Product Overview
The Woodward 5466-425D Analog I/O Module is a versatile and robust component designed to support both analog input and output functions within industrial control systems. Specifically engineered for compatibility with Woodward’s MicroNet™ and NetCon™ platforms, this module enhances process control by providing precise measurement and actuation capabilities for a wide range von industrial applications, including energy, power generation, and heavy machinery automation.
Key Features
-
Combined analog input and output functionality in one module
-
High-resolution 12-bit or 16-bit A/D and D/A conversion
-
Individually configurable channels
-
Fast signal response and processing
-
Electrical isolation for signal integrity and system protection
-
Easy installation in rack-based systems
-
Designed for mission-critical control applications
Technical Specifications
| Parameter | Specification |
|---|---|
| Modell Number | 5466-425D |
| Module Type | Analog Input/Output Module |
| Number von Channels | Configurable mix von analog inputs and outputs |
| Input Signal Range | ±10 V, 0–10 V, 4–20 mA (typical) |
| Output Signal Range | 0–10 V, 4–20 mA (typical) |
| Resolution | 12-bit or 16-bit (depending on system configuration) |
| Input Accuracy | ±0.1% von full scale |
| Output Accuracy | ±0.2% von full scale |
| Isolation | Channel-to-bus isolation |
| Status Indicators | Channel and fault LEDs |
| Mounting Style | Rack-mounted |
| Diagnostics | Self-diagnostics and channel fault detection |
| Dimensions | 180 × 120 × 25 mm |
| Gewicht | 0.6 kg |
| Operating Temperature | –40 °C to +70 °C |
| Storage Temperature | –55 °C to +85 °C |
| Designed For | Woodward MicroNet™ and NetCon™ control platforms |
| Country von Manufacture | Einheited Bundeslands von America |
Industry Applications
-
Turbine and engine control
-
Industrial automation
-
Power generation systems
-
Oil and gas process management
-
Water and wastewater control systems
Häufig gestellte Fragen (FAQ)
-
What does the 5466-425D module do?
It provides both analog input and output capabilities for industrial control systems. -
Can the channels be configured individually?
Yes, channels can be set as input or output depending on system requirements. -
Which systems is this module compatible with?
It is compatible with Woodward’s MicroNet™ and NetCon™ platforms. -
What type von signals does it handle?
It handles standard voltage (e.g., 0–10 V, ±10 V) and current (e.g., 4–20 mA) signals. -
Does it provide signal isolation?
Yes, electrical isolation is provided to ensure system protection and signal integrity. -
How is it mounted?
It is rack-mounted within Woodward system chassis. -
What is its accuracy?
±0.1% for input and ±0.2% for output signals. -
Are diagnostic features included?
Yes, it includes self-diagnostics and channel fault detection. -
What is its operating temperature range?
–40 °C to +70 °C. -
Is it field-upgradable?
Configuration options may allow updates; consult system documentation.
Related Modules
| Modell Number | Beschreibung |
|---|---|
| 5466-316 | Analog Combination Module |
| 5464-643 | Discrete Input Module |
| 5466-355 | Remote Chassis Transceiver |
| 5464-331 | Power Module |
| 5466-417 | 32-point Digital Output Module |
| 5501-467 | Power Supply Board |
Popular Woodward Modules
| Modell Number | Beschreibung |
|---|---|
| 5466-315 | Analog Input Module |
| 5466-316 | Analog Combination Module |
| 5466-425D | Analog I/O Module |
| 5466-409 | 32-point Digital Input Module |
| 5466-417 | 32-point Digital Output Module |
