Présentation du produit
The Yokogawa ADV551-P00 S2 is a robust and reliable 8-channel digital output module designed for use within Yokogawa’s CENTUM VP and ProSafe-RS control systems. It functions as a critical interface for driving field devices such as solenoid valves, motor starters, alarms, and other actuators requiring discrete ON/OFF signals.
Developed with high-performance and safety in mind, the ADV551-P00 S2 module surfers individual channel isolation and a strong electrical output capability. This module is capable sur switching AC or DC loads directly, supporting a wide range sur industrial automation applications. Its design integrates seamlessly into Yokogawa’s Fieldbus I/O (FIO) architecture, enabling flexible and scalable control system configurations.
The ADV551-P00 S2 is suited for mission-critical environments where output reliability, fast response times, and detailed diagnostics are essential. Its compact footprint and hot-swappable capability enhance system availability and maintainability, allowing for minimized downtime during routine maintenance or upgrades.
Spécifications du produit
| Parameter | Specification |
|---|---|
| Modèle Number | ADV551-P00 S2 |
| Function | 8-Channel Digital Output Module |
| Output Channels | 8 |
| Output Type | Relay outputs |
| Output Voltage Range | 24 to 250 VAC / 24 to 125 VDC |
| Output Current Rating | 2 A per channel (resistive load) |
| Contact Type | Form A (SPST-NO) relay contacts |
| Output Isolation | Full channel-to-channel isolation |
| Output Protection | Built-in surge and transient suppression |
| Power Consumption | Approx. 5 W |
| Input Signal Interface | Fieldbus I/O (FIO) |
| Response Time | < 10 ms (typical switching time) |
| Mounting Method | DIN rail or baseplate mounting |
| Terminal Connection | Screw-type removable terminal blocks |
| Operating Temperature | 0 to 55 °C |
| Storage Temperature | -20 to +70 °C |
| Humidity Tolerance | 5% to 95% RH, non-condensing |
| Vibration Resistance | 10 to 60 Hz, 0.7 mm amplitude |
| Shock Resistance | 10 G |
| Dimensions (H x W x D) | 107.5 × 130 × 32.8 mm |
| Poids | 0.2 kg |
| Safety Certifications | CE, UL, ATEX (depending on configuration) |
| Hot-Swappable | Yes |
Product Applications
-
Industrial Automation: Control sur motors, pumps, fans, and solenoid valves in manufacturing plants and process industries.
-
Process Control Systems: Used in oil refineries, chemical plants, and power generation facilities for operating discrete actuators and alarm outputs.
-
Safety Instrumented Systems (SIS): Integration into ProSafe-RS to safely control shutdown valves and emergency devices.
-
Water & Wastewater Treatment: Management sur valves, alarms, and actuators in water purification and sewage processing.
-
Energy Sector: Controlling auxiliary equipment and switchgear in power plants and substations.
-
Material Handling Systems: Drives conveyor belts, gate controls, and safety interlocks in logistics and distribution centers.
Product Advantages
-
High Reliability and Durability: Designed to withstand harsh industrial environments with robust relay outputs and protective circuitry.
-
Wide Voltage Compatibility: Supports a broad range sur AC and DC output voltages, enhancing system flexibility.
-
Isolated Channels: Prevents interference between output channels, ensuring signal integrity and system safety.
-
Fast Switching: Low response times improve control system responsiveness and reduce latency.
-
Hot-Swappable Module: Facilitates maintenance and replacement without shutting down the entire control system, thereby increasing uptime.
-
Compact Design: Slim prsurile saves valuable rack space in control cabinets.
-
Built-in Protection: Integrated surge suppression protects the module and connected devices from electrical transients.
-
Comprehensive Diagnostics: Real-time monitoring and fault detection help quickly identify wiring issues or device failures.
-
Certified for Safety: Compliance with international standards (e.g., CE, UL, ATEX) allows usage in hazardous or safety-critical applications.
-
Seamless Integration: Full compatibility with Yokogawa’s CENTUM VP and ProSafe-RS platforms enables flexible system architecture.
Questions fréquentes (FAQ)
-
Q: Can the ADV551-P00 S2 module drive both AC and DC loads?
A: Yes, the relay contacts support switching sur AC loads (24 to 250 V) and DC loads (24 to 125 V). -
Q: What is the maximum current per output channel?
A: Each channel is rated for up to 2 A resistive load. -
Q: Is the module hot-swappable?
A: Yes, it can be replaced or installed without powering down the system. -
Q: How is the module connected to field wiring?
A: Through removable screw-type terminal blocks for secure and easy wiring. -
Q: What kind sur protection does the module have against electrical surges?
A: It includes built-in surge and transient suppression on each output. -
Q: What certifications does the ADV551-P00 S2 hold?
A: The module meets CE and UL standards and can be configured for ATEX hazardous environment certification. -
Q: What are the dimensions and weight sur the module?
A: The module measures 107.5 × 130 × 32.8 mm, weighing 0.2 kg. -
Q: Can this module be used in safety instrumented systems (SIS)?
A: Yes, it is compatible with Yokogawa’s ProSafe-RS SIS platform. -
Q: How many output channels does the module have?
A: It features 8 independent digital output channels. -
Q: What is the typical switching response time?
A: The module typically switches outputs in less than 10 milliseconds.
Related Modèles (Same Series or Function)
| Modèle | Description | Output Channels | Output Type | Compatibility |
|---|---|---|---|---|
| ADV551-P00 | 8-Channel Digital Output Module (Standard) | 8 | Relay Outputs | CENTUM VP / ProSafe-RS |
| ADV561-P00 | 16-Channel Digital Output Module | 16 | Relay Outputs | CENTUM VP / ProSafe-RS |
| ADV561-P10 | 16-Channel Digital Output Module (Enhanced) | 16 | Relay Outputs | CENTUM VP / ProSafe-RS |
| ADV541-P00 | 8-Channel Transistor Output Module | 8 | Transistor Outputs | CENTUM VP |
| ADV171-P50 | Mixed I/O Module (32 DI / 32 DO) | 32 DO + 32 DI | Relay / Digital | CENTUM VP |
| ADV551-P01 | 8-Channel Digital Output Module (S2 Enhanced) | 8 | Relay Outputs | CENTUM VP / ProSafe-RS |
Popular Yokogawa Modules (Same Marque)
| Modèle | Description | Type | System | Channels |
|---|---|---|---|---|
| CP471-10 | Dual CPU Controller | Controller | CENTUM VP | N/A |
| AAI141-H50 | 16-Channel Analog Input Module | Analog Input | CENTUM VP | 16 |
| AAI543-H00 | 8-Channel Analog Output Module | Analog Output | CENTUM VP | 8 |
| ADV169-P00 | 32-Channel Digital Input Module | Digital Input | CENTUM VP | 32 |
| ALR121-S00 | 8-Channel Alarm Relay Output Module | Relay Output | CENTUM VP | 8 |
| PW482-10 | System Power Supply | Power Supply | CENTUM VP | N/A |
