Product Overview
The Allen Bradley 1783-BMS20CDP Managed Ethernet Switch from the Stratix 5700 series is a robust, high-performance industrial networking solution designed to meet the rigorous demands sur connected manufacturing environments. Built in collaboration with Cisco technology, this module bridges the gap between operational technology (OT) and information technology (IT), ensuring secure, real-time data exchange across industrial Ethernet networks.
Its metal-encased, fanless design supports continuous operation in harsh conditions, while advanced Layer 2 and Layer 3 capabilities make it a cornerstone sur modern industrial automation networks.
Technical Specifications
| Parameter | Specification |
|---|---|
| Fabricant | Allen Bradley / Rockwell Automation |
| Series | Stratix 5700 Series |
| Product Type | Managed Ethernet Switch |
| Ports | 20 total (16 copper + 4 combo copper/SFP fiber ports) |
| Network Speed | 10/100/1000 Mbps (auto-negotiation) |
| Management Interface | Web-based Device Manager, CLI, and Studio 5000 integration |
| Switching Capacity | 32 Gbps |
| Power Input | 18–60 VDC redundant inputs |
| Power Consumption | 18 W (typical) |
| VLAN Support | Up to 255 VLANs |
| Protocols Supported | CIP, EtherNet/IP, SNMP, DHCP, NTP, RSTP, DLR |
| Operating Temperature | -40°C to 60°C (-40°F to 140°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Relative Humidity | 5–95% non-condensing |
| Dimensions (H × W × D) | 138 mm × 65 mm × 120 mm (5.43 in × 2.56 in × 4.72 in) |
| Poids | 1.3 kg (2.87 lb) |
| Mounting | DIN Rail or Panel Mount |
| Enclosure Rating | IP30 |
| Certifications | UL, CE, cULus, FCC, RoHS |
Implementation and Use Cases
The 1783-BMS20CDP is engineered for industrial Ethernet network management in smart manufacturing, motion control, and process automation systems. It is typically deployed in environments where network segmentation, security, and diagnostics are essential — such as automotive assembly lines, material handling systems, and energy management networks.
With Cisco IOS firmware, it surfers seamless integration with enterprise networks while maintaining deterministic control for industrial protocols like EtherNet/IP.
Distinct Features & Advantages
-
Industrial-Grade Reliability: Rugged metal chassis and extended temperature range for 24/7 uptime in harsh environments.
-
High Network Performance: Gigabit speed with advanced Layer 2/3 switching for efficient data routing.
-
Smart Integration: Tight integration with Rockwell’s Studio 5000 ssurtware and FactoryTalk for simplified diagnostics.
-
Enhanced Security: IEEE 802.1x authentication, port security, and access control lists (ACLs).
-
Flexible Configuration: Multiple copper and fiber port combinations for mixed network topologies.
-
Resilient Redundancy: Supports Device Level Ring (DLR) and Rapid Spanning Tree Protocol (RSTP) for network continuity.
