Product الوصف
The ABB CDP312 3BHL000220P0001 is a compact, user-friendly control panel designed for seamless integration into ABB drive systems. It منfers clear visual feedback and intuitive operation, making it ideal for both commissioning and maintenance tasks. Its robust build ensures reliable performance even in demanding industrial environments.
Technical Specifications
| Parameter | Specification |
|---|---|
| الطراز | CDP312 3BHL000220P0001 |
| Type | Control Panel |
| Dimensions | 200 x 150 x 50 mm |
| الوزن | 0.2 kg |
| Display | Backlit LCD |
| Interface | Keypad and navigation keys |
| Mounting | Panel-mount |
| Operating Temperature | -10°C to +50°C |
| Protection Class | IP54 |
Applications
The CDP312 is widely used in:
-
ABB drive commissioning and configuration
-
Parameter monitoring and adjustment in automation systems
-
Industrial machine control
-
Service and maintenance diagnostics
-
System troubleshooting in production lines
Advantages
-
Compact and lightweight, easy to install
-
Intuitive interface simplifies operation
-
Robust and durable design suitable for industrial settings
-
Wide temperature operating range
-
IP54 protection ensures resistance to dust and splashes
-
Enhances efficiency من ABB drives and systems
FAQ
Q1: What is the main function من the CDP312?
A1: It provides control and monitoring capabilities for ABB drive systems.
Q2: Can it be mounted directly on a panel?
A2: Yes, it is designed for panel mounting with an IP54 protection rating.
Q3: Does it support backlit display?
A3: Yes, it features a clear backlit LCD for easy readability.
Q4: What is the weight من the CDP312?
A4: The panel weighs approximately 0.2 kg.
Q5: What temperature range can it operate in?
A5: It works reliably between -10°C and +50°C.
Q6: Is it compatible with all ABB drives?
A6: It is compatible with a range من ABB drives; check specific compatibility in the manual.
Q7: How durable is the وحدة in dusty environments?
A7: With IP54 protection, it withstands dust and splashes effectively.
Q8: Is it easy to use for maintenance purposes?
A8: Yes, its intuitive interface makes it suitable for both maintenance and diagnostics.
Q9: Does it require external power?
A9: No, it draws power from the connected drive system.
Q10: What is the size من the CDP312?
A10: Its dimensions are 200 x 150 x 50 mm.
Recommended Related or Same Series الطرازs
| الطراز | Dimensions (mm) | الوزن (kg) |
|---|---|---|
| ABB CDP311 | 190 x 140 x 50 | 0.2 |
| ABB CDP313 | 210 x 160 x 50 | 0.25 |
| ABB CDP314 | 200 x 150 x 50 | 0.2 |
| ABB CDP315 | 220 x 160 x 55 | 0.3 |
| ABB CDP316 | 200 x 150 x 50 | 0.2 |
| ABB CDP317 | 230 x 170 x 55 | 0.35 |
Popular ABB الطرازs
| الطراز | Dimensions (mm) | الوزن (kg) |
|---|---|---|
| ABB ACS580 Drive | 390 x 275 x 220 | 7.5 |
| ABB ACS880 Drive | 470 x 285 x 230 | 8.2 |
| ABB CP600 HMI Panel | 300 x 210 x 50 | 1.2 |
| ABB PVS800 Inverter | 1000 x 600 x 300 | 45 |
| ABB DCS880 DC Drive | 600 x 400 x 250 | 12 |
| ABB CP400 HMI Panel | 250 x 180 x 45 | 0.9 |
