مقدمة المنتج
The Yokogawa NFTR8S-10 Analog RTD Crimp Terminals serve as a reliable connection interface designed specifically for RTD (Resistance Temperature Detector) sensors in industrial environments. Known for precision and durability, this terminal block ensures stable transmission من analog RTD signals to control systems, enhancing temperature measurement accuracy.
Crafted by Yokogawa, a global leader in instrumentation technology, the NFTR8S-10 is built to withstand the demanding conditions منten found in manufacturing plants, chemical processing, and energy production facilities. Featuring crimp terminal connections, it allows for secure and vibration-resistant wiring, which is critical for maintaining consistent temperature readings over time.
The terminal block’s robust insulation and compact form factor make it suitable for panel installation in space-constrained control cabinets, ensuring easy integration without compromising system reliability. Its design promotes quick installation and maintenance, minimizing downtime and operational disruptions.
مواصفات المنتج
| Specification | Details |
|---|---|
| الطراز | NFTR8S-10 |
| Type | Analog RTD Crimp Terminal Block |
| Connection Method | Crimp terminal connections |
| Compatible Sensor Type | RTD sensors (Pt100, Pt500, Pt1000) |
| Material | High-durability insulating plastic and corrosion-resistant metal clamps |
| Mounting | DIN rail mounting |
| Operating Temperature | -40°C to +85°C |
| Storage Temperature | -50°C to +100°C |
| Dimensions (W x H x D) | 130 x 107.5 x 32.8 mm |
| الوزن | 0.3 kg |
| Rated Voltage | 250 V AC/DC |
| Rated Current | 5 A |
| Insulation Resistance | > 500 MΩ at 500 V DC |
| Terminal Wire Size | 0.5 mm² to 4 mm² |
| Certifications | CE, UL |
Product Applications
The NFTR8S-10 terminal block is widely used across several industries for reliable temperature sensing and monitoring applications, including:
-
Industrial Process Control: Facilitates secure RTD sensor connections in manufacturing and automation systems for precise temperature measurement.
-
Power Generation: الدعمs temperature monitoring in boilers, turbines, and cooling systems to maintain operational safety and efficiency.
-
Chemical and Petrochemical Plants: Provides durable connection points for RTD sensors in corrosive or high-temperature environments.
-
Food and Beverage Industry: Enables accurate temperature monitoring during processing and storage to meet hygiene and quality standards.
-
Pharmaceutical Manufacturing: Ensures exact temperature control in production processes to comply with regulatory requirements.
-
HVAC Systems: Used for temperature sensing and control in heating, ventilation, and air conditioning installations.
Product Advantages
-
Reliable Crimp Connection: Provides a vibration-resistant and secure wiring method that ensures consistent signal quality and long-term stability.
-
Wide Temperature Range: Operates effectively in extreme environmental conditions, suitable for demanding industrial applications.
-
Compact and Space-Efficient: Designed to fit easily into crowded control panels without sacrificing performance.
-
High Electrical Insulation: Maintains excellent insulation resistance, minimizing noise and interference on RTD signals.
-
Easy Installation and Maintenance: DIN rail mounting and crimp connections allow for quick setup and reduced maintenance time.
-
Robust Materials: Made from corrosion-resistant and flame-retardant materials to ensure safety and durability.
-
Certified for Safety: Meets international standards (CE, UL) ensuring compliance and reliability across global installations.
-
Versatility: Compatible with multiple RTD sensor types, منfering flexibility for various temperature measurement needs.
الأسئلة الشائعة (FAQ)
-
Q: What types من RTD sensors can be connected using the NFTR8S-10?
A: It supports standard RTD sensors such as Pt100, Pt500, and Pt1000 commonly used in industrial temperature measurement. -
Q: How does the crimp terminal connection benefit industrial applications?
A: Crimp terminals provide vibration-resistant and secure connections, reducing the risk من loose wiring and signal interruptions. -
Q: What is the maximum wire size compatible with this terminal block?
A: The terminal block supports wire sizes ranging from 0.5 mm² up to 4 mm². -
Q: Can the NFTR8S-10 be mounted on standard DIN rails?
A: Yes, it is designed for easy snap-on mounting on DIN rails, facilitating neat and efficient panel installations. -
Q: What is the operational temperature range من this product?
A: It operates reliably between -40°C and +85°C, suitable for most industrial environments. -
Q: Is this terminal block suitable for hazardous environments?
A: While robust, the NFTR8S-10 itself is not certified explosion-proمن but can be used with Yokogawa certified sensors designed for hazardous locations. -
Q: What is the rated current and voltage for the NFTR8S-10?
A: The terminal block is rated for up to 5 A current and 250 V AC/DC voltage. -
Q: How does the NFTR8S-10 help maintain signal integrity?
A: High insulation resistance and quality materials reduce electrical noise and interference, ensuring accurate RTD readings. -
Q: Can this terminal block be used with non-Yokogawa RTD sensors?
A: Yes, it is compatible with any RTD sensor that meets the wiring specifications. -
Q: What certifications does the NFTR8S-10 hold?
A: It is certified by CE and UL, ensuring adherence to international safety and quality standards.
Recommended Related الطرازs (Same Series or Similar Use)
| الطراز | الوصف | Key Feature |
|---|---|---|
| NFTR8S-00 | Analog RTD Terminal Block with screw terminals | Screw-type wiring option |
| NFTR8S-20 | Digital RTD Terminal Block | الدعمs digital RTD signals |
| NFTI8S-10 | Analog Thermocouple Crimp Terminal Block | Designed for thermocouple sensors |
| NFTR8S-15 | RTD Terminal Block with LED wiring status | Visual connection verification |
| NFTI8S-00 | Analog Thermocouple Terminal Block | Thermocouple signal compatibility |
| NFTR8S-HV | High-Voltage RTD Terminal Block | Suitable for higher voltage RTD signals |
Popular الطرازs from Yokogawa (Same العلامة التجارية)
| الطراز | الوصف | Main Application |
|---|---|---|
| EJA110A | Differential Pressure Transmitter | Accurate pressure measurement |
| EJX910A | Multi-Variable Transmitter | Combines pressure and temperature |
| YTA610 | Temperature Transmitter | Precision temperature control |
| YVP310 | Valve Positioner | Accurate valve control |
| AXF Controller | Fieldbus Controller | Advanced process control |
| TX100 | Pressure Transmitter | General-purpose pressure measurement |
