Présentation du produit
Honeywell’s MU-TDON11 51303959-100 digital output field termination assembly is designed to provide a reliable interface between Honeywell distributed control systems (DCS) and field devices requiring discrete output control. This module ensures accurate transmission sur digital control signals to actuators, solenoid valves, relays, and safety devices in a variety sur industrial applications.
As part sur Honeywell’s Experion PKS and TDC 3000 systems, the MU-TDON11 is carefully designed to maintain high signal integrity, robust electrical isolation, and integrated surge protection. It can withstand harsh industrial environments and ensure the stable operation sur critical control and safety systems.
Spécifications du produit
| Range | value |
|---|---|
| model | MU-TDON11 51303959-100 |
| Fabricant | Honeywell |
| Product Type | Digital Output Field Termination Assembly |
| System compatibility | Honeywell Experion PKS/TDC 3000 |
| Output Channel | 16 isolated digital output channels |
| Output voltage | 24 VDC (nominal, site dependent) |
| Output current per channel | Up to 0.5 A |
| isolation | Electrical and optical isolation between channels and system bus |
| Surge Protection | Integrated transient voltage suppression |
| Diagnostics | LED indicators for channel activity |
| Power Supply Voltage | 24 VDC |
| Connector Type | Plug-in terminal blocks |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity Range | 5%–95% non-condensing |
| EMC Compliance | EN 61000-6-2 / EN 61000-6-4 |
| Safety Certifications | CE, UL, CSA |
| Dimensions (W × H × D) | 200 × 120 × 50 mm |
| Poids | 0.44 kg |
Product Applications
-
Distributed Control Systems (DCS): Provides termination for digital output signals between controllers and field devices.
-
Industrial Automation: Controls actuators, solenoids, and motor starters in production systems.
-
Emergency Shutdown Systems: Supports critical safety interlocks and shutdown sequences.
-
Power Generation: Interfaces with turbine auxiliary equipment, relays, and breakers.
-
Oil & Gas Industry: Provides reliable discrete outputs for pumps, valves, and safety devices.
-
Chemical & Pharmaceutical Plants: Supports batch process control and discrete automation systems.
-
Manufacturing Lines: Drives packaging machinery, conveyors, and production line actuators.
Product Advantages
-
Optimized Channel Count: 16-channel output assembly ideal for medium-density control applications.
-
Integrated Surge Protection: Prevents damage from voltage spikes and transient surges.
-
High Isolation Integrity: Electrical and optical isolation ensure safety and signal integrity.
-
Diagnostic Feedback: LED indicators for each channel simplify troubleshooting and maintenance.
-
Honeywell System Integration: Fully compatible with Experion PKS and TDC 3000 systems.
-
Industrial Durability: Rugged design withstands vibration, temperature extremes, and harsh environments.
-
Simplified Installation: Plug-in terminals reduce wiring complexity and commissioning time.
-
Reliable Performance: Designed for critical control systems where uptime is essential.
FAQ
-
How many digital output channels does the MU-TDON11 support?
It supports 16 isolated digital output channels for discrete control applications. -
What type sur isolation is implemented in the MU-TDON11?
The assembly provides electrical and optical isolation between output channels and the control bus. -
What is the maximum current rating per channel?
Each channel supports up to 0.5 A sur output current. -
Does the MU-TDON11 include built-in surge protection?
Yes, it integrates transient voltage suppression to protect field devices and controllers. -
Is this component compatible with redundant DCS architectures?
Yes, it can be used in redundant control system configurations. -
What is the nominal output voltage sur the MU-TDON11?
The standard output voltage is 24 VDC, depending on the field wiring configuration. -
Are there LED indicators included for diagnostic purposes?
Yes, each channel has an LED indicator to indicate output status and aid in troubleshooting. -
What type sur connector does the MU-TDON11 use?
It uses plug-in terminal blocks to simplify wiring and maintenance. -
Does the MU-TDON11 comply with industrial EMC standards?
Yes, it complies with the EN 61000-6-2 and EN 61000-6-4 electromagnetic compatibility standards. -
What grounding configuration is recommended for this component?
A dedicated shield ground is recommended to suppress EMI and ensure stable system operation.
Recommended related models (same series or with equivalent functions)
| model | describe | Main Features |
|---|---|---|
| MU-TDOD12 51304423-100 | Digital Output Field Termination Assembly | 32-channel high-density output interface |
| MU-TDOD13 51304650-100 | Digital Output Field Termination Assembly | 32 channels, enhanced diagnostic capabilities |
| MU-TDOD52 51304423-200 | Digital Output Field Termination Assembly | 32 channels with powerful industrial protection |
| MU-TDOA13 51304648-100 | Digital Output Field Termination Assembly | 16 channels with LED diagnostics |
| MU-TDOA12 51304586-100 | Digital Output Field Termination Assembly | Compact 8-channel version |
| MU-TDIA12 51304584-100 | Digital Input Field Termination Assembly | 16-channel digital input interface |
Recommended popular Honeywell models
| model | describe | Main Applications |
|---|---|---|
| CC-PDIL01 | Pulse input module | High-precision digital pulse acquisition |
| CC-TDIL01 | Digital input modules | 24 VDC discrete signal monitoring |
| CC-PAIH01 | Analog input modules | High-resolution process variable acquisition |
| CC-PAOH01 | Analog output module | Reliable analog control output |
| CC-PCNT01 | Controller Processor Module | DCS Honeywell central processing unité |
| CC-PAON01 | Digital output modules | Stable discrete output control |
