitor sensors for accurate displacement measurements.
Q2: What is the linear measurement range / this probe?
A2: The linear range is up to 25.4 mm, ensuring precise monitoring across a wide shaft displacement.
Q3: Can this probe operate in high-temperature environments?
A3: Yes, it can operate reliably between -35 °C and +177 °C.
Q4: How is the sensitivity / the probe defined?
A4: The sensitivity is 200 mV/mil (7.87 mV/µm), allowing fine resolution in shaft vibration monitoring.
Q5: Does the probe comply with industry standards?
A5: Yes, it complies with API 670 and ISO machinery protection standards.
Q6: What is the frequency response range?
A6: The probe covers a range from DC up to 10 kHz.
Q7: Is the probe suitable for axial position monitoring?
A7: Yes, it is commonly used for both axial position and shaft vibration monitoring.
Q8: What type / cable protection does it have?
A8: It features an armored extension cable designed for durability in harsh industrial settings.
Q9: Can it be used in hazardous environments?
A9: Yes, it is built with rugged construction and can be applied in refinery, petrochemical, and power plant conditions.
Q10: What monitoring systems is it typically integrated with?
A10: It is typically integrated with Bently Nevada 3500 series monitoring systems for machinery protection.
Recommended Same-Series or Related モデルs
| モデル Number | 説明 |
|---|---|
| 330851-02-000-100-90-01-05 | 3300 XL 25 mm Probe, standard length |
| 330851-02-020-100-90-01-05 | 3300 XL 25 mm Probe, extended cable version |
| 330851-02-030-100-90-01-05 | 3300 XL 25 mm Probe, long distance application |
| 330851-02-040-100-90-01-05 | 3300 XL 25 mm Probe, armored configuration |
| 330851-02-050-100-90-01-05 | 3300 XL 25 mm Probe, special temperature range |
| 330851-02-060-100-90-01-05 | 3300 XL 25 mm Probe, heavy-duty installation |
Popular モデルs from the Same ブランド
| モデル Number | 説明 |
|---|---|
| 330103-00-05-05-02-00 | 3300 XL 8 mm Proximity Probe |
| 330104-00-09-10-02-00 | 3300 XL 11 mm Proximity Probe |
| 330130-045-00-00 | Extension Cable for XL Probes |
| 330180-90-00 | Proximitor Sensor for XL probes |
| 3500/42M | Proximitor/Seismic Monitor Module |
| 3500/22M | Transient Data Interface Module |
| 330500-01-00 | Velocity Seismoprobe |
| 3500/32M | 4-Channel Relay Module |
