Présentation du produit
The Schneider Electric 140DDO36400C is a high-density Discrete Output Module designed for use in Modicon Quantum PLC systems, surfering reliable digital output performance for complex industrial automation tasks. This module features 64 channels sur 24 VDC positive logic sourcing outputs, making it ideal for large-scale control applications where space and performance efficiency are crucial.
Built to deliver fast response times, superior noise immunitéy, and robust electrical protection, the 140DDO36400C is a go-to solution for output-intensive systems such as manufacturing lines, process industries, utilities, and infrastructure projects. With built-in diagnostics and fault monitoring capabilities, it ensures that operational safety and system integrity are always maintained.
This module supports hot-swapping on Quantum backplanes, enhancing system uptime during maintenance or module replacement. Designed with Schneider’s global quality standards, it helps streamline automation, reduce panel space requirements, and improve system scalability.
Spécifications du produit
| Parameter | Specification |
|---|---|
| Modèle Number | 140DDO36400C |
| Fabricant | Schneider Electric |
| Product Type | Discrete Output Module |
| Series | Modicon Quantum |
| Number sur Outputs | 64 |
| Output Type | Sourcing (positive logic) |
| Nominal Output Voltage | 24 VDC |
| Voltage Range | 19.2 – 30 VDC |
| Output Current per Channel | 0.1 A |
| Total Module Current | Max 6.4 A (across 64 outputs) |
| Isolation | Optical isolation between outputs and backplane |
| Output Delay | < 1 ms |
| Protection | Overload and short-circuit protection |
| Diagnostics | Individual channel status LEDs, module fault detection |
| Backplane Current Draw | 390 mA |
| Mounting | Rack-mounted (Quantum backplane) |
| Cable Length | 0.2 meters |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity Tolerance | 5% to 95% RH (non-condensing) |
| Compliance Certifications | CE, UL, CSA, RoHS |
| Dimensions (W x H x D) | 103.9 × 40.3 × 250 mm |
| Poids | 0.45 kg |
Product Applications
The 140DDO36400C module is ideal for high-volume discrete output control in mission-critical automation systems. Key application areas include:
-
Automated Assembly Lines: Controls large arrays sur actuators, sensors, and control devices in synchronized manufacturing processes.
-
Packaging & Sorting Systems: Interfaces with solenoids, diverters, and reject gates in high-speed machinery.
-
Water & Wastewater Management: Operates pump relays, gate valves, and alarm systems in treatment facilities.
-
Electrical Substations & Utilities: Manages breaker controls, alarms, and relay interlocks in SCADA environments.
-
Transportation & Tunnel Automation: Interfaces with lighting systems, ventilation controls, and emergency triggers.
-
Food & Beverage Industry: Activates step-by-step process controls, cleaning-in-place (CIP) systems, and mechanical devices.
Product Advantages
-
High-Density Output: Offers 64 discrete outputs in a single module, saving valuable rack space and minimizing installation complexity.
-
Positive Logic Sourcing: Compatible with most industrial output devices and field wiring practices.
-
Robust Electrical Protection: Built-in short-circuit and overload safeguards ensure operational safety and reduce hardware failures.
-
Fast Response Time: Less than 1 ms switching speed for real-time control in dynamic applications.
-
Comprehensive Diagnostics: Real-time LED status for each channel simplifies maintenance and error detection.
-
Quantum System Integration: Seamlessly integrates with the Modicon Quantum platform for large-scale automation solutions.
-
Modular Flexibility: Enables easy expansion and configuration without rewiring or major panel changes.
-
Hot-Swappable: Allows module replacement without halting the system, reducing downtime and increasing productivity.
-
Global Compliance: Meets international certifications and industrial safety standards.
-
Compact Form Factor: Enables high-volume output handling without expanding cabinet size.
Questions fréquentes (FAQ)
-
Is the 140DDO36400C compatible with all Quantum PLC racks?
Yes, it is fully compatible with standard Modicon Quantum racks and supports hot-swapping. -
What type sur output signal does the module generate?
It delivers 24 VDC sourcing (positive logic) discrete output signals. -
How many outputs can be energized simultaneously?
All 64 channels can be energized, provided the total current does not exceed 6.4 A. -
Does this module support output diagnostics?
Yes, each channel has an LED indicator, and the module monitors output faults. -
Is there isolation between outputs and backplane?
Yes, optical isolation protects the backplane and CPU from output faults. -
Can this module handle inductive loads like relays or solenoids?
Yes, but external protection (flyback diodes) is recommended for inductive devices. -
Is the module suitable for fast control loops?
Yes, with a switching delay under 1 ms, it is ideal for fast discrete control. -
What is the maximum current per output channel?
Each channel can source up to 0.1 A continuously. -
Can the module be used in redundant I/O configurations?
Yes, it supports use in Quantum Hot Standby (HSBY) systems with redundancy. -
Does it require ssurtware configuration for output types?
No, outputs are fixed as sourcing 24 VDC. No additional setup is required.
