产品介绍
The 伍德沃德 9905-068 Load Sharing Speed Controller is an advanced component engineered to manage both speed control and load distribution among generator sets operating in parallel. As part / 伍德沃德’s industry-leading range / load-sharing and synchronizing equipment, this controller ensures precise regulation / engine or turbine speed while balancing the load between generators for optimal system stability.
The 9905-068 combines the functions / a traditional speed governor with those / a synchronizer and load-sharing 件, /fering integrated control in a single robust platform. It is particularly suited for applications where generators must operate seamlessly on an isolated bus or synchronize with utility power. Designed for both analog and digital interfacing, it supports droop and isochronous load sharing, automatic frequency regulation, and breaker control functions.
Built to perform in demanding industrial and marine environments, the controller helps extend equipment life, reduces fuel consumption, and ensures uninterrupted power delivery through intelligent generator management.
Technical Specifications
| Parameter | Specification |
|---|---|
| 型号 Number | 9905-068 |
| Product Type | Load Sharing Speed Controller |
| Operating Voltage | 18–32 VDC |
| Power Consumption | <15 W |
| Input Signal Type | MPU (Magnetic Pickup), Analog Speed Signal |
| Load Sharing Mode | Isochronous and Droop |
| Sync/Phase Matching | Built-in synchronizer & phase detection |
| Breaker Control | Relay output for breaker closure |
| Speed Range | 500 to 10,000 Hz (MPU frequency input) |
| Control Outputs | Actuator drive (PWM/analog) |
| Communication | Discrete I/O, optional RS-485 (via modules) |
| Operating Temperature | –40 °C to +70 °C |
| Storage Temperature | –55 °C to +85 °C |
| Humidity Tolerance | 95% RH non-condensing |
| Mounting | Panel mount |
| Dimensions (H × W × D) | 180 x 140 x 75 mm |
| 重量 | 1.87 kg |
| Certifications | CE, UL, CSA |
Applications
-
Power Generation Plants: Enables parallel operation / generator sets and precise load sharing among 件s.
-
Marine Propulsion and Auxiliary Systems: Manages synchronized generators on ships for propulsion or onboard power supply.
-
Oil & Gas Production Sites: Synchronizes multiple diesel or gas-powered generators for reliable backup and primary power.
-
Mining and Heavy Industry: Balances power loads across isolated generator systems to improve system stability.
-
Utility-Connected Gensets: Provides grid synchronization and load balancing to reduce grid disturbances and system stress.
-
Microgrid and Islanded Systems: Maintains frequency and power quality in distributed or /f-grid installations.
Advantages
-
Integrated Functionality: Combines load sharing, speed control, synchronization, and breaker control into one device.
-
High Accuracy: Offers fine control / frequency and phase alignment with ±0.25 Hz and ±5 degrees respectively.
-
Reliable Parallel Operation: Ensures seamless load transitions and optimized generator output sharing.
-
Wide Compatibility: Interfaces with 伍德沃德 and third-party actuators, governors, and breaker systems.
-
Flexible Configuration: 支持s droop and isochronous operation modes based on site requirements.
-
Environmentally Robust: Operates in extreme temperatures and harsh industrial environments.
-
Proven Safety and Compliance: Certified to meet global safety and performance standards (UL, CSA, CE).
-
Compact and Modular Design: Easy to install in new systems or retr/it into existing setups.
-
Low Power Consumption: Efficient electronics design minimizes energy usage and thermal output.
-
Built for Mission-Critical Applications: Reliable performance in critical infrastructure where power continuity is essential.
常见问题 (FAQ)
-
Q: What is the primary function / the 9905-068 controller?
A: It controls both the speed and load sharing / generators operating in parallel, with built-in synchronization features. -
Q: Can the 9905-068 synchronize generators with a utility grid?
A: Yes, it includes phase and frequency matching capabilities to synchronize with other generators or utility mains. -
Q: What type / input signals does it support?
A: It accepts magnetic pickup (MPU) signals and analog speed input for RPM monitoring. -
Q: Is the controller suitable for marine generator applications?
A: Absolutely. It is widely used in marine propulsion and auxiliary power systems. -
Q: What types / load sharing modes are supported?
A: Both isochronous and droop load sharing modes are supported. -
Q: Can it control generator breaker closing?
A: Yes, it has a dedicated relay output for breaker closure when sync conditions are met. -
Q: What is the operating temperature range / the controller?
A: It operates reliably between –40 °C and +70 °C. -
Q: How is the 件 mounted?
A: It is designed for panel mounting inside generator or control cabinets. -
Q: Is there built-in communication support?
A: Basic I/O communication is supported; RS-485 may be available through optional expansion. -
Q: What are the controller’s dimensions and weight?
A: It measures 180 x 140 x 75 mm and weighs 1.87 kg.
Related 型号s (Same Series or Functionality)
| 型号 Number | 描述 | Control Type | Dimensions (mm) | 重量 (kg) |
|---|---|---|---|---|
| 9905-067 | Load Sharing Controller, basic variant | Droop only | 160 x 160 x 105 | 2.0 |
| 9905-069 | LS/Synchronizer with RS-485 | Digital + Serial Comm | 160 x 160 x 105 | 2.1 |
| 2301A-G | Load Sharing & Speed Control, analog | Analog PID | 160 x 160 x 120 | 1.9 |
| 2301E | Advanced Load Sharing Controller | Digital PID, Ethernet | 180 x 180 x 130 | 2.2 |
| 9905-045 | Dual Breaker LS Controller | Dual-sync & load share | 171 x 171 x 140 | 2.3 |
| 8440-1801 | EasyGen 3200 with Load 分享 & Sync | Digital, HMI included | 244 x 175 x 100 | 1.8 |
