The ABB TK812V050 3BSC950118R2 is an advanced industrial terminal panel designed specifically for use in demanding automation and process control environments. It belongs to ABB’s renowned series / operator panels that emphasize reliability, intuitive human–machine interaction, and rugged performance. Its robust design, combined with ABB’s expertise in control systems, makes it an essential component in modern industrial setups.
This model is commonly integrated into ABB’s automation systems and DCS (Distributed Control System) architectures, enabling operators to visualize, monitor, and interact seamlessly with process data in real time. Engineered for durability and user-friendliness, the TK812V050 supports efficient plant operation and reduces system downtime through quick diagnostics and streamlined data presentation.
Product Advantages
-
Reliable Industrial Grade Construction
Built to withstand harsh industrial conditions, including temperature variations, vibration, and dust. -
Enhanced User Interface
High-resolution display and intuitive touch interface that improves operator efficiency. -
Seamless Integration
Fully compatible with ABB’s range / controllers and automation systems, reducing integration time and complexity. -
Compact Yet Versatile
Space-saving design that does not compromise on display clarity or connectivity. -
Reduced Downtime
Quick diagnostics and real-time data visualization help detect and resolve process issues promptly. -
Long Lifecycle
Designed for long-term operation with ABB’s commitment to quality and support.
Technical Specifications
| Parameter | Specification |
|---|---|
| モデル Number | TK812V050 |
| ABB 型番 | 3BSC950118R2 |
| Display Size | 12.1 inches TFT LCD |
| Display Resolution | 800 x 600 pixels |
| Touchscreen Type | Resistive |
| Cable length | 5 m |
| 重量 | 0.025 kg |
| Supply Voltage | 24 V DC |
| Power Consumption | Approx. 20 W |
| Operating Temperature | 0 °C to +50 °C |
| Storage Temperature | -20 °C to +60 °C |
| Interface Ports | Ethernet, RS232, USB Host/Device |
| Mounting | Panel Mount |
| Protection Rating | IP65 (front panel), IP20 (rear) |
Product Applications
-
Process control in chemical, petrochemical, and pharmaceutical plants.
-
Centralized monitoring stations in power generation facilities.
-
Operator interface in water and wastewater treatment plants.
-
Visualization and data logging in food and beverage manufacturing.
-
Local control panels for oil & gas upstream and midstream applications.
-
Monitoring and control stations in pulp & paper industries.
Product Advantages Explained in Detail
The TK812V050 stands out because it brings together a durable build and modern design that perfectly fits ABB’s DCS systems. Operators benefit from an easy-to-read display, even in challenging lighting conditions, and the resistive touchscreen allows usage with gloves, essential in industrial workplaces.
The product’s robust network connectivity ensures data is transferred securely and swiftly, while the versatile mounting system allows easy installation into existing cabinets or new panel builds. Moreover, ABB’s global support network ensures that maintenance and technical support are available throughout the product’s lifecycle.
よくある質問 (FAQ)
Q1: What type / display does the TK812V050 have?
A1: It features a 12.1-inch TFT LCD display with 800 x 600 pixel resolution, providing clear visualization / process data.
Q2: Can this model withstand harsh environments?
A2: Yes, the front panel is rated IP65, /fering protection against dust and low-pressure water jets, making it suitable for industrial use.
Q3: What voltage does it operate on?
A3: It operates on 24 V DC, a standard in many industrial control environments.
Q4: Is it compatible with other ABB systems?
A4: Absolutely, it is fully compatible with ABB’s AC 800M controllers and 800xA DCS systems.
Q5: How heavy is the panel?
A5: 0.025 kg, making it lightweight enough for easy panel installation.
Q6: What kind / touch technology is used?
A6: It uses a resistive touchscreen, allowing operation with gloves.
Q7: What are the typical installation methods?
A7: Panel mounting is the standard method, which ensures stability and protection.
Q8: Does it have multiple communication ports?
A8: Yes, including Ethernet, USB Host/Device, and RS232 for versatile connectivity.
Q9: What industries typically use this model?
A9: Industries such as chemical processing, oil & gas, power generation, and water treatment.
Q10: Does ABB provide global support?
A10: Yes, ABB /fers worldwide technical support and spare parts for this product line.
Recommended モデルs from the Same Series / Related モデルs
-
ABB TK812V100
-
ABB TK813V030
-
ABB TK813V100
-
ABB TK815V030
-
ABB TK815V100
-
ABB CP6202
Popular モデルs from the Same ブランド
| モデル | Display Size | Dimensions (mm) | 重量 | Voltage |
|---|---|---|---|---|
| CP6202 | 12.1″ | 315 x 240 x 65 | 2.8 kg | 24 V DC |
| CP6203 | 15″ | 380 x 290 x 70 | 4.0 kg | 24 V DC |
| CP6204 | 17″ | 420 x 320 x 75 | 5.0 kg | 24 V DC |
| CP6302 | 12.1″ | 315 x 240 x 65 | 2.9 kg | 24 V DC |
| CP6303 | 15″ | 380 x 290 x 70 | 4.1 kg | 24 V DC |
| CP600-Pro | 7″ | 203 x 150 x 50 | 1.2 kg | 24 V DC |
