Présentation du produit
The Ovation 1X00024H03 Power Supply Module is a high-reliability power solution engineered to provide stable and efficient power for Emerson Ovation Distributed Control Systems (DCS). Designed for critical industrial applications, this module converts incoming AC or DC power into precise, regulated DC voltages required by Ovation controllers, I/O modules, and communication hardware. Its rugged construction and advanced protective features ensure continuous operation even in demanding environments. With intelligent monitoring and fault-tolerant design, the 1X00024H03 supports uninterrupted process automation and helps maintain system availability in power-sensitive applications such as power generation, water treatment, petrochemical processing, and other industrial plants.
Spécifications du produit
| Parameter | Description |
|---|---|
| Modèle Number | 1X00024H03 |
| Product Type | Power Supply Module |
| Input Voltage Range | 85–264 VAC or 110–300 VDC |
| Output Voltage | Regulated 24 VDC |
| Output Current | Up to 10 A continuous |
| Output Power | 240 W nominal |
| Efficiency | ≥90% typical |
| Isolation Voltage | 3 kV between input and output |
| Protection Features | Overload, overvoltage, short-circuit, and thermal |
| Operating Temperature | −20 °C to +70 °C |
| Storage Temperature | −40 °C to +85 °C |
| Cooling Method | Natural convection, fanless design |
| Mounting | Ovation system backplane or standard DIN-rail |
| Dimensions (L × W × H) | 250 x 200 x 120 mm |
| Poids | 2.5 kg |
Applications
-
Power Generation Plants: Ensures reliable power for Ovation controllers and field I/O during continuous operation.
-
Water & Wastewater Facilities: Provides uninterrupted power for SCADA and control networks.
-
Petrochemical and Refining: Supports automation systems exposed to harsh industrial environments.
-
Manufacturing Automation: Maintains steady power to PLCs, HMIs, and network interfaces.
-
Redundant Power Configurations: Works in parallel with other modules for fail-safe power delivery.
-
Remote Process Stations: Ideal for critical systems in isolated locations requiring high reliability.
Advantages
-
High Efficiency: ≥90% conversion efficiency reduces energy loss and heat generation.
-
Wide Input Range: Operates seamlessly with both AC and DC input sources.
-
Advanced Protection: Includes overvoltage, overload, and short-circuit safeguards to prevent system damage.
-
Compact Design: Space-saving footprint allows easy integration into Ovation racks or panels.
-
Redundancy Support: Can be configured in parallel for N+1 redundancy, ensuring continuous operation.
-
Low Maintenance: Fanless cooling reduces mechanical wear and maintenance requirements.
-
Industrial Durability: Engineered for extreme temperatures and high electromagnetic interference environments.
FAQ
-
What is the input voltage range supported by the 1X00024H03?
It supports 85–264 VAC or 110–300 VDC input. -
What is the regulated DC output voltage?
The module provides a stable 24 VDC output. -
How much output current can it deliver?
It can supply up to 10 A continuous current. -
Does it support redundant operation?
Yes, it can be paralleled with another module for N+1 redundancy. -
What type sur protection is integrated in the module?
Built-in protection includes overload, overvoltage, short-circuit, and thermal safeguards. -
Is galvanic isolation provided between input and output?
Yes, it provides 3 kV isolation for enhanced safety. -
What is the typical efficiency rating?
Efficiency is typically 90% or higher under nominal loads. -
How is cooling achieved without a fan?
The design uses natural convection cooling for silent and maintenance-free operation. -
Can the module operate in harsh environments?
Yes, it is rated for −20 °C to +70 °C operating conditions and high EMI areas. -
Does it integrate directly with Ovation system backplanes?
Yes, it is designed for seamless installation in DCS Ovation racks.
