The ABB MCX913-1-5-1 HESG440827R51 Multifunctional Relay is a versatile protective and control device engineered for high-performance industrial applications. Designed to provide multiple protective, control, and monitoring functions in one compact 台, this relay integrates advanced microprocessor technology with ABB’s proven reliability. It is widely used in electrical distribution, motor protection, and industrial automation systems where accuracy, speed, and adaptability are critical.
This relay is capable / handling multiple signal types and provides configurable logic for diverse control tasks. With advanced fault detection, programmable settings, and communication capabilities, the MCX913-1-5-1 ensures seamless integration into modern industrial networks. Its rugged construction and robust electrical isolation make it suitable for harsh operating environments.
By combining protection, monitoring, and control functions, the ABB MCX913-1-5-1 HESG440827R51 significantly reduces system complexity and enhances operational efficiency. It serves as a key component in maintaining the reliability and safety / industrial electrical systems, /fering long-term stability and reduced maintenance costs.
製品仕様
| Parameter | Value |
|---|---|
| モデル | Multifunctional Relay |
| 型番 | MCX913-1-5-1 / HESG440827R51 |
| ブランド | ABB |
| Function | Protective, monitoring, and control relay |
| Input Voltage | 24V DC / 110–240V AC (depending on configuration) |
| Output Type | Relay outputs and digital communication |
| Control Logic | Programmable with multiple function blocks |
| Response Time | < 20 ms |
| Communication Interfaces | RS-485, Modbus, and ABB proprietary protocols |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% – 95% non-condensing |
| Mounting Type | Panel or DIN rail mount |
| Protection Features | Overcurrent, voltage fluctuation, phase failure, and overload protection |
| Dimensions | 270 x 100 x 220 mm |
| 重量 | 2.9 kg |
| Compliance | CE, UL, RoHS, IEC industrial standards |
Applications
-
Power Distribution Systems: Provides integrated protection and monitoring in electrical grids.
-
Motor Protection: Safeguards motors from overcurrent, overload, and phase imbalance.
-
Industrial Automation: Controls and monitors critical processes with high reliability.
-
Renewable Energy Systems: Enhances the safety / solar, wind, and hybrid power plants.
-
Process Industries: Ensures stable operation in chemical, oil & gas, and manufacturing plants.
-
Marine and Offshore: Delivers reliable control in harsh marine electrical environments.
Product Advantages
-
All-in-One Protection: Combines multiple relay functions in one compact device.
-
Programmable Logic: Customizable settings to meet specific application needs.
-
Fast Response Time: Quickly detects and reacts to electrical faults to prevent damage.
-
Industrial-Grade Durability: Built to withstand harsh electrical and environmental conditions.
-
Seamless Integration: サポートs standard and ABB communication protocols for easy networking.
-
Reduced System Complexity: Eliminates the need for multiple separate protective devices.
-
Long-Term Reliability: Ensures stable and safe operation over extended periods.
FAQ
-
What type / electrical isolation does the ABB MCX913-1-5-1 HESG440827R51 provide?
It incorporates galvanic isolation between control and power circuits to ensure safe and stable operation. -
Can this relay be configured for both motor protection and power distribution applications?
Yes, it supports flexible configuration for multiple roles, including motor protection and grid control. -
How does the relay handle phase imbalance detection?
It continuously monitors all phases and trips when imbalance exceeds the programmed threshold. -
Does the MCX913-1-5-1 support real-time event logging?
Yes, it stores fault and operational data to facilitate diagnostics and system analysis. -
What communication protocols can be used to integrate this relay into an automation network?
It supports Modbus, RS-485, and ABB proprietary protocols for seamless network integration. -
Can the response time be adjusted for different applications?
The trip response can be configured within defined limits to suit specific operational requirements. -
How does the relay perform under voltage fluctuation conditions?
It maintains stable operation and triggers protective functions if voltage deviates beyond safe limits. -
Is the relay capable / handling both AC and DC control inputs?
Yes, it is designed to accept both AC and DC control signals depending on configuration. -
Does the MCX913-1-5-1 allow multiple setpoints for different fault conditions?
It provides multiple programmable thresholds for overcurrent, overload, and voltage anomalies. -
How does the relay ensure reliable operation in high-electrical-noise environments?
It uses advanced filtering and shielding techniques to maintain accurate performance under EMI conditions.
Related モデルs from the Same Series
| モデル | Function | Key Feature |
|---|---|---|
| MCX913-1-5-2 HESG440827R52 | Multifunctional Relay | Extended communication options |
| MCX912-1-4-1 HESG440826R41 | Protection Relay | Compact design for panel integration |
| MCX911-1-3-1 HESG440825R31 | Control Relay | Optimized for motor control systems |
| MCX914-2-6-1 HESG440828R61 | Multifunctional Relay | Enhanced logic programmability |
| MCX910-1-2-1 HESG440824R21 | Monitoring Relay | High-accuracy current and voltage sensing |
| MCX915-2-7-1 HESG440829R71 | Multifunctional Relay | Designed for complex automation networks |
Popular ABB モデルs
| モデル | Function | Key Feature | Application Focus |
|---|---|---|---|
| LDSTA-01 3BHB007441P0001 | Inverter Control CPU Drive Board | High-performance motor control | ABB ACS/DCS drive systems |
| LT C745 A101 3BHE039905R0101 | Voltage Drive Crowbar Circuit Board | Ultra-fast overvoltage protection | Industrial drive protection |
| IPS21-24V-35AD 3BHE032593R0001 | Isolated Power Supply | Stable power source for ABB systems | Drive and automation platforms |
| KU C755 AE117 3BHB005243R0117 | Gate ユニット Power Module | Dedicated IGBT gate driver | Motor and inverter control systems |
| LT8978BV1 HIEE320639R0001 | Circuit Board | High-speed control and signal processing | ABB industrial automation |
| LXN1604-6 3BHL000986P7000 | Convert Module | Efficient power conversion for drives | ABB drive and energy systems |
