产品介绍
The 伍德沃德 5501-470 CPU Module is a high-performance central processing 件 designed for use in advanced control systems within industrial environments. As a critical component in turbine, engine, and generator control systems, it acts as the computational brain, executing real-time instructions, managing communication protocols, and ensuring precise control logic execution across distributed systems.
This module is part / 伍德沃德’s 5000 series, known for its robust design, reliability, and seamless integration with 伍德沃德 control architectures such as MicroNet™ and NetCon™. Built to operate in demanding conditions, the 5501-470 is ideal for applications requiring fast response times, secure system handling, and long-term operational stability.
产品规格
| Parameter | Details |
|---|---|
| 型号 Number | 5501-470 |
| 制造商 | 伍德沃德 Inc. |
| Series | MicroNet™ / NetCon™ |
| Function | Central Processing 单位 Module |
| Processor Type | High-speed industrial-grade microprocessor |
| Operating System | Real-Time Embedded OS |
| Memory | Flash and DRAM for logic and runtime operations |
| I/O Compatibility | Compatible with 伍德沃德’s I/O and communication modules |
| Communication Ports | Ethernet, Serial (RS-232/485), CAN, Modbus TCP/IP |
| Redundancy | Yes, supports CPU redundancy configurations |
| Operating Temperature | -20°C to +70°C (-4°F to +158°F) |
| Storage Temperature | -40°C to +85°C (-40°F to +185°F) |
| Humidity Tolerance | 5% to 95% non-condensing |
| Power Supply | 18–32 VDC (typical 24 VDC) |
| Dimensions | 260 x 180 x 50 mm |
| 重量 | 1.1 kg |
| Mounting Method | Chassis-mounted via backplane |
| Certifications | CE, UL, CSA, RoHS, and marine approvals (DNV, ABS) |
| Hot-Swappable | No (requires power-down for safe removal) |
| Firmware Update 支持 | Yes, via serial or Ethernet connection using 伍德沃德 tools |
Applications
The 伍德沃德 5501-470 CPU Module is widely utilized across multiple industries where precision, performance, and durability are essential. Primary applications include:
-
Gas and Steam Turbine Control: Provides deterministic control logic execution for rotating machinery and energy management.
-
Power Generation Systems: Central processor in generator control systems for real-time monitoring and dispatching.
-
Compressor and Pump Skids: Used for PLC-style control and synchronization in oil & gas operations.
-
Marine Propulsion Systems: Executes control logic for engine safety, navigation auxiliaries, and load distribution.
-
Industrial Process Automation: Integration with fieldbus and supervisory control systems (SCADA).
-
Cogeneration and CHP Plants: Ensures seamless management / combined heat and power systems in mission-critical plants.
Product Advantages
-
Reliable Real-Time Performance: Engineered to handle fast control loops with deterministic behavior.
-
Flexible Communication: Equipped with multiple standard protocols including Modbus, Ethernet, and CAN for broad connectivity.
-
High Integration Compatibility: Seamlessly integrates with 伍德沃德’s I/O, HMI, and supervisory systems.
-
Rugged Industrial Design: Operates reliably in harsh industrial environments with vibration, temperature, and electrical noise resistance.
-
Redundancy Ready: Can be configured for redundant CPU operation to ensure fault tolerance and system uptime.
-
Secure Boot and Firmware Management: Enhanced cybersecurity features for firmware integrity and secure updates.
-
支持 for Complex Control Logic: Handles multi-level sequencing, event management, and advanced PID control.
-
Certified for Global Use: Meets major international safety and environmental compliance standards.
常见问题 (FAQ)
-
What is the primary function / the 5501-470 CPU module?
It serves as the central processing 件 in 伍德沃德 control systems, managing logic execution, communication, and data handling. -
Is the module compatible with redundant CPU configurations?
Yes, the 5501-470 supports hot-standby CPU redundancy for mission-critical applications. -
Can the module be updated remotely?
Yes, firmware updates can be carried out via Ethernet or serial interface using 伍德沃德’s configuration tools. -
What communication protocols are supported?
It supports Ethernet, CAN, RS-232, RS-485, Modbus TCP/IP, and optionally Pr/ibus or DeviceNet (with add-on modules). -
Is this CPU suitable for marine environments?
Yes, it holds marine certifications including DNV and ABS, making it suitable for shipboard control systems. -
Can it be mounted in a standard industrial cabinet?
Yes, the module is chassis-mounted via a backplane and fits into standard industrial enclosures. -
Does it support high-speed control loops?
Absolutely. It is optimized for real-time applications with tight control loop timing and fast I/O response. -
Is it possible to perform diagnostics remotely?
Yes, remote monitoring and diagnostics are supported via integrated Ethernet communication. -
What tools are used for configuration and diagnostics?
伍德沃德 Toolbox™, Control Assistant™, and GAP™ are commonly used tools for configuring and diagnosing the module. -
What is the recommended power supply range?
It operates within 18–32 VDC, with 24 VDC being the nominal recommended input voltage.
Related 型号s from the Same or Compatible Series
| 型号 Number | 描述 | Key Feature | Dimensions (mm) | 重量 (kg) |
|---|---|---|---|---|
| 5501-380 | CPU Module for MicroNet Plus | 支持s advanced redundancy | 260 x 180 x 50 | 1.15 |
| 5501-451 | High-speed CPU Module | Enhanced Ethernet support | 260 x 180 x 50 | 1.10 |
| 5501-376 | NetCon-compatible CPU | Legacy system support | 255 x 180 x 50 | 1.05 |
| 8200-1304 | MicroNet Plus Controller Module | Used in turbine governor systems | 270 x 190 x 55 | 1.20 |
| 5501-498 | CPU Module with secure firmware | Secure boot enabled | 260 x 180 x 50 | 1.12 |
| 5501-389 | Redundant Controller Module | Hot-standby operation support | 260 x 180 x 50 | 1.18 |
Popular 型号s from 伍德沃德
| 型号 Number | Product Name | Application Area | Dimensions (mm) | 重量 (kg) |
|---|---|---|---|---|
| 505XT | Digital Steam Turbine Controller | Turbine control and synchronization | 300 x 180 x 65 | 2.30 |
| 2301E | Load Sharing & Speed Control | Generator and engine control | 210 x 110 x 45 | 1.40 |
| LS-5 | Generator Synchronizer and Load 分享 | Power management systems | 240 x 120 x 50 | 1.60 |
| Peak 150 | Gas Turbine Speed Controller | Small industrial turbines | 250 x 130 x 55 | 1.55 |
| easYgen-3500XT | Generator Controller | Paralleling & grid protection | 244 x 190 x 91 | 2.20 |
| ProTech-G II | Overspeed Protection System | Mechanical overspeed protection | 260 x 160 x 60 | 2.10 |
