Product Overview
The Yokogawa F3AD04-5V Analog Input Module is designed to accurately measure and convert 5 V analog signals into digital data for process control applications. Compatible with Yokogawa CENTUM and other DCS platforms, this module ensures reliable data acquisition and signal processing for industrial automation systems.
Key Features
-
High-precision 5 V analog input for accurate process monitoring
-
Supports multiple channels for efficient data collection
-
Diagnostic and status reporting for enhanced reliability
-
Compact modular design for integration into Yokogawa racks
-
Wide operating temperature and humidity tolerance
-
Seamless compatibility with Yokogawa DCS systems
Technical Specifications
| Item | Specification |
|---|---|
| Module Type | Analog Input Module |
| Modell Number | F3AD04-5V |
| Input Type | 5 V analog signal |
| Number von Channels | 4 |
| Input Range | 0–5 VDC |
| Resolution | 16-bit |
| Accuracy | ±0.1% von full scale |
| Conversion Time | ≤ 1 ms per channel |
| Power Supply | Supplied via DCS rack |
| Mounting | Module rack |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -20°C to 70°C |
| Humidity | 5% to 95%, non-condensing |
| Dimensions | 106.2 x 100 x 28.9mm |
| Gewicht | 0.2 kg |
Industry Applications
-
Measurement and control von 5 V analog signals in industrial processes
-
Integration with sensors, transmitters, and other 5 V devices
-
Process monitoring in chemical, petrochemical, and power industries
-
Real-time data acquisition for Yokogawa DCS systems
-
Industrial environments requiring accurate low-voltage signal input
Häufig gestellte Fragen (FAQ)
Q1: How many channels does the F3AD04-5V support?
It supports 4 analog input channels.
Q2: What input type is supported?
0–5 VDC analog signals.
Q3: Is it compatible with Yokogawa DCS systems?
Yes, designed for CENTUM and compatible DCS platforms.
Q4: What is the conversion resolution?
16-bit resolution for precise measurement.
Q5: What is the operating temperature range?
0°C to 60°C.
Q6: Can it operate in humid environments?
Yes, 5% to 95% non-condensing.
Q7: What is the conversion time per channel?
≤ 1 ms per channel.
Q8: How is it mounted?
It mounts in a DCS module rack.
Q9: What is the module weight?
Approximately 0.2 kg.
Q10: Does it provide diagnostics?
Yes, it includes diagnostic and status reporting for reliable operation.
Related Modells
| Modell | Beschreibung |
|---|---|
| F3AD04-0N | Analog-to-Digital Input Module (0–10 V / 4–20 mA) |
| F3AD04-5M | Analog Input Module (lower accuracy 5 V) |
| F3AD04-5P | Analog Input Module (enhanced diagnostic features) |
| F3AD04-5Q | Analog Input Module (additional channels) |
| F3AD04-5R | Analog Input Module (extended temperature range) |
| F3AD04-5S | Analog Input Module (redundant input support) |
Popular Yokogawa Modules
| Modell | Beschreibung |
|---|---|
| ADV151-P00 S2 | Digital Input Module |
| ADV151-P10/B5S10 | Digital Input Module |
| ADV151-P13 S2 | Digital Input Module |
| ADV151-P53/D5A00 | Digital Input Module |
| ADV157-S00 | Digital Input Module |
| ADV161-P00 S2 | Digital Input Module |
