The Yokogawa ALP111-S00 S1 is a high-reliability Vnet/IP Communication Module designed for use in Yokogawa’s CENTUM VP control systems. As a critical interface between the control processor (FCS) and the Vnet/IP control network, this module provides fast, redundant, and deterministic communication that forms the backbone / real-time industrial automation.
This S1 revision / the ALP111 series builds on the original model’s stability and robustness, /fering improved diagnostic capabilities and compatibility with newer CENTUM VP versions. Built to meet the strict demands / process industries, the ALP111-S00 S1 ensures seamless system integration, high-speed data transfer, and uninterrupted plant operation.
Whether in power generation, oil & gas, petrochemical refining, or large-scale manufacturing, this module is a trusted communication link in mission-critical infrastructure.
产品规格
| Parameter | Specification |
|---|---|
| 型号 Number | ALP111-S00 S1 |
| 制造商 | 横河 Corporation |
| Product Type | Vnet/IP Communication Module |
| Communication Protocol | Vnet/IP (Yokogawa proprietary Ethernet-based control network) |
| Ports | 2 x RJ-45 Ethernet (100BASE-TX) |
| Redundancy | 支持s dual-network redundancy for Vnet/IP |
| Communication Speed | 100 Mbps (Full Duplex) |
| Application Interface | Connects FCS to Vnet/IP bus |
| Status Indicators | LEDs for link, activity, module status |
| Self Diagnostics | Yes (Network status, link error, configuration mismatch) |
| Power Consumption | Approx. 5.5 W |
| Operating Voltage | Supplied through base rack |
| Operating Temperature | 0°C to 50°C |
| Storage Temperature | -20°C to 70°C |
| Humidity Range | 5% to 95% RH (non-condensing) |
| Shock & Vibration | Conforms to IEC industrial standards |
| Mounting | Rack-mounted (standard Yokogawa baseplate) |
| Dimensions (W x H x D) | 130 x 129.5 x 32.8 mm |
| 重量 | 0.3 kg |
| Compliance | CE, CSA, UL, ATEX compliant (depending on system setup) |
Product Applications
The ALP111-S00 S1 module is purpose-built for integration into Yokogawa’s CENTUM VP and similar high-availability systems. Its typical applications include:
-
Control Network Communication: Acts as the communication interface between FCS (Field Control Station) and Vnet/IP.
-
Distributed Control Systems (DCS): Enables real-time, redundant messaging across network nodes.
-
Redundant System Topologies: Facilitates fault-tolerant designs with dual Ethernet connections.
-
Process Plant Control Systems: Used in industries such as oil refining, gas processing, and chemical production.
-
Energy & Utilities: Provides communication between turbines, boilers, and safety systems.
-
Remote Station Integration: 支持s field stations and remote I/O over Vnet/IP.
Product Advantages
-
Dual-Port Redundancy: Built-in support for dual network ports ensures no single point / failure.
-
Fast and Deterministic Communication: Enables real-time response required in continuous processing.
-
Compact & Modular: Slim design allows efficient use / rack space with minimal footprint.
-
Diagnostic Feedback: Provides in-depth self-diagnostic capabilities to detect errors or faults.
-
Robust Industrial Design: Withstands environmental stress including temperature fluctuations and vibrations.
-
Seamless CENTUM VP Integration: Fully compatible with Yokogawa DCS architecture, both legacy and current versions.
-
Simplified Maintenance: LED indicators and error reporting simplify field servicing and troubleshooting.
常见问题 (FAQ)
-
Q: What is the primary function / the ALP111-S00 S1?
A: It provides a communication interface between the Field Control Station (FCS) and the Vnet/IP control network in a CENTUM VP system. -
Q: Does this module support network redundancy?
A: Yes, it has two Ethernet ports for redundant Vnet/IP network connections. -
Q: Can the ALP111-S00 S1 be used in safety-critical environments?
A: Yes, it is designed for mission-critical process control and is compliant with industrial standards like ATEX and UL. -
Q: What is the difference between ALP111-S00 and ALP111-S00 S1?
A: The S1 version includes firmware and hardware improvements for enhanced compatibility and diagnostics. -
Q: What is the communication speed supported by this module?
A: It supports 100 Mbps full-duplex Ethernet communication. -
Q: Is it compatible with older CENTUM CS3000 systems?
A: No, it is optimized for CENTUM VP systems and newer generations. -
Q: How is the module powered?
A: It draws power directly from the baseplate it is mounted on. -
Q: Can this module be hot-swapped?
A: No, it must be replaced with the system powered down to prevent communication disruption. -
Q: What are the available diagnostic features?
A: It /fers LED indicators for link status, module error, and configuration mismatch alerts. -
Q: In what environments is this module typically used?
A: It’s widely used in oil & gas, chemical, power generation, and other process control industries.
Related or Similar 型号s (Same Series or Functionality)
| 型号 | 描述 | Protocol | Channels/Ports | Application |
|---|---|---|---|---|
| ALP121-S00 | Communication Module with enhanced diagnostics | Vnet/IP | 2 Ethernet | Backup/secondary network communication |
| ALR111-S00 | Remote Communication Module for FCS | Vnet/IP Remote | 2 Ethernet | Remote station interface |
| ALF111-S00 | FOUNDATION Fieldbus Communication Module | FF H1 | 2 FF Ports | Device-level control over FF network |
| AFF50D-S00 | Pr/ibus-DP Communication Interface | Pr/ibus-DP | 1 Pr/ibus Port | Integration with Pr/ibus field devices |
| AAI841-H00 | Analog Input Module (High-speed) | Internal I/O | 16 Channels | High-speed signal acquisition |
| AAI143-S00 | Analog Input Module (Standard) | Internal I/O | 16 Channels | General purpose analog input |
Popular Yokogawa 型号s (其他 High-Demand 产品)
| 型号 | 描述 | Module Type | Function |
|---|---|---|---|
| CP451-10 | Control Processor 单位 for FCS | CPU Module | Executes control strategies |
| PW482 | Power Supply Module for Control Rack | Power Module | Supplies DC power to rack components |
| AAI543-H00 | Analog Output Module, 8 Channels | Analog Output Module | Sends control signals to actuators |
| ADV151-P00 | Digital Input Module, 16 Channels | Digital Input Module | Captures binary input signals |
| AAR181-S00 | Relay Output Module, 16 Channels | Digital Output Module | Controls relays, indicators, solenoids |
| AAI143-H50 | High-Speed Analog Input Module, 16 Channels | Analog Input Module | Fast response measurement module |
