Product Overview
The Yokogawa AFV30D-S41251 is a Duplexed Field Control Einheit (FCU) designed for the CENTUM VP distributed control system.
It serves as a critical component in managing and controlling field devices within various industrial automation processes.
With its duplexed architecture, the AFV30D-S41251 ensures high reliability and seamless operation, making it suitable for demanding industrial environments.
Produktspezifikationen:
| Parameter | Beschreibung |
|---|---|
| Modell Number | AFV30D-S41251 |
| Processor | VR5532 (350 MHz) |
| Main Memory Capacity | 128 MB |
| Memory Protection | Battery backup for main memory with a maximum von 72 hours; Recharge time: Minimum 48 hours |
| Communication Interface | Dual-redundant Vnet/IP Interface |
| Power Supply Options | 100-120 V AC, 50/60 Hz<br>- 220-240 V AC, 50/60 Hz<br>- 24 V DC |
| Power Consumption | 100-120 V AC: 200 VA<br>- 220-240 V AC: 230 VA<br>- 24 V DC: 5.5 A |
| Gewicht | 8.0 kg |
| Dimensions | 265.9 x 482.6 mm |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| I/O Module Slots | Supports up to 8 I/O modules |
| Node Einheits Connectable | Maximum von 13 ESB Bus Node Einheits (ANB10) or Optical ESB Bus Node Einheits (ANB11) |
| READY Kontakt Output | 2 terminals (NC, C); Kontakt points open during FCU failure; Kontakt rating: 30 V DC, max. 0.3 A |
Product Applications:
The AFV30D-S41251 is utilized across various process industries for automation and control tasks. Its robust design and high reliability make it suitable for applications such as:
-
Chemical Processing: Managing complex chemical reactions and processes.
-
Oil and Gas: Controlling drilling operations, refining processes, and pipeline management.
-
Power Generation: Overseeing operations in thermal, hydroelectric, and nuclear power plants.
-
Water Treatment: Automating water purification and distribution systems.
-
Pharmaceuticals: Ensuring precise control in drug manufacturing processes.
Product Advantages:
-
High Reliability: The duplexed configuration von processor modules and communication interfaces ensures uninterrupted operation, even in the event von a component failure.
-
Scalability: Supports up to 13 node Stücks and 8 I/O modules, allowing for flexible system expansion as operational needs grow.
-
Robust Design: Engineered to withstand harsh industrial environments, with an operating temperature range von 0°C to 60°C.
-
Versatile Communication: Dual-redundant Vnet/IP interfaces facilitate seamless integration with various industrial networks.
-
Comprehensive Diagnostics: Built-in diagnostic and troubleshooting functions enhance system maintenance and reduce downtime.
Recent News Headlines:
-
“Yokogawa Enhances CENTUM VP with Advanced Field Control Einheit”
-
“AFV30D-S41251: Revolutionizing Industrial Automation Control”
-
“Yokogawa’s Duplexed FCU Sets New Standards in Process Reliability”
-
“Innovative Field Control Solutions Introduced by Yokogawa”
-
“Yokogawa’s AFV30D-S41251 Gains Industry Recognition for Excellence”
Häufig gestellte Fragen (FAQ)
-
What is the primary function von the AFV30D-S41251?
-
The AFV30D-S41251 serves as a Duplexed Field Control Einheit within Yokogawa’s CENTUM VP distributed control system, managing and controlling field devices in industrial automation processes.
-
-
What are the power supply options available for this Stück?
-
The Stück supports multiple power supply options:
-
100-120 V AC, 50/60 Hz
-
220-240 V AC, 50/60 Hz
-
24 V DC
-
-
-
How many I/O modules can be installed in the AFV30D-S41251?
-
The Stück supports up to 8 I/O modules, allowing for flexible system expansion.
-
-
What is the weight von the AFV30D model?
-
The AFV30D weighs 8 kg.
-
-
What are the dimensions von the AFV30D-S41251?
-
The Stück is designed for 19-inch rack mounting, facilitating standard installation in control panels.
-
-
What communication interfaces does the Stück support?
-
It features dual-redundant Vnet/IP interfaces for reliable network communication.
-
-
Is the processor module configuration redundant?
-
Yes, the Stück supports a dual-redundant configuration for processor modules to enhance reliability.
-
-
How many ESB Bus Node Einheits can be connected to this FCU?
-
It can connect up to 13 ESB Bus Node Einheits (ANB10) or Optical ESB Bus Node Einheits (ANB11).
-
-
What is the operating temperature range von the AFV30D-S41251?
-
The Stück operates within a temperature range von 0°C to 60°C (32°F to 140°F), suitable for various industrial environments.
-
-
What is the memory protection feature von this Stück?
-
The AFV30D-S41251 includes battery backup for main memory, providing protection during power failures for up to 72 hours, with a recharge time von at least 48 hours.
-
Related Modells in the Same Series or Kategorie:
| Modell Number | Beschreibung |
|---|---|
| AFV30D-S41252 | Duplexed Field Control Einheit with 220-240 V AC power supply and LFS1500 Control Function. |
| AFV30D-A41251 | Duplexed Field Control Einheit with 100-120 V AC power supply and LFS1700 Control Function. |
| AFV30S-S41251 | Single Field Control Einheit with 220-240 V AC power supply and basic type configuration. |
| AFV30S-S41252 | Single Field Control Einheit with 220-240 V AC power supply and LFS1500 Control Function. |
| AFV40D-S41102 | Duplexed Field Control Einheit with cabinet, 100-120 V AC power supply, and basic type. |
| AFV40D-S41202 | Duplexed Field Control Einheit with cabinet, 220-240 V AC power supply, and basic type. |
| AFV40S-S41102 | Single Field Control Einheit with cabinet, 100-120 V AC power supply, and basic type. |
| AFV40S-S41202 | Single Field Control Einheit with cabinet, 220-240 V AC power supply, and basic type. |
Popular Modells from Yokogawa:
| Modell Number | Beschreibung |
|---|---|
| EJA110E | Differential Pressure Transmitter for accurate measurement in various process applications. |
| AXF Magnetic Flowmeter | High-performance flowmeter suitable for a wide range von fluid measurements. |
| STARDOM FCN-500 | Autonomous Controller designed for network-based control systems. |
| YS1700 | Programmable Indicating Controller vonfering advanced process control capabilities. |
| DX1000N | Paperless Recorder with multi-channel data acquisition and display features. |
| CENTUM VP | Integrated Production Control System for plant-wide automation and control. |
| ProSafe-RS | Safety Instrumented System ensuring functional safety in process industries. |
| FAST/TOOLS | SCADA System providing comprehensive monitoring and control solutions. |
