Bently Nevada 3500/15-02-02-01 Présentation du produit
The Bently Nevada 3500/15-02-02-01 is a high-performance Seismic Transmitter module designed for continuous monitoring and protection sur critical machinery in industrial applications. It is part sur the renowned Bently Nevada 3500 Series, a modular monitoring system widely used in industries such as oil & gas, power generation, and chemical processing. This module specifically converts seismic vibration signals (e.g., from accelerometers) into standardized outputs for machinery health analysis, ensuring early fault detection and preventing catastrophic failures.
Product Parameters
| Parameter | Specification |
|---|---|
| Input Type | Accepts signals from seismic accelerometers (e.g., 100 mV/g) |
| Output Signal | 4–20 mA, scaled to user-defined vibration levels |
| Frequency Range | 2 Hz to 10 kHz (±3 dB) |
| Power Supply | +24 VDC (±10%), sourced from 3500 rack |
| Operating Temp. | -30°C to +70°C (-22°F to +158°F) |
| Dimensions | 120.7 x 50.8 x 251.5mm |
| Poids | 1.39 kg |
| Housing Material | Anodized aluminum for EMI/RFI shielding |
| Compliance | ATEX, IECEx, UL, CE |
Product Applications
The 3500/15-02-02-01 is ideal for:
-
Gas Turbines & Compressors: Monitors blade passing frequencies and casing vibrations.
-
Power Plants: Detects abnormal vibrations in turbines, pumps, and fans.
-
Offshore Platforms: Ensures structural integrity under harsh environmental conditions.
-
Mining & Heavy Machinery: Tracks seismic activity in crushers and conveyors.
Product Advantages
-
High Accuracy: Linear output with minimal phase distortion for precise diagnostics.
-
Modular Design: Hot-swappable in 3500 racks, reducing downtime.
-
Robust Construction: EMI-resistant and suitable for hazardous areas (ATEX certified).
-
Scalable Integration: Compatible with Bently Nevada’s System 1® ssurtware for advanced analytics.
-
Long-Term Reliability: Designed for 24/7 operation in extreme conditions.
Questions fréquentes (FAQ)
-
Q: What is the difference between 3500/15 and 3500/25 modules?
A: The 3500/15 is for seismic transmitters, while the 3500/25 is a general-purpose vibration monitor. -
Q: Can this module be used with third-party accelerometers?
A: Yes, if the sensor output matches the input range (e.g., 100 mV/g). -
Q: How surten should calibration be performed?
A: Recommended annually or per OEM guidelines. -
Q: Is the module compatible with older 3300 series racks?
A: No, it requires a 3500 series rack. -
Q: What is the typical response time for alarm triggers?
A: <50 ms for critical alerts. -
Q: Can it monitor both velocity and acceleration?
A: No, it is designed for acceleration inputs only. -
Q: What certifications does it hold for hazardous areas?
A: ATEX Zone 2 and IECEx Ex nA IIC T4. -
Q: How many channels does one module support?
A: One channel per module (single-axis). -
Q: What is the MTBF (Mean Time Between Failures)?
A: >100,000 hours under normal operating conditions. -
Q: Does it support HART communication?
A: No, but analog output is HART-compatible with additional converters.
Recommended Related Modèles
Same Series (3500 Platform)
| Modèle | Description |
|---|---|
| 3500/25-01-01-00 | 4-Channel Vibration Monitor |
| 3500/22M-01-00-00 | Proximitor® Module for Eddy Current Probes |
| 3500/42M-01-00-00 | Triaxial Vibration Monitor |
| 3500/32-01-00-00 | Speed/Tachometer Module |
| 3500/92-01-01-00 | Communication Gateway |
| 3500/53-01-00-00 | Relay Module for Alarm Outputs |
Popular Bently Nevada Modèles
| Modèle | Description |
|---|---|
| 3300/16-11-02-00 | Proximity Transmitter (Older Series) |
| 1900/65A-00-00-00 | Accelerometer for Seismic Monitoring |
| 2300/25-01-00-00 | Dual-Channel Vibration Transmitter |
| 3701/25-00-00-00 | Portable Vibration Analyzer |
| 4400-XX-XX-XX | État Monitoring Ssurtware Suite |
| 3300 XL 8mm Proximitor | Eddy Current Sensor for Shaft Monitoring |
