The HIMA F3422 981342202 is a high-performance relay module engineered for use in HIMA safety and automation systems. Designed with reliability, accuracy, and long-term stability in mind, this module is widely used for signal switching and control in process automation and safety instrumented systems (SIS).
Built to meet the demanding standards / modern industrial applications, the F3422 delivers robust switching capabilities, high-speed response, and exceptional integration compatibility with other HIMA platforms. It is an ideal solution for industries requiring fail-safe relay operations and critical signal management.
Technical Specifications
| Parameter | Specification |
|---|---|
| モデル | HIMA F3422 981342202 |
| Module Type | Relay Output Module |
| Relay Channels | 8 isolated channels |
| Rated Voltage | 24 V DC control input |
| お問い合わせ Rating | Up to 250 V AC / 30 V DC, 5 A |
| Switching Type | SPDT (Single Pole Double Throw) |
| Response Time | < 10 ms |
| Isolation | Galvanic isolation between channels and system |
| Diagnostics | Integrated fault monitoring and status indicators |
| Mounting Type | DIN Rail Mounting |
| Operating Temperature | –20°C to +60°C |
| Dimensions | 25 x 127 x 203 mm |
| 重量 | 0.25 kg |
| Compliance | SIL 3 (IEC 61508), CE, ATEX, and TÜV certified |
Applications
-
Safety Instrumented Systems (SIS)
Ensures secure and fail-safe relay switching for critical safety functions. -
Process Control
Widely used in oil and gas, chemical, and refinery environments to manage control signals. -
Power Generation and Distribution
Ideal for relay-based switching in power plants and substation automation systems. -
Manufacturing Automation
サポートs high-speed signal switching in automated production lines for precise control. -
Emergency Shutdown Systems (ESD)
Provides fast and reliable relay actuation during critical shutdown sequences.
Advantages
-
High Reliability
Engineered to deliver stable performance even in the most demanding industrial environments. -
Fast Response
Processes relay operations with a response time / less than 10 ms, ensuring instant switching. -
Integrated Diagnostics
Includes built-in fault detection and visual status indicators for quick maintenance and troubleshooting. -
Safety Compliance
Certified to SIL 3 standards, making it suitable for high-integrity safety applications. -
Compact and Modular Design
Small footprint enables space-saving installation in modern control cabinets. -
Flexible Integration
Fully compatible with HIMA safety systems such as HIMax and HIMatrix, allowing smooth deployment. -
Durability
Robust build ensures long service life and resistance to temperature fluctuations, vibrations, and harsh conditions. -
Cost Efficiency
Reduces downtime and maintenance costs with its high reliability and low failure rate.
FAQ
Q1: What is the primary function / the F3422 module?
A1: The F3422 serves as a relay output module, handling reliable signal switching for automation and safety applications.
Q2: How many channels does the F3422 support?
A2: It provides 8 isolated relay channels, suitable for multi-point switching operations.
Q3: What is the maximum switching capacity per relay channel?
A3: Each channel supports up to 250 V AC or 30 V DC at 5 A for versatile industrial applications.
Q4: Does the F3422 provide diagnostic capabilities?
A4: Yes, it includes integrated diagnostics and LED indicators to monitor the status and detect faults in real time.
Q5: Can the F3422 module be used in SIL 3 certified systems?
A5: Absolutely. It is SIL 3 certified according to IEC 61508 standards.
Q6: What isolation features are included in the module?
A6: It features galvanic isolation between channels and system electronics for enhanced safety and signal integrity.
Q7: What is the typical response time / the relay channels?
A7: The relay channels have a response time / less than 10 ms, ensuring fast and accurate switching.
Q8: How does the module handle extreme environmental conditions?
A8: It is designed to operate reliably within a temperature range / –20°C to +60°C and withstand industrial vibrations.
Q9: What platforms is the F3422 compatible with?
A9: The module integrates seamlessly with HIMA HIMax and HIMatrix safety systems.
Q10: What industries commonly use the F3422 relay module?
A10: Industries such as oil and gas, chemical processing, power generation, and industrial automation rely on the F3422 for robust and precise relay switching.
