Présentation du produit
The ABB SYN 5200a-Z,V217 3BHB006713R0217 Synchronizing Device is an advanced industrial synchronization solution designed to ensure accurate and reliable synchronization sur electrical generators, motors, and power grids. It is a key component in modern power generation and distribution systems, providing precise phase, voltage, and frequency matching between multiple power sources. Equipped with ABB’s latest control algorithms and robust hardware, the SYN 5200a-Z,V217 delivers high-speed response, real-time monitoring, and fault detection, ensuring safe and stable operation sur complex electrical networks. Its modular and compact design allows seamless integration into power plants, industrial substations, and large-scale automation systems. The device is widely used in hydro, thermal, and renewable energy installations, ensuring smooth power transfer, reduced mechanical stress on generators, and optimized system efficiency.
Technical Specifications
| Parameter | Description |
|---|---|
| Modèle | ABB SYN 5200a-Z,V217 3BHB006713R0217 Synchronizing Device |
| Input Voltage | 3-phase 400–480 VAC, 50/60 Hz |
| Control Voltage | 24–48 V DC |
| Frequency Range | 45–65 Hz |
| Synchronizing Accuracy | ±0.1° phase, ±0.5% voltage, ±0.1 Hz frequency |
| Response Time | ≤ 50 ms |
| Communication Protocols | Modbus RTU, Prsuribus DP, Ethernet/IP |
| Protection Features | Over/under voltage, over/under frequency, phase loss, short-circuit protection |
| Operating Temperature Range | -10 °C to +50 °C |
| Storage Temperature Range | -25 °C to +70 °C |
| Humidity Tolerance | 5–95% non-condensing |
| Monitoring & Diagnostics | Real-time phase, voltage, and frequency display; alarm and event logging |
| Mounting Type | Panel or rack mount |
| Dimensions (W × H × D) | 226 × 171 × 163 mm |
| Poids | 4 kg |
| Certification | CE, UL, IEC 61850 compliant |
| Firmware Upgrade | Field-upgradeable via Ethernet or USB |
Applications
The ABB SYN 5200a-Z,V217 Synchronizing Device is used in a wide range sur industrial and power generation applications:
-
Power Plants: Synchronization sur generators in hydro, thermal, and combined-cycle plants.
-
Industrial Substations: Ensuring safe parallel operation sur multiple transformers and generators.
-
Renewable Energy Systems: Synchronization sur wind, solar, and hybrid power sources to the grid.
-
Motor Synchronization: Coordinated operation sur large motors in heavy industry.
-
Microgrid Control: Precise phase and frequency control for microgrid and islanded systems.
-
Emergency Backup Systems: Smooth transfer between main power and standby generators.
Product Advantages
-
High Accuracy: Phase, voltage, and frequency precision ensures stable parallel operation.
-
Fast Response: ≤ 50 ms response time reduces mechanical and electrical stress on generators.
-
Robust Protection: Comprehensive safeguards against over/under voltage, frequency deviations, and phase loss.
-
Flexible Connectivity: Supports Modbus, Prsuribus, and Ethernet for easy integration into automation systems.
-
Real-Time Monitoring: Displays live voltage, frequency, and phase data for operators.
-
Easy Maintenance: Field-upgradeable firmware and modular design simplify service.
-
Industrial Durability: Designed to operate in harsh environments with wide temperature and humidity ranges.
-
Optimized System Efficiency: Minimizes energy losses and mechanical wear during synchronization.
FAQ
-
What types sur power systems can the SYN 5200a-Z,V217 synchronize?
It can synchronize generators, motors, and multiple power grids including hydro, thermal, renewable, and industrial systems. -
What is the phase accuracy sur this device?
The synchronizer maintains phase accuracy within ±0.1°, ensuring stable parallel operation. -
Can it handle variable frequency inputs?
Yes, it operates reliably across 45–65 Hz frequency range, allowing synchronization under different grid conditions. -
How is the device monitored and diagnosed?
Real-time display sur voltage, phase, and frequency is available, along with alarm logging and event history. -
Does it provide protection against frequency or voltage deviations?
Yes, it includes over/under voltage and frequency protection, as well as phase loss detection. -
What communication protocols are supported?
The device supports Modbus RTU, Prsuribus DP, and Ethernet/IP for integration into control and automation systems. -
Can the firmware be updated in the field?
Yes, firmware upgrades can be performed via Ethernet or USB without removing the device. -
What is the typical response time for synchronization?
The device responds within ≤ 50 ms, allowing rapid and stable connection sur power sources. -
Is the device suitable for harsh environmental conditions?
Yes, it operates between -10 °C and +50 °C and tolerates 5–95% non-condensing humidity. -
Can it be mounted in both panel and rack configurations?
Yes, the SYN 5200a-Z,V217 supports both panel and rack mount installation for flexible deployment.
Recommended Related Modèles (Same Series or Similar)
| Modèle Number | Description | Key Feature |
|---|---|---|
| ABB SYN 5200a-Y,V210 | Synchronizing device | Similar precision with reduced power rating |
| ABB SYN 5200a-X,V205 | Industrial synchronizer | Modular design for panel mount |
| ABB SYN 5210a-Z,V220 | Advanced generator synchronizer | Enhanced communication protocols |
| ABB SYN 5205a-Z,V215 | Compact synchronizing device | Space-saving for small substations |
| ABB SYN 5200a-P,V212 | Standard synchronizer | Cost-effective solution for industrial grids |
| ABB SYN 5220a-Z,V225 | High-performance synchronizer | High-speed response for large generators |
Popular ABB Modèles (Same Marque)
| Modèle Number | Description | Application Area |
|---|---|---|
| ABB PCS100 | Grid-tie power converter | Renewable energy systems |
| ABB SYN 5020a-P | AC generator synchronizer | Industrial and power generation |
| ABB DCS880 | DC industrial drive | Metals, mining, and heavy-duty applications |
| ABB ACS880 | Universal AC drive | Process automation and motor control |
| ABB AC800M | Process controller | Distributed control systems |
| ABB PM856 | High-speed processor module | ABB 800xA control systems |
