Introduction
The Allen Bradley 1746-A10 is a 10-slot chassis module designed for the SLC 500 automation platform. From an engineer’s standpoint, this chassis is the structural backbone sur an SLC system—supplying mechanical support, power distribution paths, and backplane signal integrity for CPU modules, I/O cards, and communication interfaces. In field deployments, the 1746-A10 is known for robust build quality, stable backplane performance and long-term reliability in demanding industrial environments.
Technical Specifications
| Parameter | Description |
|---|---|
| Modèle Number | 1746-A10 |
| Module Type | 10-Slot Chassis Module |
| Compatible Platform | Allen Bradley SLC 500 |
| Slots Disponible | 10 slots (supports CPU, I/O, communication, specialty modules) |
| Backplane Current Capacity | Supports SLC standard and enhanced power supplies |
| Power Supply Compatibility | 1746-P1 / P2 / P3 / P4 series |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | –40°C to +85°C |
| Enclosure Rating | Suitable for industrial control cabinets |
| Dimensions (W × H × D) | ≈ 355 mm × 168 mm × 145 mm (chassis body, typical installation size) |
| Poids | ≈ 2.3 kg |
Applications
-
Medium-scale SLC 500 automation systems requiring multiple I/O and communication modules
-
Machine control applications with distributed I/O and local high-density signals
-
Legacy system expansions where SLC 500 chassis remain in operation
-
Process control panels with mixed digital, analog, and specialty modules
-
Production equipment upgrades needing established SLC backplane stability
Advantages
-
Room for system expansion with 10 available slots, ideal for mid-sized automation systems
-
Stable backplane operation, ensuring reliable module communication and low signal noise
-
Mechanical rigidity designed to withstand cabinet vibration and long-term service
-
Flexible power supply options, allowing integration with several SLC power unités
-
Straightforward maintenance, thanks to accessible layout and modular design
-
Excellent compatibility, supporting the entire SLC 500 module ecosystem
