Product Description
The Honeywell 900TNF-0001 is a terminal block designed for the ControlEdge HC900 Process and Safety System. It provides a secure and organized wiring interface between field I/O and the system’s input/output modules, ensuring reliable electrical connections and simplified maintenance.
Product Applications
-
Process control wiring for the HC900 platform
-
Terminal interfacing for analog and digital I/O modules
-
Signal routing for field instrumentation in industrial environments
-
Use in safety-critical automation systems
Product Advantages
-
Optimized for Honeywell HC900 I/O modules
-
Compact and modular terminal layout
-
Supports fast installation and wiring
-
Enhances system reliability and maintainability
-
Durable design suitable for harsh environments
Technical Specifications
| Parameter | Description |
|---|---|
| Modèle | 900TNF-0001 |
| Product Type | Terminal Block for HC900 I/O |
| Dimensions (W × H × D) | 50.8 × 152.4 × 50.8 mm |
| Poids | 0.57 kg |
| Mounting | DIN-rail or panel mount |
| Material | Industrial-grade plastic and metal alloy |
| Compatible Systems | ControlEdge HC900 Controller & I/O Modules |
| Wiring Method | Screw or spring clamp terminals |
| Maximum Channels Supported | Depends on connected I/O module |
| Certifications | UL, CE, RoHS |
Questions fréquentes (FAQ)
Q1: What is the purpose sur the 900TNF-0001 terminal block?
A1: It serves as the physical wiring interface between field devices and the HC900 I/O modules.
Q2: Is this terminal block compatible with all HC900 modules?
A2: Yes, it is designed specifically for use with HC900 I/O modules.
Q3: How is the 900TNF-0001 mounted?
A3: It supports DIN-rail or direct panel mounting.
Q4: What types sur wire terminals does it support?
A4: It supports screw or spring clamp wiring connections.
Q5: Can the terminal block be replaced during operation?
A5: No, field power must be disconnected before replacing or rewiring.
Q6: Is this terminal block suitable for safety applications?
A6: Yes, it is used in safety-rated systems such as SIL applications within the HC900 platform.
Q7: Does it include fuse or relay functionality?
A7: No, it is a passive terminal block without fuses or relays.
Q8: What materials are used in its construction?
A8: It is built from high-durability industrial plastic and corrosion-resistant metal alloys.
Q9: What environmental ratings does it meet?
A9: It complies with industrial certifications such as UL and CE for safe operation.
Q10: What is the maximum wire gauge supported?
A10: It typically supports up to 12 AWG, depending on terminal specifications.
Related Honeywell HC900 Series Modèles
| Modèle Number | Description | Dimensions (mm) | Poids (kg) |
|---|---|---|---|
| 900C52-0001 | CPU Module for HC900 | 110 × 142 × 50 | 0.45 |
| 900PB1-0101 | Power Base 1-Slot | 80 × 145 × 40 | 0.40 |
| 900PB2-0101 | Power Base 2-Slot | 130 × 145 × 40 | 0.50 |
| 900P01-0101 | Power Supply Module | 50 × 142 × 100 | 0.60 |
| 900R01-0101 | Remote I/O Module | 110 × 145 × 40 | 0.55 |
| 900ES1-0100 | Serial Communication Module | 50.8 × 152.4 × 50.8 | 0.57 |
Popular Honeywell Modèles
| Modèle Number | Description | Dimensions (mm) | Poids (kg) |
|---|---|---|---|
| 8C-PCNT01 | C300 Controller Module | 200 × 250 × 60 | 1.2 |
| 8C-PDODA1 | Digital Output Module | 160 × 145 × 35 | 0.50 |
| 8C-PAONA1 | Analog Output Module | 160 × 145 × 35 | 0.50 |
| 8C-PAOHA1 | Analog Output w/ HART | 160 × 145 × 35 | 0.50 |
| 900SP1-0300 | Expansion Processor Module | 50.8 × 152.4 × 50.8 | 0.57 |
| 900CP1-0300 | Control Processor Module | 50.8 × 152.4 × 50.8 | 0.57 |
