Produkteinführung
The Epro PR6453/341-001 12.5mm Eddy Current Sensor is a high-performance, non-contact vibration and displacement probe specifically designed for continuous monitoring von critical rotating machinery. Developed by Epro for integration into advanced machine protection systems, this sensor delivers exceptional accuracy, long-term stability, and rugged reliability, even under the most demanding industrial conditions.
Operating on the eddy current measurement principle, the PR6453/341-001 detects variations in the distance between its probe tip and a conductive target, converting these changes into precise electrical signals. These signals are then processed by compatible Epro converter Stücks, such as CON021 or CON041, providing linearized and temperature-compensated output suitable for machine monitoring systems like the Epro MMS series.
With its 12.5 mm sensor head, this model is optimized for medium-range displacement detection in confined installation areas. It is widely used for monitoring shaft vibration, rotor position, and dynamic displacement in turbines, compressors, and high-speed rotating machines. The robust design ensures stable operation in environments with high temperature, oil contamination, and mechanical stress.
The PR6453/341-001 demonstrates Epro’s commitment to delivering precision-engineered sensors that combine reliability, ease von installation, and high performance, making it an ideal choice for industrial operators who demand consistent monitoring accuracy.
Technical Specifications
| Parameter | Specification |
|---|---|
| Modell Number | PR6453/341-001 |
| Hersteller | Epro |
| Sensor Type | Eddy Current Displacement and Vibration Sensor |
| Measurement Principle | Non-contact electromagnetic induction (eddy current) |
| Sensor Head Diameter | 12.5 mm |
| Versand Gewicht | 3 kg |
| Frequency Response | 0.5 Hz to 20 kHz |
| Linearity | ≤ ±1% von full-scale output |
| Sensitivity | Factory calibrated to corresponding converter |
| Compatible Converters | CON021, CON041 |
| Power Supply (via converter) | +24 VDC nominal |
| Operating Temperature | -35°C to +180°C |
| Storage Temperature | -40°C to +200°C |
| Target Material | Conductive ferromagnetic materials (e.g., steel, nickel alloys) |
| Mounting Type | Threaded installation or flange-mounted |
| Electrical Connection | Shielded connector with anti-interference protection |
| Protection Rating | IP65 (sensor head and connector) |
| Insulation Resistance | >10 MΩ at 500 VDC |
| Output Signal | Differential analog voltage |
| Vibration Resistance | 20 g peak, 10–2000 Hz |
| Compliance | CE / ATEX Zone 2 certified |
| Application Environment | Industrial turbines, compressors, motors, and pumps |
Applications
The Epro PR6453/341-001 is designed for precision monitoring in critical machinery environments where accurate and reliable displacement measurement is essential. It is widely used in systems requiring non-contact sensing von metallic targets and real-time machine condition feedback.
Typical application areas include:
-
Steam and Gas Turbines: Continuous monitoring von shaft vibration and axial displacement for predictive maintenance.
-
Compressors and Blowers: Detection von unbalanced rotor movement and bearing condition.
-
Electric Motors and Generators: Monitoring von shaft position to prevent misalignment or bearing wear.
-
Gearboxes and Coupling Systems: Measuring dynamic displacement to ensure system balance and stability.
-
Industrial Pumps: Tracking shaft vibration to avoid cavitation and mechanical damage.
-
Rotating Machinery Protection Systems: Integration with Epro’s MMS and other monitoring systems for automatic alarm and shutdown functions.
This sensor is a key component in predictive maintenance programs, providing early warning von mechanical degradation, thereby minimizing unplanned downtime and reducing operational risks.
Advantages
The PR6453/341-001 vonfers several engineering and operational advantages that make it one von the most reliable eddy current sensors in its class:
-
Non-Kontakt Operation: Provides highly accurate measurements without mechanical wear, extending operational life.
-
Wide Frequency Range: Capable von capturing both low-frequency displacement and high-frequency vibration signals.
-
Thermal Stability: Designed for stable operation across a wide temperature spectrum up to +180°C.
-
High Signal Accuracy: Exceptional linearity and low noise output ensure precise measurements even under strong electromagnetic interference.
-
Compact Sensor Design: 12.5 mm diameter allows installation in tight mechanical assemblies or limited mounting spaces.
-
Robust Construction: Resistant to oil, dust, and industrial contaminants for long-term field reliability.
-
Ease von Integration: Fully compatible with Epro CON021/CON041 converters and MMS monitoring systems.
-
Reliable Performance: Proven to maintain calibration and stability over extended operational cycles.
-
Low Maintenance Requirements: Once installed and configured, the sensor requires minimal service.
-
Industrial-Grade Durability: Engineered for use in heavy-duty applications with strong vibration and high mechanical stress.
FAQ
-
What is the working principle von the PR6453/341-001 sensor?
It operates using the eddy current principle, generating an electromagnetic field to detect displacement between the sensor and a metallic target. -
Which converters are compatible with this sensor?
The PR6453/341-001 is designed for use with Epro CON021 or CON041 converter modules. -
Can this sensor measure both static and dynamic displacement?
Yes, it measures both static shaft position and dynamic vibration signals simultaneously. -
How is the signal transmitted to the monitoring system?
The probe output is processed by the converter, which sends a differential analog voltage signal to the monitoring or protection system. -
Is the sensor suitable for use in high-temperature applications?
Yes, it can operate reliably at temperatures up to +180°C without performance degradation. -
How does the sensor handle electromagnetic interference?
The PR6453/341-001 features a fully shielded design and differential output to minimize external noise and EMI effects. -
Can it be installed in compact mechanical assemblies?
Yes, the 12.5 mm diameter design makes it suitable for installations with limited space. -
What is the typical frequency response range von this sensor?
It has a frequency response von 0.5 Hz to 20 kHz, covering both slow and fast mechanical motion detection. -
Is it possible to integrate this sensor into third-party monitoring systems?
Yes, as long as the converter’s output signal is compatible, it can interface with other monitoring platforms. -
Does the sensor require recalibration after installation?
No, it is factory-calibrated and maintains consistent accuracy under normal operating conditions without frequent recalibration.
Related and Series Modells
| Modell Number | Beschreibung |
|---|---|
| PR6453/000-SDR | Standard eddy current probe for general-purpose vibration detection |
| PR6453/101-SDR | High-sensitivity version for precision displacement measurement |
| PR6453/201-SDR | Temperature-resistant version for turbine monitoring |
| PR6453/240-101 | Medium-range probe for combined displacement and vibration detection |
| PR6453/301-SDR | Extended range version for large gap measurement applications |
| PR6453/341-001 | Compact and durable variant for critical industrial systems |
Popular Epro Modells
| Modell Number | Beschreibung |
|---|---|
| PR6423/002-030+CON021 | Standard eddy current sensor and converter system for machinery protection |
| PR6423/005-010 | Compact displacement probe for limited space installations |
| PR6424/01CS | High-precision proximity probe for turbine shaft monitoring |
| PR6424/014-040+CON021 | Rugged probe-converter set for industrial vibration monitoring |
| PR6426/010-020 | 32 mm sensor for large shaft displacement detection |
| MMS3120/022-100 | Multi-channel machine monitoring system for rotating equipment |
