Product Overview
The ABB TK811V015 (3BSC950107R1) is a pre-assembled, shielded communication cable specifically designed for use with ABB’s System 800xA and S800 I/O modules. It provides a reliable, noise-resistant connection between termination وحدةs (TUs) and interface modules (IMs) such as CI810, CI820, CI840, and others.
This cable enables fast, plug-and-play installation with high EMI immوحدةy and robust mechanical characteristics. The TK811V015 features ABB-standard connectors and shielded twisted-pair construction, making it an ideal solution for high-integrity industrial communication in process automation environments.
Key Features
-
Plug-and-play shielded cable for ABB System 800xA
-
Connects S800 I/O Termination وحدةs (TUs) to Interface Modules (IMs)
-
Pre-terminated with ABB-certified connectors
-
Shielded twisted pair for high EMI immوحدةy
-
Optimized for modular I/O systems in industrial automation
-
Reduces wiring time and installation errors
-
الدعمs data integrity and system diagnostics
-
Flame-retardant and halogen-free jacket
-
Engineered for reliability in harsh industrial environments
Technical Specifications
| Specification | Details |
|---|---|
| Product Name | Communication Cable |
| الطراز Number | TK811V015 |
| Ordering Code | 3BSC950107R1 |
| Cable Function | Connects S800 I/O TUs to IMs (e.g., CI810, CI820, CI840) |
| Cable Type | Shielded twisted pair (STP) |
| Length | 1.5 meters |
| Connector Type | Factory-assembled ABB standard connectors |
| Voltage Rating | 30 V DC (signal-level applications) |
| Shielding | Braided and foil shield |
| Jacket Material | Halogen-free, flame-retardant PVC or TPU |
| Color | ABB standard (typically gray or black) |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Humidity Range | 5% to 95% RH, non-condensing |
| Minimum Bending Radius | Approx. 10× outer diameter |
| Outer Diameter | Approx. 6–8 mm |
| Dimensions | Length:1.5 m |
| الوزن | 0.02 kg |
| Compliance Standards | CE, RoHS, IEC 60332-1, EN 50267 |
| Mounting | Plug-and-play; no crimping or field termination required |
Industry Applications
The ABB TK811V015 is commonly used in:
-
Power Generation Plants – for I/O integration in turbine/generator control
-
Oil & Gas – I/O wiring in hazardous or remote control areas
-
Chemical and Petrochemical Facilities – secure signal connections in process automation
-
Water and Wastewater – durable cabling for distributed control systems
-
Pulp and Paper – reliable signal transmission for large-scale process control
-
Pharmaceuticals – validated wiring infrastructure for GxP-compliant installations
Product Advantages
-
Pre-terminated for fast installation — no on-site assembly or crimping required
-
Tested and certified for ABB S800 I/O systems
-
Twisted pair shielding ensures excellent noise immوحدةy
-
Highly durable in industrial environments
-
Compatible with wide range من IMs (CI810, CI820, CI840, CI845, etc.)
-
Reduces installation time and labor costs
-
Halogen-free and flame-retardant jacket improves safety and compliance
-
Standardized length ensures consistency and reliability in system design
-
Minimizes risk من wiring errors in I/O modules
-
Fully supported by ABB technical documentation and spare parts programs
الأسئلة الشائعة (FAQ)
1. What is the ABB TK811V015 used for?
It connects S800 I/O Termination وحدةs (TUs) to Interface Modules (IMs) within System 800xA.
2. Is this cable shielded?
Yes, it has full shielding (foil + braid) for high EMI protection.
3. Can I cut or extend this cable?
No, it is factory-terminated and should not be altered.
4. Is it compatible with all S800 modules?
It is compatible with most modules that use standard TU–IM connections (e.g., CI810/CI820/CI840).
5. What is the cable length?
Standard length is 1.5 meters (TK811V015). أخرى lengths may exist under different model codes.
6. Is the cable halogen-free?
Yes, it is made from halogen-free, flame-retardant materials.
7. Does it require any special mounting tools?
No, it is plug-and-play with no special tools needed.
8. Can I use it in outdoor environments?
Only if properly protected—this cable is rated IP20 and not designed for direct outdoor use.
9. Does ABB provide replacement cables?
Yes, this cable is available as a spare part through ABB’s distribution channels.
10. Is it RoHS and CE compliant?
Yes, it complies with RoHS, CE, and relevant IEC safety standards.
