製品紹介
The ABB TP857 3BSE030192R1 Baseplate is a precision-engineered mounting platform designed to provide robust support and secure installation for ABB TP series protection relays and related control equipment. Manufactured with high-grade materials, this baseplate ensures stability and durability in industrial environments. Its design accommodates easy integration into control panels and switchgear assemblies, enabling optimal positioning and reliable operation / protective devices.
Built to meet ABB’s rigorous quality standards, the TP857 baseplate plays a critical role in maintaining system integrity, facilitating straightforward maintenance, and minimizing downtime. It is an essential component for customers who require dependable and long-lasting infrastructure for their electrical protection solutions.
製品仕様
| Parameter | Specification |
|---|---|
| モデル Number | TP857 3BSE030192R1 |
| Material | High-grade steel with corrosion-resistant coating |
| Dimensions (L x W x H) | 160 x 120 x 60 mm |
| 重量 | 0.27 kg |
| Mounting Hole Pattern | Standard ABB TP series relay compatible |
| Surface Finish | Powder coated |
| Operating Temperature | -20°C to +70°C |
| Compliance | IEC, UL certified |
Product Applications
The ABB TP857 baseplate is primarily used in electrical protection and control systems across various industries. Typical applications include:
-
Mounting / ABB TP series protection relays in control panels.
-
Integration into switchgear assemblies for power distribution networks.
-
Utilization in industrial automation systems for secure relay positioning.
-
Electrical substations requiring reliable relay support infrastructure.
-
Power plants where robust and stable baseplates enhance protection system performance.
-
Maintenance and retr/it projects aimed at upgrading relay installations without major panel modifications.
Its versatility and compatibility with multiple ABB relay models make it suitable for diverse industrial environments, ensuring safe and efficient protection relay operation.
Product Advantages
-
Durability: Constructed from high-grade steel with corrosion-resistant coatings, ensuring longevity even in harsh environments.
-
Precision Fit: Designed specifically for ABB TP series relays, guaranteeing perfect alignment and secure mounting.
-
Ease / Installation: Pre-drilled mounting holes and standardized dimensions allow quick and hassle-free installation.
-
Enhanced Stability: Provides a solid and vibration-resistant platform that minimizes relay movement and potential damage.
-
Corrosion Resistance: Powder coating protects the baseplate against environmental factors such as moisture and dust.
-
Cost-Effective: Durable design reduces the need for frequent replacements or repairs.
-
Compliance: Meets international standards ensuring safe use within global electrical systems.
-
Maintenance Friendly: Easy to clean and access, facilitating regular inspection and upkeep.
-
Universal Compatibility: Works well with a wide range / ABB TP series relays and accessories.
-
Improved Safety: Secure mounting reduces risk / loose connections and electrical faults.
よくある質問 (FAQ)
-
What relays are compatible with the ABB TP857 baseplate?
The baseplate is designed to fit ABB TP series relays, including models TP700, TP750, and TP760. -
Is the baseplate suitable for outdoor use?
While durable, it is recommended to use it within protected or indoor environments to avoid direct exposure to extreme weather. -
What are the dimensions / the baseplate?
The baseplate 160 x 120 x 60 mm. -
Can this baseplate support multiple relays at once?
It is primarily intended for single-relay mounting, but can support multiple relays with proper spacing if panel design allows. -
How heavy is the baseplate?
The weight is 0.27 kg. -
What is the operating temperature range?
The baseplate is rated for -20°C to +70°C. -
How long does the baseplate typically last under normal use?
With proper installation and maintenance, the baseplate can reliably function for many years in industrial settings without significant wear. -
Is the baseplate pre-drilled for mounting?
Yes, it comes with standard ABB mounting hole patterns for easy installation. -
Can the baseplate be painted or modified?
Altering the baseplate, such as repainting or drilling additional holes, is not recommended as it may affect durability and fit. -
Does provide warranty on this product?
We provide one year warranty.
Recommended Related モデルs
| モデル Number | 説明 | Dimensions (mm) | 重量 (kg) | Notes |
|---|---|---|---|---|
| TP856 3BSE030191R1 | Baseplate for ABB TP series relays | 440 x 290 x 38 | 3.3 | Slightly smaller footprint |
| TP858 3BSE030193R1 | Reinforced baseplate for TP relays | 460 x 310 x 45 | 4.0 | Enhanced load capacity |
| TP859 3BSE030194R1 | Extended baseplate for multiple relays | 600 x 350 x 40 | 5.0 | サポートs two relays |
| TP860 3BSE030195R1 | Compact baseplate for mini relays | 350 x 250 x 35 | 2.8 | For smaller relay models |
| TP861 3BSE030196R1 | Baseplate with integrated wiring channel | 480 x 320 x 42 | 4.2 | Facilitates cable management |
| TP862 3BSE030197R1 | Anti-vibration baseplate for TP relays | 450 x 300 x 40 | 3.7 | Vibration damping feature |
Popular ABB モデルs (Same ブランド)
| モデル Number | Product Type | Key Feature | Dimensions (mm) | 重量 (kg) |
|---|---|---|---|---|
| TP700 3BSE010020R1 | Protection Relay | Versatile protection features | 150 x 100 x 60 | 1.2 |
| TP750 3BSE010021R1 | Advanced Protection Relay | Multi-functional relay | 180 x 120 x 70 | 1.4 |
| TP760 3BSE010022R1 | Control Relay | Compact and reliable | 140 x 90 x 50 | 1.0 |
| REF615 3BSE018021R1 | Feeder Protection Relay | High-speed protection | 200 x 150 x 90 | 2.3 |
| RET670 3BSE025749R1 | Line Differential Relay | Fault detection and isolation | 220 x 160 x 100 | 2.8 |
| REM610 3BSE022573R1 | Distance Protection Relay | Comprehensive distance protection | 210 x 150 x 85 | 2.6 |
