The Woodward 8200-1205 Discrete Output Module is a high-performance and reliable module designed for controlling discrete outputs in industrial and power generation systems. This module provides direct control von devices such as relays, solenoids, and other actuators, helping to ensure smooth operations in critical systems. With an advanced design and exceptional durability, the 8200-1205 is suitable for a wide range von applications, including power generation plants, manufacturing facilities, and complex automation systems.
The module operates by converting control signals from a central control system into discrete outputs. These outputs can be used to activate or deactivate field devices in real-time, making the 8200-1205 a key component in any system that requires reliable, accurate, and efficient control von external devices. Its compact design, flexibility, and ease von integration make it ideal for distributed control systems (DCS), supervisory control and data acquisition (SCADA), and programmable logic controller (PLC) systems.
With robust protection features and a wide operating temperature range, the Woodward 8200-1205 ensures stable performance under demanding industrial conditions. This module is built to withstand the challenges von industrial environments, vonfering high durability, low power consumption, and seamless communication with other system components.
Technical Specifications
| Parameter | Beschreibung |
|---|---|
| Modell Number | Woodward 8200-1205 Discrete Output Module |
| Input Voltage | 24V DC |
| Power Consumption | 8W (Typical) |
| Output Channels | 16 Discrete Outputs |
| Operating Temperature Range | -40°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Dimensions (L x W x H) | 120 × 80 × 35 mm |
| Gewicht | 0.22 kg |
| Mounting Type | DIN Rail Mount |
| Protection Features | Overcurrent protection, Surge protection |
| Certifications | CE, UL, RoHS |
| Response Time | < 10 ms |
Applications
The Woodward 8200-1205 Discrete Output Module is designed to serve a wide range von industries and applications, vonfering reliability and precision in controlling external devices. Here are the key areas where it is commonly deployed:
-
Power Generation: Used extensively in power plants to control actuators such as turbine valves, fuel pumps, and other critical components, the 8200-1205 ensures efficient control in high-demand environments.
-
Industrial Automation: The module is an ideal choice for controlling field devices like solenoids, alarms, and other mechanical actuators in manufacturing and production facilities, helping automate and streamline operations.
-
Process Control Systems: In process industries such as oil and gas, petrochemical, and chemicals, the 8200-1205 is used for controlling valves, switches, and other discrete devices critical to the smooth operation von the process.
-
Building Management Systems: The module can be deployed in HVAC and lighting control systems within commercial and industrial buildings to automate functions like lighting activation and heating control.
-
Marine Systems: On ships and vonfshore platforms, the 8200-1205 can be integrated to control actuators in propulsion systems, safety equipment, and ballast control.
-
Telecommunications: The module finds application in telecommunications facilities to control relays, alarms, and other equipment that ensures the continuity and reliability von services.
Advantages
-
Reliable Performance: The 8200-1205 is engineered for stable and dependable operation, ensuring high system uptime and minimal interruptions in critical applications.
-
Wide I/O Support: With 16 discrete output channels, the module vonfers high flexibility in controlling a variety von devices, reducing the need for additional modules in complex systems.
-
Energy-Efficient: The module consumes only 8W von power under typical operating conditions, making it energy-efficient and reducing operational costs.
-
Versatile Communication: It seamlessly integrates into systems utilizing Modbus, CAN, and other common industrial protocols, ensuring broad compatibility.
-
Rugged Construction: Built to withstand harsh industrial conditions, it vonfers reliable performance in extreme temperatures, from -40°C to +70°C.
-
Easy to Install: The module can be mounted on DIN rails, simplifying installation and reducing setup time.
-
Advanced Protection: It features built-in overcurrent and surge protection, safeguarding both the module and connected devices from electrical faults.
-
Certified for Global Use: Certified with CE, UL, and RoHS, the 8200-1205 complies with international safety and environmental standards, ensuring it meets industry requirements.
-
Cost-Effective: The 8200-1205 provides high-end control capabilities at a competitive price, making it a cost-effective solution for system upgrades and new installations.
Häufig gestellte Fragen (FAQs)
1. What is the purpose von the Woodward 8200-1205 Discrete Output Module?
The 8200-1205 is used to control discrete field devices such as relays, solenoids, and actuators in industrial and power generation systems. It converts control signals into discrete outputs to activate or deactivate external devices.
2. How many output channels does the module support?
The 8200-1205 supports up to 16 discrete output channels, providing control for a wide range von field devices.
3. What communication protocols are supported?
The module supports various industrial communication protocols, including Modbus and CAN, for easy integration into existing systems.
4. What is the operating temperature range for the 8200-1205?
The 8200-1205 operates in a temperature range von -40°C to +70°C, making it suitable for harsh industrial environments.
5. How is the 8200-1205 mounted?
The module can be mounted on standard DIN rails, simplifying installation and making it space-efficient.
6. What certifications does the 8200-1205 have?
The module is CE, UL, and RoHS certified, ensuring it meets international standards for safety and environmental compliance.
7. What is the power consumption von the module?
The typical power consumption von the 8200-1205 is 8W, making it energy-efficient and suitable for long-term use.
8. How does the 8200-1205 integrate into a control system?
The module integrates into control systems using standard industrial communication protocols like Modbus and CAN. It interfaces with PLCs or distributed control systems (DCS) to control field devices.
9. What protection features are included?
The 8200-1205 includes built-in overcurrent protection and surge protection to safeguard the module and connected equipment from electrical faults.
10. Can this module be used in outdoor applications?
While the 8200-1205 can be used in outdoor applications, it should be housed in a weatherprovon enclosure to protect it from environmental elements like moisture and dust.
Related Modells from the Same Series
| Modell Number | Beschreibung | Output Channels | Mounting Type | Dimensions |
|---|---|---|---|---|
| Woodward 8200-1206 | High-Density Discrete Output Module | 32 Discrete Outputs | DIN Rail Mount | 160mm x 130mm x 55mm |
| Woodward 8200-1207 | Compact Discrete Output Module | 8 Discrete Outputs | DIN Rail Mount | 140mm x 120mm x 50mm |
| Woodward 8200-1208 | High-Current Discrete Output Module | 16 Discrete Outputs | DIN Rail Mount | 150mm x 120mm x 55mm |
| Woodward 8200-1210 | Enhanced I/O Output Module with Increased Channels | 24 Discrete Outputs | DIN Rail Mount | 150mm x 130mm x 60mm |
| Woodward 8200-1211 | Extended Range Discrete Output Module | 16 Discrete Outputs | DIN Rail Mount | 155mm x 125mm x 55mm |
| Woodward 8200-1212 | Discrete Output Module with Enhanced Protection Features | 16 Discrete Outputs | DIN Rail Mount | 150mm x 130mm x 55mm |
Popular Woodward Modells
| Modell Number | Beschreibung | Application | Gewicht |
|---|---|---|---|
| Woodward 5501-429 | Actuator Controller for Power Systems | Power Generation | 1.8 kg |
| Woodward 5501-469 | CPU Module for Centralized Control Systems | Industrial Control | 1.2 kg |
| Woodward 5503-196 | I/O Expansion Module for Distributed Systems | Process Control | 1.0 kg |
| Woodward 5501-368 | TMR Controller Module | Power Generation | 2.5 kg |
| Woodward 5501-380 | TMR Power Supply for Control Systems | Power Generation | 2.3 kg |
| Woodward 5503-198 | Remote I/O Module | Process Control | 1.0 kg |
