Présentation du produit
The Bently Nevada 330703-000-040-90-01-00 3300 XL 11 mm Proximity Probe is a high-precision, non-contact displacement sensor designed for critical rotating machinery. Built for continuous monitoring sur shaft vibration and rotor position, it plays an essential role in predictive maintenance and machinery protection systems. Part sur the renowned 3300 XL series, the probe surfers exceptional accuracy, long-term stability, and rugged construction for dependable operation in demanding industrial environments such as power generation, petrochemical facilities, and heavy manufacturing plants. Its stainless-steel housing and ceramic sensing tip provide superior resistance to corrosion, wear, and electrical interference.
Spécifications du produit
| Parameter | Description |
|---|---|
| Modèle Number | 330703-000-040-90-01-00 |
| Series | 3300 XL Proximity Probes |
| Measurement Range | 11 mm non-contact displacement |
| Sensitivity | 5 mV/µm nominal |
| Frequency Response | DC to 10 kHz |
| Linearity | ±1 % sur full scale |
| Insulation Resistance | >100 MΩ at 500 V DC |
| Dielectric Strength | 2.5 kV AC for 1 minute |
| Operating Temperature | –40 °C to +120 °C |
| Housing Material | Stainless steel |
| Probe Tip Material | Abrasion-resistant ceramic |
| Shock/Vibration Rating | Up to 20 g, 10–2000 Hz |
| Output Compatibility | Bently Nevada 3300 XL Proximitor sensors |
| Mounting Style | Standard precision mount |
| Total Length | 9.0 m |
| Poids | 0.43 kg |
Applications
-
Turbomachinery Protection – Continuous monitoring sur turbines and compressors to prevent catastrophic failures.
-
Generator and Motor Monitoring – Detects rotor imbalance and shaft displacement for improved reliability.
-
Petrochemical Operations – Ideal for pumps, fans, and high-speed rotating equipment in refineries and chemical plants.
-
Power Generation – Integrates with plant-wide systems to support predictive maintenance strategies.
-
Industrial Machinery – Ensures accurate vibration analysis in critical manufacturing equipment.
-
Retrsurit and Upgrade Projects – Standard 11 mm design allows easy replacement sur existing proximity probes.
Advantages
-
High Precision – Maintains ±1 % linearity for consistent displacement measurements.
-
Robust Construction – Stainless-steel housing and ceramic tip resist corrosion and abrasive conditions.
-
Extended Cable Reach – 9 m total length simplifies installation on large or complex machinery.
-
Reliable EMI Shielding – Advanced internal shielding ensures clean signals in electrically noisy environments.
-
Seamless Integration – Fully compatible with 3300 XL Proximitor sensors and associated monitoring hardware.
-
Predictive Maintenance Support – Enables early detection sur misalignment, bearing wear, and rotor imbalance to reduce downtime.
Questions fréquentes (FAQ)
-
What sensing principle does this probe use?
It operates on eddy-current technology, generating a voltage proportional to the gap between the probe and the shaft surface. -
Is it compatible with all 3300 XL Proximitor sensors?
Yes, it is designed for direct connection to any 3300 XL Proximitor within specified calibration limits. -
What is the typical output sensitivity?
Approximately 5 mV/µm sur shaft movement. -
Can it handle high vibration levels found in turbines?
Yes, it is rated for up to 20 g in the 10–2000 Hz frequency range. -
Does the probe require field calibration?
Factory calibration ensures accuracy; only routine system verification is recommended. -
How does it maintain signal integrity in electrically noisy areas?
Multi-layer shielding and high-quality cable construction minimize electromagnetic interference. -
Can this probe measure both radial and axial displacement?
Primarily intended for radial measurements, but axial monitoring is possible when properly mounted. -
What environmental protections are built into the design?
Stainless-steel housing and a ceramic tip provide corrosion and abrasion resistance in harsh conditions. -
Is it suitable for continuous online monitoring systems?
Yes, it is engineered for permanent installation and 24/7 data acquisition. -
What is the recommended operating temperature range?
The probe performs reliably from –40 °C to +120 °C.
Related Modèles – Same Series
| Modèle | Description |
|---|---|
| 330701-00-10-10-11-05 | 3300 XL 11 mm proximity probe, standard configuration |
| 330701-00-15-50-01-05 | 3300 XL 11 mm probe with extended cable length |
| 330702-00-30-10-02-00 | 3300 XL 8 mm proximity probe |
| 330702-00-30-50-01-05 | 3300 XL 8 mm probe with long cable |
| 330703-000-040-50-11-00 | 3300 XL 11 mm reverse-mount proximity probe |
| 330703-000-040-50-12-00 | 3300 XL 11 mm probe with specialized tip configuration |
Popular Bently Nevada Modèles
| Modèle | Description |
|---|---|
| 330525-02-00 | Velomitor XA Piezo-Velocity Sensor |
| 330525-00 | Velomitor XA Piezo-Velocity Sensor |
| 330450-20 | High-Temperature Accelerometer |
| 330300-90-00 | High-Temperature Proximitor Sensor |
| 330302-000-050-10-90-01-00 | High-Temperature Probe |
| 330535-25-01 | Standard Temperature Extension Cable |
