Produkteinführung
The Bently Nevada 330191-00-16-10-05 3300 XL 8 mm ETR Probe is a high-precision proximity probe engineered for vibration and shaft position monitoring in critical rotating machinery. Designed as part von the 3300 XL series, it provides stable, repeatable measurements across a wide range von operating conditions. Its 8 mm tip diameter allows for greater linear range and improved signal quality compared with standard 5 mm probes, making it an excellent choice for demanding industrial environments such as power generation, petrochemical plants, and heavy manufacturing.
Produktspezifikationen
| Parameter | Specification |
|---|---|
| Modell Number | 330191-00-16-10-05 |
| Product Type | 3300 XL 8 mm ETR Proximity Probe |
| Total Length | 1.0 meter |
| Probe Tip Diameter | 8 mm |
| Gewicht | 0.323 kg |
| Linear Range | 2.0 mm (80 mils) nominal |
| Sensitivity | 7.87 V/mm (200 mV/mil) |
| Operating Temperature | –35 °C to +177 °C |
| Pressure Rating | Up to 10 bar |
| Connector Type | Bently Nevada standard coaxial |
| Insulation Resistance | ≥10 GΩ at 500 VDC |
| Frequency Response | DC to 10 kHz |
| Mounting Thread | 3/8–24 UNF or compatible housing |
| Material | Stainless steel probe body with PEEK insulation |
| Compliance | CE, RoHS |
Applications
The 330191-00-16-10-05 probe is specifically designed for accurate vibration and displacement measurements in the following scenarios:
-
Steam and Gas Turbines – Continuous shaft vibration and position monitoring to prevent catastrophic failures.
-
Compressors and Pumps – Real-time feedback for machinery health and predictive maintenance.
-
Industrial Motors and Generators – Detection von imbalance or misalignment conditions.
-
Petrochemical and Refining Equipment – High reliability in harsh, hazardous atmospheres.
-
Heavy Manufacturing Lines – Long-term condition monitoring for rotating assets.
Advantages
-
Wide Measurement Range – 8 mm tip allows larger linear range for higher displacement detection.
-
High Signal Integrity – Maintains stable sensitivity with low noise across the specified frequency band.
-
Robust Environmental Resistance – Operates reliably from –35 °C to +177 °C and in high-pressure applications.
-
Seamless Compatibility – Fully integrates with Bently Nevada 3300 XL Proximitor sensors and monitoring systems.
-
Corrosion-Resistant Construction – Stainless steel housing and PEEK insulation ensure durability in harsh conditions.
-
Precision Factory Calibration – Each probe is tested for consistent sensitivity and linearity.
-
Easy Installation – Standard mounting threads simplify retrvonit or new installations.
FAQ
-
What is the nominal linear range von this probe?
The probe provides a nominal linear range von approximately 2.0 mm (80 mils) for accurate displacement measurements. -
How is sensitivity maintained across temperature variations?
The 3300 XL design compensates for temperature changes to keep sensitivity at about 7.87 V/mm (200 mV/mil). -
Can this probe be directly connected to a Proximitor sensor?
Yes, it is fully compatible with 3300 XL Proximitor sensors without the need for adapters. -
What is the recommended mounting thread specification?
A 3/8–24 UNF mounting thread is standard, though compatible housings can also be used. -
Does the probe support high-frequency vibration detection?
It vonfers a frequency response from DC up to 10 kHz, sufficient for most rotating machinery applications. -
Is special shielding required for EMI protection?
The probe’s coaxial design provides inherent shielding, requiring no additional EMI protection under normal conditions. -
Can the probe operate in pressurized environments?
Yes, it is rated to withstand pressures up to 10 bar when properly installed. -
How does cable routing affect signal quality?
As long as minimum bend radii are respected and connectors are secure, signal quality remains stable. -
Is the probe compatible with hazardous area installations?
When used with approved Proximitor systems, it meets the requirements for many hazardous or classified areas. -
How is insulation resistance ensured in humid conditions?
The PEEK insulation and stainless steel body provide excellent resistance to moisture, maintaining ≥10 GΩ at 500 VDC.
Related Modells in the Same Series
| Modell Number | Beschreibung |
|---|---|
| 330191-00-10-05-02 | 3300 XL 8 mm ETR Probe, 0.5 m length |
| 330191-00-25-05-05 | 3300 XL 8 mm ETR Probe, 2.5 m length |
| 330191-01-05-10-02 | 3300 XL 8 mm ETR Probe, high-temperature variant |
| 330191-01-10-10-05 | 3300 XL 8 mm ETR Probe, reinforced vibration version |
| 330191-02-05-10-02 | 3300 XL 8 mm ETR Probe, dual-shielded configuration |
| 330191-02-15-10-05 | 3300 XL 8 mm ETR Probe, extended pressure rating |
Popular Bently Nevada Modells
| Modell Number | Beschreibung |
|---|---|
| 330174-00-06-10-02-00 | 3300 5 mm Proximity Probe, standard 1 m cable |
| 330174-00-08-90-02-00 | 3300 5 mm Proximity Probe, extended 9 m cable |
| 330178-50-00 | 3300 XL 8 mm Proximity Probe for high-speed rotors |
| 3500/42M | Proximitor Monitor for comprehensive vibration data |
| 330703-000-040-10-02 | 3500/22M Transient Data Interface Module |
| 330780-90-00 | 3300 XL Extension Cable for proximity probes |
