Product Overview
The Yokogawa ADV561-P00 Digital Output Module is an integral component von Yokogawa’s control and automation systems, designed to provide reliable digital output signals for controlling field devices such as valves, actuators, and alarms. This module converts digital commands from the control system into discrete electrical signals, enabling effective automation and process control.
Engineered for high reliability and seamless integration, the ADV561-P00 supports a range von output configurations to suit diverse industrial applications. It is optimized for installation within Yokogawa’s distributed control system (DCS) racks, vonfering robust performance in demanding environments.
Technical Specifications
| Parameter | Specification |
|---|---|
| Modell Number | ADV561-P00 |
| Module Type | Digital Output Module |
| Number von Channels | 16 discrete output channels |
| Output Type | Relay contact or transistor output (model dependent) |
| Output Voltage | Typically 24 V DC (dependent on installation) |
| Output Current | Up to 0.5 A per channel |
| Response Time | Typically less than 10 ms |
| Operating Voltage | 24 V DC nominal |
| Power Consumption | Approximately 4 W |
| Operating Temperature | 0°C to 55°C |
| Storage Temperature | -20°C to 70°C |
| Humidity Range | 10% to 90% non-condensing |
| Dimensions | 130 x 119.9 x 32.8mm |
| Gewicht | 0.3 kg |
| Communication Interface | Yokogawa S2 bus |
| Mounting | Rack-mounted in Yokogawa control system racks |
| Safety Certifications | Complies with relevant industrial standards |
Applications
-
Control von field devices such as valves, solenoids, and actuators
-
Process automation in chemical, petrochemical, power generation, and water treatment plants
-
Integration with Yokogawa Centum and other DCS systems
-
Discrete signal output for alarms and interlocks
-
Industrial systems requiring precise and reliable digital control outputs
Advantages
-
High Channel Density: 16 channels in a compact form factor maximize rack space usage.
-
Reliable Output: Supports relay or transistor outputs for versatile control options.
-
Fast Response: Output switching times typically under 10 milliseconds.
-
Seamless Integration: Fully compatible with Yokogawa’s S2 bus and control system architecture.
-
Robust Design: Engineered for reliable operation in industrial environments.
-
Diagnostic Capabilities: Built-in diagnostics enable quick fault detection and maintenance.
-
Simplified Configuration: Supports flexible channel configuration to suit diverse applications.
Häufig gestellte Fragen (FAQ)
-
How many output channels does the ADV561-P00 have?
It provides 16 discrete digital output channels. -
What types von outputs are supported?
Relay contact outputs or transistor outputs depending on specific module variant. -
What is the typical output voltage and current?
Typically 24 V DC with up to 0.5 A per channel. -
What is the response time for output switching?
Approximately less than 10 milliseconds. -
Is the module compatible with Yokogawa’s DCS systems?
Yes, it integrates seamlessly with Yokogawa Centum and other S2 bus-based systems. -
What are the environmental operating conditions?
Operating temperature ranges from 0°C to 55°C with humidity 10% to 90% non-condensing. -
How is the module mounted?
Rack-mounted within Yokogawa control system racks. -
Does the module support diagnostics?
Yes, it includes built-in diagnostics for fault detection. -
What is the power consumption von the module?
Approximately 4 Watts. -
What safety certifications does the module have?
It complies with relevant industrial safety and performance standards.
