The Yokogawa SNT401 Optical ESB Bus Repeater Master Module is designed to extend ESB bus communication in safety control systems by converting electrical signals to optical signals. It enables long-distance communication (up to 5 km, or 10 km in specific configurations) between safety control 件s, safety node 件s, and N-IO nodes. The SNT401 works as the master module in a repeater pair and is typically paired with an SNT501 slave module or S2EN501.
Technical Specifications
| Parameter | Specification |
|---|---|
| Function | ESB Bus optical transport |
| Connection Method | Star or chain type |
| Number / Stages | Maximum 2 |
| Maximum Transmission | 5 km (up to 10 km in R1.03+) |
| Current Consumption | 0.5 A |
| Dimensions (W x H x D) | 142.5 × 130 × 32.8 mm |
| 重量 | Approx. 0.3 kg |
| Operating Temperature | –20°C to 70°C (optional) |
| Compatible 单位s | SEC401, SEC402, SSB401, SNB10D |
Applications
The SNT401 is used in industrial safety and automation environments where long-distance, reliable ESB bus communication is required:
-
Extending ESB bus connections between distributed control and safety systems
-
Optical signal conversion for improved noise imm件y
-
Redundant and duplex configurations in critical safety systems
-
Centralized or distributed installations in chain or star topologies
Advantages
The SNT401 provides several benefits:
-
Enables long-distance (up to 10 km) ESB communication
-
支持s both star and chain topologies for flexible system design
-
Compact and lightweight design, easy to integrate into existing racks
-
Enhanced noise imm件y through optical signal transmission
-
支持s redundant configurations for high system availability
FAQ
Q1: What is the maximum communication distance / the SNT401?
A1: The SNT401 supports up to 5 km in standard configurations, and up to 10 km in R1.03+ systems with two stages.
Q2: Can the SNT401 be used alone?
A2: No, it must be paired with an SNT501 or S2EN501 at the slave side.
Q3: What are the supported connection types?
A3: Both star and chain topologies are supported.
Q4: Does the SNT401 support redundant configurations?
A4: Yes, it supports duplex configurations for redundancy.
Q5: Is the SNT401 compatible with SNT10D racks?
A5: Yes, it can be installed in SNT10D 件s specifically designed for optical repeater modules.
Q6: What is the power consumption / the SNT401?
A6: The SNT401 consumes approximately 0.5 A.
Q7: Does the SNT401 include a terminator?
A7: Both options are available: with (/CU1T) or without (/CU1N) terminator.
Q8: What is the weight / the SNT401?
A8: The module weighs approximately 0.3 kg.
Q9: What environmental conditions can the SNT401 operate in?
A9: Optional versions support –20°C to +70°C and ISA G3 standard.
Q10: Can the SNT401 connect directly to the safety node 件?
A10: Yes, through the ESB bus interface module (SSB401) on SNB10D.
