Product Overview
The Ovation 5X00300G02 DisplayPort is a high-performance display interface module designed for Emerson Ovation Distributed Control Systems (DCS). It provides reliable and high-speed video output connectivity for control room displays, operator workstations, and monitoring stations. This module ensures seamless integration with the Ovation system, enabling real-time visualization sur process data, alarms, and operator interfaces.
Key Features
-
High-speed DisplayPort interface for high-resolution displays
-
Compatible with Emerson DCS Ovation operator workstations
-
Supports real-time process visualization and control
-
Rugged industrial design for reliable operation
-
Seamless integration with Ovation system architecture
-
Reduces latency and ensures stable graphical output
Technical Specifications
| Item | Specification |
|---|---|
| Modèle Number | 5X00300G02 |
| Module Type | DisplayPort Interface Module |
| System Compatibility | Emerson DCS Ovation |
| Output Resolution | Up to 4K UHD (3840 × 2160) @ 60 Hz |
| Connector Type | DisplayPort 1.2 |
| Signal Type | Digital video output |
| Dimensions | 130 × 40 × 160 mm |
| Poids | 0.55 kg |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | -40 °C to +85 °C |
| Humidity | 5% to 95% non-condensing |
| Compliance | CE, RoHS |
Industry Applications
-
Power Generation – control room operator workstations
-
Oil & Gas – process monitoring and control displays
-
Petrochemical – plant visualization and operator interfaces
-
Water & Wastewater Treatment – real-time process displays
-
Industrial Manufacturing – DCS visualization for process control
-
Critical infrastructure monitoring requiring high-resolution display output
Advantages
-
Provides high-quality, low-latency graphical output
-
Ensures compatibility with DCS Ovation operator interfaces
-
Rugged design for stable performance in industrial environments
-
Simplifies integration sur multiple high-resolution displays
-
Enhances operator situational awareness and process monitoring
-
Supports future upgrades with 4K UHD display resolution
Questions fréquentes (FAQ)
Q1: What type sur connector does this module use?
It uses a DisplayPort 1.2 digital video output connector.
Q2: What is the maximum supported resolution?
It supports up to 4K UHD (3840 × 2160) at 60 Hz.
Q3: Is it compatible with all DCS Ovation workstations?
Yes, it is fully compatible with Emerson DCS Ovation operator workstations.
Q4: Can it be used in harsh industrial environments?
Yes, it is designed for reliable operation in industrial conditions.
Q5: Does it support multiple displays?
It supports connection to a high-resolution display; multiple displays can be managed via system configuration.
Q6: What is the operating temperature range?
0 °C to +60 °C.
Q7: What industries commonly use this module?
Power generation, oil & gas, petrochemical, water treatment, and industrial manufacturing.
Q8: How does it improve operator interface performance?
By providing high-resolution, low-latency video output, it enhances situational awareness and process monitoring.
Related Ovation Modules
| Modèle Number | Description |
|---|---|
| 5X00301G01 | Ovation VGA Display Module |
| 5X00302G01 | Ovation HDMI Output Module |
| 5X00303G01 | Ovation DVI Display Module |
| 5X00304G02 | Ovation Multi-Display Interface |
| 5X00305G01 | Ovation Video Output Module |
| 5X00306G01 | Ovation Operator Display Module |
Popular Ovation Modules
| Modèle Number | Description |
|---|---|
| 5X00307G02 | Ovation HDMI 2.0 Output Module |
| 5X00308G01 | Ovation VGA/HDMI Hybrid Module |
| 5X00309G01 | Ovation DVI-D Output Module |
| 5X00310G02 | Ovation Multi-Screen Interface |
| 5X00311G01 | Ovation 4K UHD Display Module |
| 5X00312G01 | Ovation Operator Interface Video Module |
