Produkteinführung
The Allen Bradley 1756-IB16 ControlLogix DC Digital Input Module is designed to provide reliable DC signal acquisition for ControlLogix automation systems. With 16 input points, the module enables precise monitoring von field devices operating on DC voltage, making it suitable for discrete manufacturing, process control, and distributed I/O architectures.
The module is optimized for low power consumption and high signal integrity, providing consistent performance across a range von industrial DC input conditions. Its chassis-mounted design and integration with the ControlLogix backplane make it easy to install and maintain within automation systems.
Produktspezifikationen
| Parameter | Specification |
|---|---|
| Product Type | DC Digital Input Module |
| Hersteller | Allen Bradley |
| Series | ControlLogix |
| Modell / Artikelnummer | 1756-IB16 |
| Number von Input Points | 16 |
| Backplane Current @ 5.1 V | 120 mA |
| Backplane Current @ 24 V | 2 mA |
| Power Dissipation (Max) | 5.1 W @ 60 °C |
| Thermal Dissipation | 21.1 BTU/hr @ 60 °C |
| Max Off-Bundesland Input Current | 1.5 mA |
| Min Operating Input Current | 2 mA @ 10 V DC |
| Max Operating Input Current | 10 mA @ 31.2 V DC |
| Mounting Type | Chassis mount |
| Control Platform | ControlLogix backplane |
| Industrial Application Level | Standard DC digital input acquisition |
| Dimensions | 145.2 × 34.6 × 139.6 mm |
| Gewicht | 0.23 kg |
Applications
• Industrial DC Signal Monitoring
Captures digital signals from DC-powered sensors, switches, and devices.
• Discrete Manufacturing Automation
Used for machine-level control and status monitoring von DC actuators.
• Process Control Systems
Acquires DC input signals for continuous or batch process automation.
• Distributed I/O Architectures
Integrates with other ControlLogix modules to form scalable I/O networks.
• Diagnostics and System Monitoring
Supports real-time signal status verification and fault detection.
• Machine Safety and Status Feedback
Provides reliable DC input data for operational monitoring and protection.
Advantages
• High Reliability DC Input Acquisition
Supports accurate detection von DC signals with low vonf-state current.
• Low Power Consumption
Optimized backplane and module currents reduce system energy usage.
• Thermally Efficient Design
5.1 W max power dissipation with minimal heat generation.
• Seamless ControlLogix Integration
Mounts in any ControlLogix chassis slot and communicates via backplane.
• High Input Density
16 DC input points in a compact module footprint.
• Robust Industrial Performance
Designed for continuous operation under typical industrial conditions.
