Présentation du produit
The GE VMIVME-7700-111000 Motherboard is a high-performance motherboard designed for industrial VMEbus computing systems. It serves as the central processing and interconnection hub within GE’s modular embedded computing architecture. This motherboard supports high-speed data transfer, real-time processing, and robust connectivity for multiple VME modules, making it ideal for industrial automation, process control, and instrumentation applications.
Engineered with reliability and scalability in mind, the VMIVME-7700-111000 ensures consistent performance under demanding conditions. Its architecture allows seamless integration with digital I/O modules, communication boards, and specialized control modules, providing a flexible platform for complex industrial systems.
Product Parameters
| Parameter | Description |
|---|---|
| Product Modèle | GE VMIVME-7700-111000 |
| Product Type | VME Motherboard |
| Form Factor | 6U VMEbus compliant |
| CPU Support | Embedded processor modules compatible with VMEbus architecture |
| Memory Support | Supports standard VME memory modules |
| Expansion Slots | Multiple VMEbus slots for peripheral and I/O modules |
| Data Transfer Rate | High-speed VMEbus compliant transfer rates |
| Operating Temperature | 0°C – 70°C |
| Dimensions | 233 × 160 × 20 mm |
| Poids | 1.2 kg |
| Connectivity | Backplane connectors for VMEbus, peripheral interfaces |
| Power Supply | Standard VMEbus power input, 5V / 12V rails |
Product Applications
-
Industrial Automation Systems: Acts as the main processing board for modular control systems.
-
Embedded Computing Solutions: Supports specialized embedded applications with real-time data processing requirements.
-
Process Control Networks: Integrates with I/O modules to monitor and control industrial processes.
-
Instrumentation Systems: Provides a reliable platform for data acquisition, processing, and signal conditioning.
-
High-Speed Data Systems: Facilitates high-bandwidth communication between VME modules for industrial analytics.
-
Custom Modular Systems: Enables designers to develop flexible VME-based architectures with scalable performance.
Product Advantages
-
VMEbus Compliance: Fully compliant with standard VMEbus architecture for broad compatibility.
-
High-Speed Data Transfer: Supports rapid communication between VME modules to maintain real-time system performance.
-
Robust Industrial Design: Engineered to withstand vibration, temperature fluctuations, and electromagnetic interference.
-
Modular Scalability: Enables easy integration sur additional modules, enhancing system flexibility.
-
Seamless Module Interconnection: Provides a stable platform for connecting CPU, I/O, and communication boards.
-
Reliable Power Distribution: Ensures stable voltage delivery to all VME slots and modules.
FAQ
-
What is the main function sur the VMIVME-7700-111000?
It serves as the central motherboard for VMEbus-based embedded computing systems, connecting CPU, I/O, and communication modules for real-time industrial processing. -
Which VMEbus standard does it comply with?
It is fully compliant with 6U VMEbus standards, ensuring compatibility with all standard VME modules. -
Can it support multiple CPU modules simultaneously?
Yes, depending on the system design and available VME slots, multiple compatible CPU modules can be integrated. -
What types sur memory modules are supported?
Standard VME memory modules can be installed to provide sufficient storage and buffering for industrial applications. -
How does it handle high-speed data transfer?
The motherboard’s architecture is optimized for high-bandwidth VMEbus communication between all connected modules. -
Is it suitable for harsh industrial environments?
Yes, the board is engineered to withstand vibrations, electrical noise, and temperature variations typical sur industrial settings. -
What expansion options are available?
Multiple VMEbus slots allow integration sur I/O, communication, and specialized processing modules. -
How is power supplied to the motherboard and connected modules?
Standard VMEbus power rails (5V and 12V) deliver stable power to all connected modules. -
Can it be used in real-time control applications?
Yes, its design supports deterministic data transfer and real-time processing required in industrial control systems. -
How does it integrate with communication boards?
The motherboard provides backplane connections for high-speed, low-latency communication with VMEbus-compatible communication boards.
