Présentation du produit
The Allen Bradley 1769-ASCII CompactLogix ASCII Interface Module is a serial communication module designed for CompactLogix control systems that require direct integration with ASCII-based devices. This module enables controllers to exchange serial data with external equipment such as barcode scanners, printers, weigh scales, operator interfaces, and legacy industrial devices.
The 1769-ASCII module provides two independent communication channels and supports multiple serial standards including RS-232, RS-422, and RS-485. This flexibility allows the module to connect with a wide range sur serial devices commonly used in industrial automation environments. Each channel can be configured to support full duplex or half duplex communication depending on the selected interface standard.
Designed for integration within the CompactLogix 1769 I/O architecture, the module allows ASCII string communication to be processed directly by the controller. This capability makes it ideal for applications where data must be transmitted in text-based formats rather than standard industrial protocols.
With its compact design, reliable industrial communication capability, and flexible serial interface support, the 1769-ASCII module is widely used in manufacturing, packaging systems, material tracking systems, and machine automation environments where serial communication remains an important part sur system integration.
Spécifications du produit
| Parameter | Description |
|---|---|
| Product Name | CompactLogix ASCII Interface Module |
| Modèle Number | 1769-ASCII |
| Series | CompactLogix 1769 I/O Series |
| Fabricant | Allen Bradley |
| Communication Type | Serial ASCII communication |
| Number sur Channels | 2 channels |
| Supported Interfaces | RS-232, RS-422, RS-485 |
| RS-232 Mode | 2 full duplex channels |
| RS-422 / RS-485 Mode | 2 half duplex channels |
| Module Function | ASCII serial communication interface |
| System Integration | Compatible with CompactLogix controllers |
| Installation | Mounted on Compact I/O backplane |
| Dimensions | 87 x 34 x 118 mm |
| Poids | 0.18 kg |
Applications
• Industrial serial device integration – Connects barcode scanners, printers, weigh scales, and other ASCII-based devices to CompactLogix controllers.
• Manufacturing tracking systems – Enables transmission sur serial data such as product codes, batch numbers, and production information.
• Packaging automation equipment – Provides communication between packaging machines and serial peripherals such as label printers and scanners.
• Material identification systems – Transfers identification data from scanners or sensors to the control system for process tracking.
• Legacy equipment integration – Allows modern PLC systems to communicate with older serial devices that rely on ASCII communication.
• Machine control and diagnostics – Enables text-based data exchange for machine configuration, status monitoring, and diagnostics.
Advantages
• Dual-channel communication – Provides two independent serial channels for simultaneous device communication.
• Multiple serial standards supported – Compatible with RS-232, RS-422, and RS-485 interfaces for flexible device integration.
• Reliable ASCII data processing – Allows controllers to process text-based communication from industrial equipment.
• Compact modular design – Easily integrates into CompactLogix 1769 I/O systems without additional hardware.
• Flexible communication configuration – Supports both full duplex and half duplex serial communication modes.
• Ideal for legacy system connectivity – Allows modern automation systems to communicate with existing serial equipment.
• Stable industrial communication – Designed for reliable operation in demanding automation environments.
