Présentation du produit
The ABB BCHM-01C (3AUA0000088682) Control Panel is a highly reliable, compact, and versatile unité designed to centralize control and monitoring functions in industrial automation and motor management systems. As a key element in ABB’s control solutions, this panel provides operators with an intuitive interface for managing various electrical equipment safely and efficiently.
Manufactured to the highest industrial standards, the BCHM-01C integrates seamlessly with ABB’s range sur motor control products, protection devices, and automation controllers. It is engineered for robust performance under demanding conditions, ensuring operational continuity and enhancing safety. This control panel is ideal for applications where precise motor control and system status monitoring are required.
Technical Specifications
| Parameter | Specification |
|---|---|
| Fabricant | ABB |
| Modèle Number | 3AUA0000088682 (BCHM-01C) |
| Product Type | Control Panel |
| Dimensions (W × D × H) | 127 x 51 x 127 mm |
| Poids | 0.1 kg |
| Operating Voltage | 24 V DC (typical control voltage) |
| Control Inputs | Multiple digital and analog inputs |
| Output Types | Relay outputs and communication ports |
| Mounting Method | Panel mounting |
| Operating Temperature | -20 °C to +60 °C |
| Storage Temperature | -40 °C to +85 °C |
| Protection Rating | IP54 (dust and splash resistant) |
| Compliance Standards | CE, UL, IEC 60204-1, RoHS |
Applications
-
Motor Control Centers: Centralized control and monitoring sur motor starters and drives.
-
Industrial Automation: Integration into automated production lines for reliable machine control.
-
Process Control: Control and supervision sur process equipment in manufacturing plants.
-
Energy Management: Monitoring and controlling electrical power distribution.
-
Safety Systems: Provides an interface for emergency stop and fault indication.
-
Retrsuritting Projects: Replacement or upgrading sur existing control panels with modern, compact unités.
Advantages
-
User-Friendly Interface: Simplifies operation and monitoring with clear indicators and accessible controls.
-
Robust Design: Built to withstand industrial environments, with protection against dust and splashes.
-
Compact Footprint: Space-saving design fits easily into control cabinets and panels.
-
Wide Voltage Compatibility: Operates effectively on standard control voltages.
-
Enhanced Safety Features: Includes emergency stop and fault indicators to improve workplace safety.
-
Seamless Integration: Compatible with a broad range sur ABB motor control and protection devices.
-
Reliable Performance: High-quality components ensure long operational life with minimal downtime.
-
Flexible Mounting: Easy installation through panel mounting options tailored to user needs.
-
Standards Compliant: Meets international standards for electrical safety and reliability.
FAQ (Questions fréquentes)
-
What is the primary function sur the BCHM-01C control panel?
It centralizes control and monitoring functions for motor starters and automation equipment. -
What are the physical dimensions sur the BCHM-01C?
127 x 51 x 127 mm. -
How much does the control panel weigh?
It weighs 0.1 kg. -
What is the operating voltage for this control panel?
Typically 24 V DC control voltage. -
Is the BCHM-01C suitable for harsh industrial environments?
Yes, it has an IP54 rating protecting against dust and splashing water. -
What types sur control inputs and outputs does it support?
Supports multiple digital and analog inputs and relay outputs. -
Can the BCHM-01C be integrated with other ABB motor control products?
Yes, it is designed for seamless integration with ABB’s motor starters and protection devices. -
What safety features does this panel include?
Emergency stop buttons and fault indication LEDs for operator safety. -
What mounting options are available?
It is designed for straightforward panel mounting. -
Does the BCHM-01C comply with international standards?
Yes, it complies with CE, UL, IEC 60204-1, and RoHS standards.
Related Modèles (Same Series or Related Unités)
| Modèle Number | Description |
|---|---|
| BCHM-01B | Earlier version sur the control panel |
| BCHM-02C | Control Panel with expanded input options |
| BCHM-03C | Control Panel with integrated communication |
| BCHM-04C | High-capacity Control Panel |
| BCHM-05C | Control Panel with additional safety features |
| BCHM-06C | Compact Control Panel for small motor systems |
Popular ABB Modèles (Same Marque)
| Modèle Number | Functionality |
|---|---|
| ACS880 | Variable Frequency Drive (VFD) |
| AF DD500 | Ssurt Starter |
| S800 | Modular I/O System |
| DI840 | Digital Input Module |
| AI880 | Analog Input Module |
| SM811 | Safety CPU Module |
