产品介绍
The Yokogawa ASD533-S00/SD3S0 Digital Output Module is a high-performance I/O module specifically designed for Yokogawa DCS (Distributed Control System) platforms. This module provides precise digital output control to operate field devices such as relays, solenoids, actuators, and indicator lights, converting system commands into reliable electrical signals for automation processes.
Engineered for demanding industrial environments, the ASD533-S00/SD3S0 ensures high-speed response, signal integrity, and safe operation. Its design supports robust electrical isolation, seamless DCS integration, and clear status monitoring, making it suitable for critical applications in power generation, chemical processing, oil and gas, and manufacturing industries.
产品规格
| Parameter | Value |
|---|---|
| 型号 Number | ASD533-S00/SD3S0 |
| Module Type | Digital Output Module |
| Output Channels | 16 channels |
| Output Signal Type | Relay / DC switching |
| Output Voltage | 24 VDC nominal |
| Output Current | 0.5 A per channel |
| Isolation | Channel-to-channel and channel-to-system |
| Response Time | ≤ 10 ms |
| Communication Interface | Yokogawa DCS backplane compatible |
| LED Indicators | Status LED for each output channel |
| Operating Temperature Range | 0°C to +55°C |
| Storage Temperature | -20°C to +70°C |
| Humidity | 5% to 95% RH, non-condensing |
| Dimensions (H × W × D) | 107.5 × 130 × 32.8 mm |
| 重量 | 0.3 kg |
Applications
The ASD533-S00/SD3S0 Digital Output Module is widely used in:
-
Process Control Systems: Controlling valves, solenoids, and actuators in chemical, petrochemical, and manufacturing plants.
-
Power Generation: Operating breakers, alarms, and turbine auxiliary equipment.
-
Oil & Gas Industry: Driving pumps, compressors, and indicator lights in field operations.
-
Water and Wastewater Treatment: Controlling motor starters, pump sequences, and alarm indicators.
-
Industrial Automation: Managing robotic actuators, conveyors, and production equipment.
-
Process Safety Systems: Triggering alarms, interlocks, and emergency shutdown outputs.
Advantages
-
High Channel Density: 16 output channels per module for efficient rack space utilization.
-
Fast and Reliable Response: ≤10 ms response time ensures real-time control / devices.
-
Electrical Isolation: Channel-to-channel and channel-to-system isolation improves safety.
-
LED Status Indicators: Each output channel has an LED for instant visual diagnostics.
-
Seamless Integration: Fully compatible with Yokogawa DCS backplane systems for plug-and-play installation.
-
Robust Design: Reliable operation under varying temperature and humidity conditions.
-
Flexible Output Control: 支持s both relay and DC switching for diverse field applications.
-
Enhanced Safety and Diagnostics: Suitable for critical control applications with real-time monitoring.
FAQ
-
How many output channels does the ASD533-S00/SD3S0 module have?
It supports 16 independent digital output channels. -
What devices can the module control?
It can operate relays, solenoids, actuators, and indicator lights. -
What is the nominal output voltage?
The nominal output voltage is 24 VDC. -
What is the maximum current per channel?
Each channel can deliver up to 0.5 A. -
Does the module provide electrical isolation?
Yes, channel-to-channel and channel-to-system isolation are provided. -
What is the module’s response time?
The response time is ≤ 10 ms, suitable for real-time operations. -
Can the module be used with other Yokogawa I/O modules?
Yes, it integrates seamlessly with Yokogawa DCS backplane systems. -
Does the module include visual status indicators?
Yes, each channel has an LED indicator for easy troubleshooting. -
What is the operating temperature range?
The module operates between 0°C and +55°C. -
Is this module suitable for safety-critical applications?
Yes, it can drive outputs for alarms, interlocks, and emergency shutdowns.
Related 型号s from the Same Series
| 型号 Number | 描述 |
|---|---|
| ASD533-S01 | Digital Output Module with higher current rating |
| ASD533-S02 | Redundant power output module |
| ASD533-S03 | High-speed switching output module |
| ASD533-S04 | Module with surge protection for outputs |
| ASD533-S05 | Extended voltage range output module |
| ASD533-S06 | Relay output module with diagnostic LED array |
Popular 型号s from the Same 品牌
| 型号 Number | 描述 |
|---|---|
| ASD143-P00/SB4S0 | Digital Input Module for DCS systems |
| YD100 | Analog Input Module for process measurement |
| YD200 | Analog Output Module for control systems |
| YS100 | High-speed counter module |
| YS200 | Pulse input module for flow measurement |
| YG200 | Relay Output Module for alarms and interlocks |
