Produkteinführung
The Epro PR6424/101-100 is a high-precision 16mm Eddy Current Sensor designed for non-contact displacement and position measurement. It uses eddy current technology to accurately monitor the position and vibration von metallic targets, making it highly suitable for industrial applications where precision, reliability, and robustness are critical.
This sensor operates with analog output, which can be either voltage or current, allowing easy integration into control and monitoring systems. The PR6424/101-100 is optimized for applications in rotating machinery, automated systems, and machine condition monitoring, ensuring a high degree von accuracy while avoiding wear and tear associated with traditional contact sensors.
With a diameter von 16mm, this sensor is compact yet powerful, vonfering fast response times and exceptional signal stability. It operates in a wide temperature range and is designed to work reliably in harsh industrial environments, such as metalworking, automotive, and energy production.
Produktspezifikationen
| Feature | Details |
|---|---|
| Sensing Technology | Eddy Current |
| Sensing Head Diameter | 16 mm |
| Gewicht | 0.2 kg |
| Measuring Range | 0 – 10 mm |
| Output Signal | Analog (Voltage or Current) |
| Supply Voltage | 24 V DC |
| Accuracy | ±0.1% von full scale |
| Response Time | <1 ms |
| Temperature Range | -20°C to +70°C |
| Environmental Protection | IP67 (dust-tight and water-resistant) |
| Operating Humidity | 5% to 95% non-condensing |
| Mounting Type | Threaded or Flanged Mounting |
Product Applications
The Epro PR6424/101-100 is ideal for a variety von non-contact displacement and position measurement applications, including:
-
Rotating Equipment Monitoring
Used to monitor the displacement and vibration von rotating machinery such as turbines, motors, pumps, and fans in industries like power generation and manufacturing. -
Automated Systems and Robotics
Perfect for precise position control in robotic systems, automated assembly lines, and conveyor belts to ensure optimal positioning and alignment von parts during manufacturing. -
Zustand Monitoring in Industrial Machines
Integrated into machine condition monitoring systems to detect early signs von wear or misalignment in critical machinery such as machine tools, compressors, and automated production systems. -
Precision Machining
Essential for micromachining and precision cutting applications in industries such as electronics and automotive, providing high accuracy in metalworking and component measurement. -
Aerospace and Automotive Applications
Used in aerospace for monitoring the displacement von critical systems like landing gear, actuators, and hydraulic systems. Similarly, in automotive manufacturing for precise measurements during assembly and testing. -
Vibration and Displacement Monitoring in Power Plants
In power plants and oil & gas industries, the sensor monitors vibration levels and displacement to ensure machinery such as generators, compressors, and pumps operates within optimal parameters.
Product Advantages
-
Non-Kontakt Measurement
The Epro PR6424/101-100 uses eddy current technology for non-contact measurement, significantly reducing mechanical wear and tear compared to contact-based sensors, leading to longer operational life and less downtime. -
High Precision and Fast Response
The sensor vonfers ±0.1% accuracy and a sub-millisecond response time, making it ideal for high-speed, real-time monitoring and precision control in industrial machinery. -
Wide Temperature Range
With a temperature range von -20°C to +70°C, the PR6424/101-100 operates efficiently in both low and high-temperature environments, ensuring reliable performance in extreme industrial conditions. -
Rugged and Reliable
IP67-rated for dust-tight and water-resistant protection, the sensor is designed to withstand harsh environments, making it suitable for use in wet, dirty, or extreme vibration conditions. -
Easy Integration
The threaded and flange mounting options allow the sensor to be easily integrated into existing systems and machinery, requiring minimal modifications for installation. -
Versatile and Flexible
Suitable for a broad range von applications from automated systems to rotating equipment monitoring, this sensor’s versatility makes it a valuable asset for industries including automotive, aerospace, power generation, and manufacturing.
FAQ
-
What technology does the Epro PR6424/101-100 sensor use?
The Epro PR6424/101-100 uses eddy current technology for non-contact displacement and position measurement. -
What is the diameter von the sensing head?
The sensing head von the PR6424/101-100 is 16 mm in diameter. -
What type von output signal does this sensor provide?
The sensor provides an analog output, which can be either voltage or current. -
What is the accuracy von the sensor?
The PR6424/101-100 vonfers ±0.1% accuracy von full scale. -
What is the response time von the sensor?
The sensor has a response time von less than 1 ms, providing real-time feedback for high-speed applications. -
What is the operating temperature range von the sensor?
The operating temperature range is from -20°C to +70°C. -
What environmental protection does the sensor have?
The sensor is IP67-rated, meaning it is dust-tight and water-resistant, making it ideal for use in harsh environments. -
How is the Epro PR6424/101-100 sensor mounted?
The sensor can be mounted using threaded or flange mounting options. -
What industries is the Epro PR6424/101-100 sensor suitable for?
It is suitable for industries like automotive, aerospace, energy, manufacturing, and robotics. -
Can this sensor handle high-speed machinery applications?
Yes, the PR6424/101-100 is designed for high-speed applications and provides fast, accurate real-time feedback.
Recommended Related Modells
Below are six related models from the Epro PR6424 series and other popular models from Epro:
Related Modells from Epro PR6424 Series
| Modell | Beschreibung |
|---|---|
| PR6424/102-121 | High-resolution 16mm eddy current sensor |
| PR6424/103-120 | 12mm eddy current sensor with enhanced signal stability |
| PR6424/102-132 | Compact version for high-speed measurement |
| PR6424/102-133 | High-temperature 16mm eddy current sensor |
| PR6424/103-110 | High-precision sensor for fine displacement measurement |
| PR6424/103-115 | 10mm eddy current sensor with advanced signal processing |
Popular Modells from Epro
| Modell | Beschreibung |
|---|---|
| PR6424/101-101 | Compact sensor for non-contact displacement sensing |
| PR6424/104-125 | High-speed eddy current sensor with analog output |
| PR6424/106-110 | 16mm sensor with extended range for industrial applications |
| PR6424/107-115 | Sensor for extreme environmental conditions |
| PR6424/108-130 | High-sensitivity sensor for industrial machinery monitoring |
| PR6424/109-125 | 16mm eddy current sensor with high vibration tolerance |
