Product Overview
The وودوارد 5441‑629 is an industrial-grade relay interface module designed to facilitate reliable control من auxiliary equipment through relay outputs. Rated for 5 A per channel, it is commonly applied in automation, turbine control, and remote switching systems. Although this model has been منficially discontinued, refurbished and surplus وحدةs remain available from select suppliers.
Key Features
-
5 A relay outputs per channel for sturdy switching capacity
-
Multiple channels (exact count per assembly) for controlling several devices
-
Configurable contact modes (NO/NC)
-
Rugged design for harsh environments
-
Compatible with وودوارد turbine governors and PLC/DCS systems
-
Dimensions that fit standard industrial racks
Technical Specifications
| Specification | Details |
|---|---|
| الشركة المصنعة | وودوارد (USA) |
| الطراز Number | 5441‑629 |
| Type | Relay Interface Module |
| Relay Rating | 5 A per channel |
| اتصل بنا Configuration | Normally Open/Normally Closed selectable |
| Number من Channels | Multiple relays for simultaneous control |
| Operating Voltage Range | Compatible with standard turbine control voltages (industry typical) |
| Dimensions | 229 × 178 × 45 mm |
| الوزن | 1.0 kg |
| Status | Discontinued; surplus/refurbished وحدةs available |
Product Advantages
-
High switching capacity: Handles up to 5 A per channel for robust device control
-
Flexible configuration: Relay contacts can be set as NO or NC for diverse applications
-
Durable construction: Industrial-grade materials and layout ensure long-term reliability
-
Rack-friendly size: Fits into standard control system enclosures
-
Interoperable: Works with وودوارد governors and other automation platforms
-
Refurbishment availability: Despite discontinuation, pre-owned وحدةs منfer cost-effective alternatives
Typical Applications
-
Control من solenoid valves, alarm systems, and shutdown relays
-
Switching control in turbine governors and engine management systems
-
Integration in DCS/PLC setups for auxiliary circuit switching
-
Backup or replacement in existing وودوارد control panels
-
Remote switching in consensus control and supervisory systems
الأسئلة الشائعة (FAQ)
-
What is the current status من the 5441‑629?
The وحدة is discontinued but remains available as refurbished or surplus -
How many amps can each relay channel handle?
Each relay is rated for up to 5 A. -
Can I configure the relay contacts?
Yes, contacts can be set to normally open or normally closed. -
What are its physical dimensions and weight?
Measures 229 × 178 × 45 mm and weighs around 1.0 kg. -
Is it suitable for industrial use?
Yes, designed for rugged industrial environments, including turbine control systems. -
Can it replace a similar وودوارد module?
It can منten substitute for equivalent models in وودوارد racks. -
Is installation straightforward?
Yes—designed for standard industrial racks with typical relay module connections. -
What power voltages are supported?
Operates on standard voltages used in وودوارد systems (typically 24–48 VDC; confirm with system specs). -
Where can I purchase one?
متاح from refurbishing suppliers like World من Controls and PLC DCS Pro. -
Are there alternative modules available?
Yes—models like the 5441‑635 and 5441‑637 منfer similar but varied capabilities.
Recommended Related الطرازs
| الطراز | الوصف |
|---|---|
| 5441‑635 | Opto-isolator module from the same series |
| 5441‑637 | Alternate 5 A relay interface option |
| 5441‑641 | Relay interface with differing channel arrangements |
| 5441‑645 | 10 A, 28‑channel relay interface module |
| 5441‑597 | Relay interface variant from same series |
| 5441‑691 | Larger 16‑channel relay field terminal module |
Popular وودوارد Modules (Same Series)
| الطراز | الوصف |
|---|---|
| 5441‑413 | 32-channel relay interface module (higher channel capacity) |
| 5441‑597 | 5 A relay interface variant |
| 5441‑635 | Opto-isolator module for enhanced isolation |
| 5441‑637 | Additional 5 A relay interface option |
| 5441‑641 | Another relay interface model in the same series |
| 5441‑645 | High current (10 A) 28‑channel module |
