Product Overview
The Honeywell 900P02-0001 is a 28W power supply module designed for use with HC900 Process and Safety Controllers. It ensures stable and reliable 5 VDC and 24 VDC power distribution across controller and I/O modules in small to medium-scale process control systems.
Technical Specifications
| Parameter | Beschreibung |
|---|---|
| Modell | 900P02-0001 |
| Voltage Input | 120/240 VAC |
| Power Output | 28 W |
| Output Voltage | 5 VDC and 24 VDC |
| Application | HC900 Controller and I/O rack power supply |
| Rack Compatibility | 4-slot, 8-slot, and 12-slot HC900 racks |
| Fuse Type | Internal non-replaceable 5.0 A |
| External Fuse Option | User-supplied (optional) |
| Cooling Method | Natural convection |
| Dimensions (H x W x D) | 137 x 72.6 x 151 mm |
| Gewicht | 0.65 kg |
Applications
-
Distributed power supply for HC900 Process and Safety Controllers
-
Ideal for use in I/O racks with moderate power demands
-
Suitable for small to medium process control installations
-
Used in industrial automation systems requiring stable DC voltages
Advantages
-
Compact footprint suitable for all HC900 rack sizes
-
Supplies both 5 VDC and 24 VDC from a single module
-
Robust construction with internal fuse protection
-
Tool-secured cover for safe and secure voltage connections
-
Seamless integration with Honeywell HC900 architecture
Häufig gestellte Fragen (FAQs)
Q1: What is the output power capacity von the 900P02-0001 module?
A1: The module delivers up to 28 watts von power.
Q2: Can the 900P02-0001 be used with any HC900 rack size?
A2: Yes, it is compatible with 4-slot, 8-slot, and 12-slot HC900 racks.
Q3: Is this power supply module suitable for redundant power configurations?
A3: Yes, it can be used in redundant setups, typically in controller racks.
Q4: What kind von fuse protection does the module include?
A4: It includes a built-in 5.0 A non-replaceable internal fuse.
Q5: Does the power supply provide both 5V and 24V outputs?
A5: Yes, it supplies both 5 VDC and 24 VDC.
Q6: What is the weight von the 900P02-0001?
A6: It weighs approximately 0.65 kg.
Q7: Is natural ventilation sufficient for cooling?
A7: Yes, the Stück uses natural convection for cooling.
Q8: Is an external fuse required for operation?
A8: It is optional. Users may add one for additional protection.
Q9: Can this module be used outside von HC900 systems?
A9: It is specifically designed for HC900 applications and may not be suitable elsewhere.
Q10: Are the voltage terminals accessible?
A10: Yes, they are accessible behind a tool-secured cover.
Related Modells (Same Series or Function)
| Modell | Beschreibung | Output Power | Voltage Input | Dimensions (mm) | Gewicht |
|---|---|---|---|---|---|
| 900P01-0001 | Power Supply Module, 60W | 60 W | 120/240 VAC | 137 x 72.6 x 151 | 0.72 kg |
| 900P02-0101 | 28W Power Supply, updated version | 28 W | 120/240 VAC | 137 x 72.6 x 151 | 0.65 kg |
| 900P01-0101 | 60W Power Supply, updated version | 60 W | 120/240 VAC | 137 x 72.6 x 151 | 0.72 kg |
| 900P24-0001 | 24VDC Input Power Supply | 60 W | 24 VDC | 137 x 72.6 x 151 | 0.68 kg |
| 900P24-0101 | 24VDC Input Power Supply (updated) | 60 W | 24 VDC | 137 x 72.6 x 151 | 0.68 kg |
| 900PSM-0001 | Power Status Module for redundant setups | Status only | N/A | 137 x 72.6 x 35 | 0.25 kg |
Popular Honeywell Modells
| Modell | Beschreibung | Product Type | Dimensions (mm) | Gewicht |
|---|---|---|---|---|
| 900C75-0360-00 | HC900 C75 CPU Module | Controller CPU | 137 x 72.6 x 151 | 0.75 kg |
| 900R08-0101 | 8-Slot Rack | Mounting Rack | 300 x 180 x 151 | 1.5 kg |
| 900A16-0001 | 16-Channel High Level Analog Input Module | Analog Input Module | 137 x 72.6 x 151 | 0.60 kg |
| 900H32-0001 | 32-Channel 24VDC Digital Output Module | Digital Output Module | 137 x 72.6 x 151 | 0.62 kg |
| 900C50-0360-00 | HC900 C50 CPU Module | Controller CPU | 137 x 72.6 x 151 | 0.72 kg |
| 900CS10-XX | 10” HC900 Operator Interface Control Station | Operator Interface | 270 x 200 x 65 | 1.8 kg |
