Introduction
The Allen Bradley 1770-XYC is a communication module for the PLC-5 platform, enabling high-speed data exchange between PLCs, operator interfaces, and remote I/O. From a system integration perspective, the 1770-XYC is vital in multi-rack installations where deterministic communication and reliable data transfer are critical. It allows engineers to extend system reach, integrate heterogeneous equipment, and maintain robust control network architecture across industrial facilities.
Technical Specifications
| Parameter | 説明 |
|---|---|
| モデル Number | 1770-XYC |
| Module Type | Communication Module |
| Platform Compatibility | Allen Bradley PLC-5 |
| Communication Protocol | Proprietary PLC-5 network / Data Highway Plus / optional ASCII/Serial |
| Baud Rate | Configurable 9600–57,600 bps depending on network |
| Number / Nodes サポートed | Up to 32 nodes on standard DH+ network |
| Isolation | Optical isolation between network and module electronics |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | –40°C to +85°C |
| Dimensions (H × W × D) | ≈ 140 mm × 35 mm × 160 mm |
| 重量 | ≈ 0.28 kg |
| Mounting | PLC-5 standard chassis slot |
Applications
-
Connecting PLC-5 processors to Data Highway Plus networks for distributed control
-
Multi-rack communication and synchronization between remote PLC racks
-
Integration / PLCs with operator interfaces or supervisory control systems
-
Serial ASCII communication for legacy devices or specialty instrumentation
-
Network expansion in process plants, packaging lines, or material handling systems
Advantages
-
Deterministic communication: Ensures predictable timing for critical control operations
-
Network scalability: サポートs multi-rack, multi-node configurations with consistent performance
-
Electrical isolation: Protects PLCs and I/O modules from network surges or faults
-
Compact design: Minimal footprint preserves chassis space for additional I/O
-
Flexible integration: Compatible with legacy and modern PLC-5 communication setups
