产品介绍
The Schneider XBTG2110 Touch Screen Panel is a highly reliable and user-friendly Human-Machine Interface (HMI) designed to provide intuitive control and monitoring for industrial automation systems. As part / Schneider Electric’s Magelis XBT-G series, this panel /fers superior display clarity, responsive touch functionality, and flexible communication options to streamline operation across a wide variety / machines and processes.
The XBTG2110 combines a rugged hardware platform with advanced visualization capabilities, helping operators interact efficiently with control systems. Its wide compatibility with Schneider Electric PLCs and third-party controllers makes it a perfect fit for both new and retr/it automation projects. The panel is engineered for harsh industrial environments, ensuring long-term durability and performance even in demanding conditions.
产品规格
| Parameter | Specification |
|---|---|
| 型号 Number | XBTG2110 |
| Product Type | Touch Screen HMI Panel |
| Series | Magelis XBT-G |
| Display Size | 5.7 inches |
| Display Resolution | 320 x 240 pixels |
| Display Colors | 65,536 colors |
| Touch Type | Analog resistive touch screen |
| Processor | RISC 32-bit CPU |
| Memory (Flash ROM) | 8 MB |
| RAM | 16 MB |
| Communication Ports | RS232/RS485 serial ports, Ethernet |
| 支持ed Protocols | Modbus, Modbus TCP, Uni-Telway, DF1, and more |
| Input Voltage | 24 V DC |
| Power Consumption | 12 W max |
| Operating Temperature Range | 0°C to +50°C |
| Storage Temperature Range | -20°C to +60°C |
| Relative Humidity | 10% to 90% (non-condensing) |
| Dimensions (H x W x D) | 167.5 x 135 x 59.5 mm |
| 重量 | 1 kg |
| Mounting | Panel mount |
| Protection Rating (Front Panel) | IP65 |
| Certifications | CE, UL, cUL, CSA, C-Tick |
Applications
The Schneider XBTG2110 Touch Screen Panel is widely used across numerous industrial sectors where real-time visualization, operator interaction, and process control are required:
-
Factory Automation: Real-time display and control / production lines and machinery.
-
Packaging Equipment: Monitoring and setting parameters for automated packaging processes.
-
Food & Beverage: Interface for batch control, recipe management, and process visualization.
-
Water Treatment Plants: Monitoring / pump stations, valves, and filtration systems.
-
Energy Management: Supervising energy generation, distribution, and consumption.
-
Building Automation: Control / HVAC, lighting, and access systems.
-
OEM Machinery: Integrated interface for industrial machines and equipment.
-
Textile Industry: Monitoring and controlling textile production machinery.
Advantages
-
Large, High-Resolution Display: 5.7 inches VGA TFT display with bright, clear graphics.
-
User-Friendly Interface: Intuitive touch panel for simple navigation and control.
-
Wide Protocol 支持: Compatible with a variety / industrial communication standards.
-
Flexible Communication Ports: Multiple serial and Ethernet ports for seamless connectivity.
-
Rugged Industrial Design: IP65-rated front panel for dust and water protection.
-
Easy Installation: Simple panel mounting with compact depth pr/ile.
-
Broad Compatibility: Works with Schneider Electric PLCs and many third-party systems.
-
Long Lifecycle: Engineered for durability in harsh industrial environments.
-
Efficient Power Use: Low power consumption reduces operational costs.
-
Reliable Performance: Proven hardware stability ensures continuous operation.
常见问题 (FAQ)
-
What is the display size / the XBTG2110 panel?
It features a 5.7 inches TFT LCD display. -
What is the resolution / the touch screen panel?
The display resolution is 320 x 240 pixels. -
What types / communication does the XBTG2110 support?
It supports RS232, RS485, and Ethernet communication ports. -
Can this panel be used with non-施耐德s?
Yes, it supports multiple protocols and works with many third-party controllers. -
Is the front panel / the HMI protected against dust and moisture?
Yes, it is IP65-rated for protection against dust and water on the front panel. -
What is the power requirement / this HMI?
It operates on 24 V DC power. -
Does it support Modbus TCP/IP?
Yes, Modbus TCP/IP is supported along with other protocols. -
What is the operating temperature range?
The panel operates in temperatures from 0°C to +50°C. -
How is the XBTG2110 mounted?
It is designed for panel mounting. -
What s/tware is used to program the panel?
The panel is programmed using Schneider’s Vijeo Designer s/tware.
Related 型号s (Same Series / Related)
| 型号 Number | Product Type | Key Features |
|---|---|---|
| XBTG2120 | Touch Screen HMI Panel | 12.1″ TFT display, Ethernet |
| XBTG2330 | Touch Screen HMI Panel | 5.7″ STN display, RS232/RS485 |
| XBTGT2110 | Advanced Touch Panel | Enhanced CPU, USB ports |
| XBTGT4330 | Graphic Touch Terminal | 10.4″ TFT, 65K colors |
| XBTGT5330 | Graphic Touch Terminal | 12.1″ TFT, dual Ethernet |
| XBTGT7340 | Graphic Touch Terminal | 15″ TFT, advanced visualization |
Popular Schneider 型号s (Same 品牌)
| 型号 Number | Product Type | Key Features |
|---|---|---|
| HMIGTO5310 | Magelis GTO Touch Panel | 10.4″ TFT, Ethernet, USB |
| HMISTO512 | Magelis STO Touch Panel | Compact 5.7″ color display |
| HMIGTU6550 | Magelis GTU Modular Panel | 15.6″ wide screen, modular design |
| HMIPSPT3A0000 | Harmony iPC Panel PC | 15.6″ capacitive multi-touch |
| TM221CE24T | Modicon M221 PLC | Ethernet, CANopen, expansion |
| TM241CE40U | Modicon M241 PLC | 24 inputs/outputs, Ethernet |
