製品紹介
The Allen Bradley 2098-DSD-030-SE Ultra3000 Digital Servo Drive is a high-performance motion control solution designed for industrial automation systems requiring precise servo control and stable high-speed operation. As part / the Ultra3000 series, this drive integrates advanced digital control technology with SERCOS-based communication to deliver synchronized, deterministic motion performance in multi-axis systems.
With a 3 kW power rating and a 15–30 AMP operating range, the drive is well suited for medium-to-heavy industrial applications. It supports a wide 100–240 VAC input range along with a dedicated 12/24 VDC control supply, ensuring reliable operation under varying electrical conditions. Its robust design, combined with accurate positioning control, makes it ideal for CNC machinery, packaging systems, robotics, and automated production lines where motion precision and repeatability are essential.
製品仕様
| Parameter | Specification |
|---|---|
| モデル | 2098-DSD-030-SE |
| Series | Ultra3000 |
| Type | Digital Servo Drive |
| Communication | SERCOS Interface |
| Input Voltage | 100–240 VAC |
| Frequency | 50/60 Hz |
| Control Supply Voltage | 12/24 VDC |
| Power Rating | 3 kW |
| Current Range | 15–30 AMP |
| Control Modes | Position, Velocity, Torque |
| Motor Compatibility | Allen-Bradley Servo Motors |
| Protection Features | Overcurrent, Overvoltage, Thermal Protection, Fault Diagnostics |
| Cooling Method | Forced Air Cooling |
| Environmental Rating | IP20 |
| Dimensions | 360.68 × 91.44 × 243.84 mm |
| 重量 | 6.2 kg |
Applications
• CNC machining systems, providing accurate multi-axis coordination and stable servo performance for cutting and shaping operations.
• Industrial robotics, supporting synchronized motion control for assembly, welding, and pick-and-place systems.
• Packaging machinery, enabling precise speed and position control for filling, sealing, and labeling processes.
• Material handling systems, ensuring smooth and repeatable motion in conveyors and automated transfer systems.
• Printing and converting equipment, maintaining tight registration control and consistent motion accuracy.
Advantages
• High power output (3 kW) supports demanding industrial automation and heavy-load applications.
• SERCOS communication interface ensures real-time, deterministic motion synchronization across multiple axes.
• Wide voltage compatibility (100–240 VAC) allows flexible installation in different industrial environments.
• Stable dual control supply (12/24 VDC) improves system reliability and control consistency.
• Advanced digital servo control provides high precision, fast response, and smooth motor operation.
• Robust industrial design ensures reliable performance under continuous operation and harsh factory conditions.
