Product Overview
The ABB TK850V007 3BSC950192R1 Bus Terminator is a high-quality termination device designed for ABB fieldbus and control networks. It ensures proper signal termination to prevent reflections and maintain reliable communication across the network.Engineered for industrial environments, the bus terminator is compact, durable, and easy to install. It is compatible with ABB automation systems and contributes to stable, high-performance data communication for control and monitoring applications.
Key Features
-
Provides proper termination for ABB fieldbus and control networks
-
Prevents signal reflections and data errors
-
Compact and durable design for industrial use
-
Easy installation on DIN rail or panel
-
Ensures reliable and stable network communication
-
Compatible with ABB automation and control systems
-
Ideal for power, process, and manufacturing automation
Technical Specifications
| Item | Specification |
|---|---|
| メーカー | ABB |
| 型番 | 3BSC950192R1 |
| Product Type | Bus Terminator |
| Dimensions | Length：0.7 m |
| 重量 | 0.2 kg |
| Termination Resistance | 120 Ω typical |
| Operating Temperature | –20 °C to +60 °C |
| Storage Temperature | –40 °C to +85 °C |
| Humidity | 0–95% RH, non-condensing |
| Mounting | DIN rail or panel mount |
| Applications | Fieldbus termination, network stabilization, control system reliability |
Industry Applications
-
Power generation and distribution
-
Process automation
-
Industrial control systems
-
Manufacturing automation
-
Oil, gas, and energy management systems
-
Real-time monitoring and diagnostics
よくある質問 (FAQ)
Q1: What is the main function / the TK850V007 bus terminator?
It ensures proper termination / ABB fieldbus networks to prevent signal reflections.
Q2: What is the typical termination resistance?
The standard termination resistance is 120 Ω.
Q3: Can it be mounted on a DIN rail?
Yes, it supports DIN rail or panel mounting.
Q4: What is the operating temperature range?
The terminator operates between –20 °C and +60 °C.
Q5: Is it suitable for industrial environments?
Yes, it is designed to withstand industrial conditions and humidity.
Q6: Does it improve network stability?
Yes, it stabilizes the communication network and ensures reliable data transmission.
Q7: Is installation complex?
No, it /fers easy and straightforward installation.
Q8: Which industries commonly use this terminator?
Power, process automation, manufacturing, and industrial control sectors.
Related ABB Modules
| モデル | 説明 |
|---|---|
| TK850V001 3BSC950186R1 | Standard Bus Terminator |
| TK850V002 3BSC950187R1 | High-speed Bus Terminator |
| TK850V003 3BSC950188R1 | DIN Rail Bus Terminator |
| TK850V004 3BSC950189R1 | Panel Mount Bus Terminator |
| TK850V005 3BSC950190R1 | Industrial Bus Terminator |
| TK850V006 3BSC950191R1 | Bus Terminator with LED indication |
Popular ABB Modules
| モデル | 説明 |
|---|---|
| TK850V007 3BSC950192R1 | Bus Terminator |
| TK850V001 3BSC950186R1 | Standard Bus Terminator |
| TK850V002 3BSC950187R1 | High-speed Bus Terminator |
| TK850V003 3BSC950188R1 | DIN Rail Bus Terminator |
| TK850V004 3BSC950189R1 | Panel Mount Bus Terminator |
| TK850V005 3BSC950190R1 | Industrial Bus Terminator |
