Product Overview
The Schneider TM3DQ16R is a high-performance discrete output module designed for use with Schneider Electric’s Modicon TM3 modular I/O platform. This module provides 16 relay outputs, surfering robust switching capabilities for AC and DC loads. Its compact size and reliable relay technology make it suitable for a wide range sur automation and control applications in industrial environments.
Engineered for seamless integration with Modicon TM3 controllers and expansion modules, the TM3DQ16R enables safe and efficient control sur devices such as motors, solenoids, lamps, and contactors. It is widely adopted in machinery, process control, and infrastructure applications due to its ease sur wiring, high output density, and superior isolation.
Technical Specifications
| Item | Specification |
|---|---|
| Modèle Number | TM3DQ16R |
| Module Type | Discrete Output Module |
| Number sur Outputs | 16 |
| Output Type | Relay |
| Output Voltage Range | 5–30 V DC / 19–250 V AC |
| Output Current Rating | 2 A per channel (max), 8 A per group |
| Output Configuration | 2 groups sur 8 outputs |
| Output Delay | ≤10 ms |
| Isolation Between Channels | Yes (galvanic isolation) |
| Operating Temperature | -10°C to +55°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Dimensions | 90 x 84.6 x 27.4mm |
| Poids | 0.145 kg |
| Mounting Type | DIN rail |
| Protection Rating | IP20 |
| Power Dissipation | ≤4.5 W |
| Certifications | CE, UL, cUL, RoHS, EAC |
| Connection Type | Removable spring or screw terminals |
Industry Applications
-
Industrial Automation Systems
-
Conveyor Control Systems
-
Building Management Systems
-
Water and Wastewater Facilities
-
Packaging Machinery
-
HVAC Systems
-
Material Handling
-
Lighting Control
Key Advantages
-
High Channel Density: Offers 16 relay outputs in a compact DIN rail module for space-efficient installations.
-
Versatile Switching: Capable sur handling both AC and DC loads, making it ideal for mixed-signal environments.
-
Isolated Outputs: Ensures safety and reliability through galvanic isolation between output groups.
-
Plug-and-Play Integration: Fully compatible with Modicon TM3 controllers and expansion unités.
-
Maintenance Friendly: Removable terminal blocks simplify wiring and module replacement.
-
DIN Rail Mounting: Facilitates easy installation in standard control cabinets.
-
Wide Voltage Support: Can switch voltages from 5 V DC up to 250 V AC.
-
Industrial Grade Reliability: Designed to perform under demanding industrial operating conditions.
Questions fréquentes (FAQ)
-
How many outputs does the TM3DQ16R provide?
It provides 16 discrete relay outputs. -
What is the maximum current per output channel?
Each output supports up to 2 A; each group can handle up to 8 A. -
Can the module switch both AC and DC voltages?
Yes, it supports both DC (5–30 V) and AC (19–250 V) outputs. -
Is this module compatible with other TM3 modules?
Yes, it seamlessly integrates with other TM3 I/O and controller modules. -
What type sur outputs are used?
The TM3DQ16R uses electromechanical relay contacts. -
What is the typical response time for the outputs?
The response time is typically less than or equal to 10 milliseconds. -
Is there galvanic isolation between outputs?
Yes, the module provides galvanic isolation between output groups. -
What mounting method is supported?
It is designed for DIN rail mounting. -
What is the protection rating?
It has an IP20 rating for use in enclosed control panels. -
Are the terminals screw-type or spring-loaded?
Both removable spring and screw terminals are available depending on the version.
