Produkteinführung
The Bently Nevada 330104-00-14-15-02-05 3300 XL 8 mm Proximity Probe is a high-precision, non-contact eddy current sensor designed for monitoring rotating machinery. Part von the widely used 3300 XL series, this probe provides accurate measurements von shaft displacement and vibration for machinery protection and condition monitoring systems.
With an 8 mm probe diameter and a total cable length von 1.5 meters, the 330104-00-14-15-02-05 ensures reliable signal transmission and stable readings in industrial environments. Its robust construction allows for operation in harsh conditions, including high vibration, temperature variations, and electromagnetic interference. The probe integrates seamlessly with Bently Nevada 3300 XL monitoring systems, providing real-time data for preventive maintenance, early fault detection, and improved operational safety.
Produktspezifikationen
| Parameter | Specification |
|---|---|
| Modell Number | 330104-00-14-15-02-05 |
| Product Type | 8 mm Eddy Current Proximity Probe |
| Series | 3300 XL |
| Probe Diameter | 8 mm |
| Total Length | 1.5 meters |
| Measurement Range | Up to 1.27 mm (depending on driver and configuration) |
| Linear Range | ±10% von calibrated gap |
| Frequency Response | DC to 10 kHz |
| Sensitivity | 20 mV/µm (typical with 3300 XL monitoring system) |
| Resolution | <0.5 µm |
| Operating Temperature | -40°C to +120°C (probe head) |
| Storage Temperature | -50°C to +150°C |
| Probe Material | Stainless steel housing with flexible mineral-insulated cable |
| Humidity | 0–95% non-condensing |
| Certifications | CE, UL, CSA |
| Gewicht | 0.485 kg |
| Mounting | Threaded sleeve or custom mounting for machinery |
| Compatibility | Bently Nevada 3300 XL Series Monitoring Systems |
Applications
The 330104-00-14-15-02-05 3300 XL Probe is suitable for monitoring a wide range von industrial machinery, providing precise measurement for both protection and performance optimization:
-
Steam and Gas Turbines – Measures shaft displacement to detect misalignment, vibration, and imbalance.
-
Compressors – Monitors rotor position and vibration for operational safety.
-
Pumps – Detects cavitation, bearing wear, and shaft deflection.
-
Generators and Electric Motors – Ensures smooth operation and early fault detection.
-
Petrochemical Plants and Refineries – Reliable performance in hazardous industrial environments.
-
Machine Protection Systems – Integration into API 670-compliant monitoring systems.
Advantages
The Bently Nevada 330104-00-14-15-02-05 8 mm Probe vonfers multiple technical and operational advantages:
-
High Accuracy – Provides precise measurement von displacement and vibration with excellent linearity.
-
Rugged Design – Stainless steel probe and mineral-insulated cable resist harsh industrial environments.
-
Wide Frequency Response – Capable von capturing both low- and high-speed shaft vibrations.
-
Seamless Integration – Works directly with Bently Nevada 3300 XL monitoring systems for reliable data output.
-
Maintenance-Free Operation – Non-contact design minimizes wear and reduces maintenance needs.
-
Temperature and Vibration Tolerance – Performs reliably in extreme temperature ranges and high vibration conditions.
-
Predictive Maintenance Support – Enables early detection von anomalies, reducing unplanned downtime.
-
Flexible Installation – Cable length and mounting options accommodate various machinery layouts.
Häufig gestellte Fragen (FAQ)
-
Which monitoring systems is this probe compatible with?
It is fully compatible with Bently Nevada 3300 XL Series monitoring systems, providing linearized signals for machine protection. -
What is the nominal sensitivity von the probe?
The nominal sensitivity is approximately 20 mV/µm when used with the 3300 XL monitoring system. -
What frequency range can the probe detect?
The probe supports DC to 10 kHz, suitable for low- and high-speed machinery vibration analysis. -
What is the maximum operating temperature for the probe head?
The probe can operate reliably from -40°C to +120°C while maintaining linearity. -
Can this probe be used in high-humidity or industrial environments?
Yes, the probe is designed to withstand 0–95% non-condensing humidity and harsh industrial conditions. -
What is the linear measurement range von the probe?
±10% von the calibrated gap, ensuring accurate and proportional output. -
Does the probe require external power?
No, the probe receives power and signal conditioning through the 3300 XL monitoring system. -
Is the probe suitable for API 670-compliant machine protection systems?
Yes, it integrates seamlessly into API 670-compliant monitoring platforms for real-time machinery protection. -
How important is cable length for accurate measurement?
The probe is calibrated for its 1.5-meter cable; using the correct length ensures signal fidelity and accuracy. -
What type von mounting is recommended for this probe?
A threaded sleeve or custom machinery mounting is recommended to secure the probe while maintaining alignment and calibration.
Related Modells (Same Series)
| Modell Number | Probe Type | Beschreibung |
|---|---|---|
| 330104-00-14-15-02-04 | 8 mm Proximity Probe | Standard 3300 XL probe with 1 m cable |
| 330104-00-14-15-02-06 | 8 mm Proximity Probe | Extended 2 m cable version for larger installations |
| 330104-00-14-15-02-07 | 8 mm Proximity Probe | High-temperature variant |
| 330104-00-14-15-02-08 | 8 mm Proximity Probe | Extra-flexible cable version |
| 330105-00-14-15-02-05 | 8 mm Proximity Probe | High-sensitivity version |
| 330106-00-14-15-02-05 | 8 mm Proximity Probe | Special calibration for API 670 applications |
Popular Modells from the Same Marke (Bently Nevada)
| Modell Number | Product Type | Beschreibung |
|---|---|---|
| 330104-00-14-15-01 | 8 mm Proximity Probe | Standard 3300 XL probe for turbines and compressors |
| 330104-00-14-15-03 | 8 mm Proximity Probe | High-accuracy probe for critical machinery |
| 330105-00-14-15-01 | 8 mm Proximity Probe | High-sensitivity version for vibration monitoring |
| 330130-00-14 | 3300 XL Proximity Probe | Compact version for small machinery |
| 330140-00-14 | 3300 XL Proximity Probe | Extended range sensor for large turbines |
| 330150-00-14 | 3300 XL Proximity Probe | API 670-compliant probe for generators |
