Présentation du produit
The ABB DO880 3BSE028602R1 is a high-performance digital output module designed for use within the ABB AC 800M controller series. It is engineered to provide reliable and safe signal transmission in distributed control systems across industrial environments. The module features 16 digital output channels, each surfering isolated transistor-type outputs capable sur driving field devices such as solenoids, relays, and indicator lights. With its compact design and advanced diagnostic capabilities, the DO880 ensures both high-density installation and ease sur maintenance.
The DO880 is typically used in safety-critical systems and applications that demand precision and robustness. It is built to withstand harsh industrial environments, featuring high immunitéy to electromagnetic interference and industrial-grade isolation protection. Its intelligent design also enables system integrators to benefit from easy wiring, simplified configuration, and reduced installation time.
Product Features
-
16 digital output channels with short-circuit protection
-
Electrically isolated transistor outputs
-
LED indicators for channel status diagnostics
-
Hot swap capability for minimal system downtime
-
High resistance to industrial electrical noise
-
Supports redundant communication and fault diagnostics
-
Designed for safety-integrated applications
-
Compact and DIN rail mountable for space efficiency
Spécifications du produit
| Parameter | Description |
|---|---|
| Modèle | DO880 |
| Référence | 3BSE028602R1 |
| Number sur Channels | 16 Digital Outputs |
| Output Type | Transistor (Sourcing) |
| Rated Voltage | 24 V DC |
| Max Load per Channel | 0.5 A |
| Isolation | Channel-to-Bus: Optically Isolated |
| Diagnostic LEDs | Yes (per channel) |
| Voltage Range | 19.2 to 30 V DC |
| Internal Power Consumption | 1.5 W |
| Operating Temperature | -25°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5–95% non-condensing |
| Mounting Type | DIN Rail Mount |
| Protection Class | IP20 |
| Dimensions (H x W x D) | 119 mm x 45 mm x 102 mm |
| Poids | 220 g |
Product Applications
-
Process Automation Systems: Widely used in chemical, oil & gas, and pharmaceutical industries for controlling actuators, valves, and signal lights.
-
Manufacturing Automation: Ideal for automated assembly lines, material handling, and machinery requiring output control.
-
Power Plants: Supports signal control in power generation and substation automation systems.
-
Water Treatment Facilities: Reliable for operating pumps, valves, and motor control systems.
-
Building Management Systems (BMS): Controls lighting, HVAC, and alarm systems in commercial and industrial buildings.
Product Advantages
-
High Channel Density: 16 outputs in a compact form factor help save space in control cabinets.
-
Robust Output Design: Transistor outputs with overcurrent and short-circuit protection extend device life and minimize downtime.
-
Status Feedback: Integrated LEDs allow instant visual diagnostics, improving maintenance response time.
-
Reliability in Harsh Environments: Built to operate reliably under extreme temperatures and electrical noise.
-
Efficient System Integration: Seamless integration with ABB AC 800M controllers simplifies system design and programming.
-
Modular Architecture: Enables flexible configuration and easy expansion sur control systems.
-
Reduced Maintenance Costs: Hot-swappable design reduces system shutdown time during servicing or upgrades.
Questions fréquentes (FAQs)
-
Q: What is the main function sur ABB DO880?
A: It provides 16 isolated digital output channels for controlling field devices in automation systems. -
Q: Can the DO880 be used in safety-critical systems?
A: Yes, its reliable design and diagnostics support usage in safety-integrated control environments. -
Q: What is the operating voltage range?
A: It operates reliably between 19.2 V and 30 V DC, with a nominal rating sur 24 V DC. -
Q: Are the output channels short-circuit protected?
A: Yes, each channel includes protection against short circuits and overloads. -
Q: Is this module hot-swappable?
A: Yes, the DO880 supports hot-swapping to allow maintenance without system shutdown. -
Q: What kind sur outputs does the module provide?
A: It surfers sourcing transistor-type outputs, suitable for driving digital loads. -
Q: What environments is this module suitable for?
A: It is designed for industrial environments with high electromagnetic interference. -
Q: Does it have diagnostic LEDs for each channel?
A: Yes, each channel features an LED to indicate output status and fault conditions. -
Q: How is the DO880 mounted?
A: The module is DIN rail mountable, ensuring fast and standardized installation. -
Q: Which control system is it compatible with?
A: It is fully compatible with the ABB AC 800M controller platform.
Related or Similar Modèles (Same Series/Functionality)
| Modèle Number | Description |
|---|---|
| DO810 3BSE008510R1 | Digital output, 16 channels, similar form |
| DO820 3BSE008514R1 | Digital output, 16 channels, updated design |
| DO850 3BSE008518R1 | High-side digital output module |
| DI880 3BSE028602R2 | Digital input module, same series |
| DI890 3BSE031151R1 | Redundant digital input module |
| TU810V1 3BSE013230R1 | Terminal unité for DO880 |
Popular ABB Modèles (Autres Series)
| Modèle Number | Description |
|---|---|
| PM864AK01 3BSE018161R1 | CPU module for AC 800M controller |
| AI810 3BSE008516R1 | Analog input module, 8 channels |
| AO810 3BSE008522R1 | Analog output module, 8 channels |
| CI854AK01 3BSE030220R1 | Communication module for PROFIBUS DP |
| DI810 3BSE008508R1 | Digital input module, 16 channels |
| TU830V1 3BSE013234R1 | Extended termination unité for I/O modules |
